CONTROL BOARD ADJUSTMENTS (cont)
P.E INPUT RESPONSE MODE
The P.E input can be configured to respond in one of three modes.
OPEN AND CLOSE CYCLES STOP
In this mode all cycles are prevented from being
completed or initiated when the P.E input is
active.
CLOSE CYCLES STOP
In this mode the P.E input has no effect when
opening but will stop the gate when closing.
REVERSES CLOSE CYCLES
In this mode the P.E input has no effect when
opening but will cause the gate to reverse if
activated when closing.
PED INPUT FUNCTION
The PED input can be configured to a SWIPE type input for
pedestrian access. This provides full functionality with the P.E
Triggered Pedestrian auto-close function.
PARAMETER
P.E INPUT RESPONSE MODE Sets the P.E
response mode. Options are OPEN and CLOSE
cycles stop, Close cycles stop or Close cycle reverse
PED INPUT = SWIPE MODE Selects the PED input
functions as pedestrian access swipe input.
REMOTE CODE ENABLED
Selects remote transmitter coding function
TRANSMITTER ACTIVITY REPORTS
Select serial output of transmitter activity
VACATION MODE
Selects vacation mode - disables remote control.
BATTERY / SOLAR MODE
Selects Battery Backup / Solar operation

MENU 7 OPERATING MODES

REMOTE CODE
The controller supports the Remote Code Set feature. This
parameter can be used to disable the feature for security or
transmitter management reasons.
TRANSMITTER ACTIVITY REPORTS
This parameter enable transmitter activity report outputs for
logging access to the gate opener. Contact ATA for more details.
VACATION MODE
Vacation mode can be turned on or off using this parameter.
BATTERY / SOLAR MODE
The controller can be instructed to turn off the battery backup
facilities so that the control board can be shut down without hav-
ing to disconnect the battery backup system.
MIN
OPN&CLS stop
CLS to stop
CLS to Reverse
OFF
OFF
OFF
OFF
OFF
19
MAX DEFAULT STEP UNITS MENU #
CLS to
Reverse
ON OFF
ON ON
ON OFF
ON OFF
ON ON
7
7
7
7
7
7
