Audio Submenu

Figure 16.
The
Audio
and attenuation, output format, and volume.
Audio Mute — Press the navigation buttons to globally mute or unmute audio output.
Audio Format — Press the navigation buttons to select the audio input format. Input 1
can only be set to
format (see the table below for a description of the formats).
Format
Details
None
Mutes audio for the selected input. Sets "No Audio" EDID.
Analog 1
Sets the selected input to analog input 1. Sets "No Audio" EDID.
Analog 2
Sets the selected input to analog input 2. Sets "No Audio" EDID.
LPCM-2Ch
Sets the selected input to LPCM-2Ch audio. Sets 2Ch audio EDID.
Multi-Ch
Sets the selected input to Multi-Ch audio. Sets Multi-Ch audio EDID.
LPCM-2Ch Auto
Sets the selected input prioritize 2-channel LPCM audio. Audio on analog input 1
(Analog 1)
is passed when 2-channel LPCM audio is not present. Sets 2Ch audio EDID.
Multi-Ch Auto
Sets the selected input to prioritize multi-channel audio, but will pass 2-channel
(Analog 1)
LPCM if multi-channel audio is not available. Audio from analog input 1 is passed
when digital is not present. Sets Multi-Ch audio EDID.
LPCM-2Ch Auto
Sets the selected input prioritize 2-channel LPCM audio. Audio on analog input 2
(Analog 2)
is passed when 2-channel LPCM audio is not present. Sets 2Ch audio EDID.
Multi-Ch Auto
Sets the selected input prioritize multi-channel audio, but will pass 2-channel
(Analog 2)
LPCM if multi-channel audio is not available. Audio on analog input 2 is passed
when digital audio is not present. Sets 2Ch audio EDID.
Analog Gain and Attenuation — Press the navigation buttons to set the gain (in dB) for
the applicable analog input.
Output Format — Press the navigation buttons to set the output format.
Output Volume — Press the navigation buttons to set the audio output volume.
Audio Submenu
submenu allows adjustment of audio settings, including mute, input format, gain
,
, or
None
Analog 1
. Inputs 2-4 can be set for any audio input
Analog 2
IN1604 DTP and IN1604 HD Scalers • Operation
Inputs
All
All
All
2-4
2-4
2-4
2-4
2-4
2-4
24
