Features - Automatic Technology Easy Slider Installation Instructions Manual

Your Easy Slider Automatic Sliding Gate
Opener has many features which you will
appreciate. The components and materials
used in this Automatic Opener are of the
latest technology and highest quality.
Listed below are some of the many

features.

DUAL GATE INSTALLATIONS
The integrated controller is able to control
two sliding gates with the addition of a
slave sliding gate opener. Interconnection
is via 5 wire with mains power only
required for the master drive unit.
OPERATION
To operate the gate opener simply activate
one the integrated controller's control
inputs using a remote control transmitter,
keypad or many other devices such as key
switches, loop detectors etc. In response
the gate will then open, stop or close as
requested. Optionally, the controller can be
configured to automatically close after
operation using one of several auto-close
modes.
OPERATOR CONSOLE
Incorporated into the integrated controller
is a simple to use operator console which
consists of several buttons and a display.
The console greatly simplifies installation,
adjustments and status indication. With the
addition of the console, facilities were only
available on previous controller using an
additional hand held programmer are now
available as standard via a simple menu
system. Features include
transmitter storage and names, setting
various parameters, selecting specialized
operating modes and preforming system
diagnostics.
HOPPING CODE TRANSMITTERS
The integrated controller incorporates a
Hopping code remote control receiver.
Hopping code systems work by the
transmitters generating a new encrypted
access code each time they are activated.
As the receiver is able to follow the
encryption sequence and also rejects any
access code it has already received it is
able to foil code breaking techniques used
by thieves to gain unauthorised access. In
addition to this, each Hopping code
transmitter has a unique serial number - so
no two transmitters are alike. Further, with
a huge error rejection rate which allows
FEATURES
less than 1 error in 10
remote control system is greatly enhanced.
SECURITY CODE STORE
The Easy Slider Gate Opener uses state of
the art technology in storing your selected
transmitter security codes. Up to 575
different transmitters can be stored in the
opener's memory with the facility to
assign a 11 character name to each
transmitter.
ALPS (AUTOMATIC
POSITIONING SYSTEM)
We have developed a revolutionary gate
travel limit setting system. The ALPS
technology does away with manual
adjustment of the gates limits position
using mechanical parts such as micro
switches and cams. In addition the installer
is guided through the steps of installation
by the incorporated console's display.
The ALPS technology records the gates
travel limit positions and stores it in
memory. If the gate is moved manually
during power failure, the ALPS will
re-align the gate limits transparently
during the first operations after power is
restored and stop at the correct limit
position.
In addition, during installation, a hand held
transmitter can be used when setting the
gate travel limits. This allows the installer
to closely observe and control the gates
movement from any position rather than
editing having to be within arms reach of the
console.
ISS (INTELLIGENT SAFETY
OBSTRUCTION SYSTEM)
During installation, the "normal" motor
load is recorded for each section of gate
travel. During normal operation this
recorded "profile" is used as reference to
determine if the gate has encountered an
obstruction. If
encountered during a close cycle, the gate
will reverse to the open position. If the
gate encounters an obstruction during an
open cycle, the gate will stop. As the
"normal" profile of the gate changes with
age, the system continuously keeps the
recorded profile current. As this is a safety
feature the Obstruction System should be
checked at least once a month.
STATUS INDICATION
19 the security of the
The status of the gate opener can be
determined at anytime by observing the
console's screen. When the MAIN
SCREEN
position of the gate or the result of the last
movement can be found. The display will
also show the count down progress of the
auto-close timers. Any active input will
also be displayed along with the state of
various features such as periodic service,
battery backup operation and vacation
mode.
LIMITS
CONTROL OF LOCK AND LIGHTS
The incorporated controller has dedicated
outputs for operating a electric lock and
warning or courtesy lights. The timing of
these outputs can be adjusted to suit your
needs. In addition a button on a remote
control can be coded to operate the Light
output
EXTENSIVE OPERATING MODES
V I A C O N T R O L I N P U T S A N D
REMOTE CONTROL
The
configured to operate in many different
ways via its 7 control and safety inputs
which include P.E, OPEN, STOP, CLOSE,
OSC, SWIPE and PEDESTRIAN. Remote
control operation is provided with each
transmitter's button being able to be con-
figured
PEDESTRIAN, SWIPE, CLOSE, OPEN,
STOP, LIGHT or VACATION functions.
The controllers functionality is further
enhanced by 4 auto-close modes, 3 P.E
response modes and two pedestrian
response modes. For details refer to
relevant instruction manual sections.
BATTERY BACKUP AND SOLAR
OPERATION
The sliding gate opener can be fitted with
optional battery backup or solar chargers
to provide operation during power outages
or at unpowered sites respectively.
an obstruction is
MANUAL OPERATION
The opener is equipped with a unique
manual disengaging device. If the power to
the opener is disrupted for any reason the
gate can disengaged via a key lock located
on the operator. This will allow you to
manually open or close the gate.
4
is displayed, the current
integrated controller
to operate one of
can be
OSC,
