Control board adjustments
Menu 7. Operating modes
P.E input response mode
The P.E input can be configured to respond in one
of three modes.
Open and close cycles stop
In this mode all cycles are prevented from being
completed or initiated when the P.E input is
active.
Close cycles stop
In this mode the P.E input has no effect when
opening but will stop the gate when closing.
Reverses close cycles
In this mode the P.E input has no effect when
opening but will cause the gate to reverse if
activated when closing.
PED input function
The PED input can be configured to a SWIPE
type input for pedestrian access. This provides
full functionality with the P.E Triggered Pedestrian
auto-close function.
Remote code
The controller supports the Remote Code Set feature.
This parameter can be used to disable the feature for
security or transmitter management reasons.
Parameter
P.E INPUT RESPONSE MODE Sets the P.E
response mode. Options are OPEN and CLOSE
cycles stop, Close cycles stop or Close cycle
reverse
PED INPUT = SWIPE MODE Selects PED input
functions as pedestrian access swipe input
REMOTE CODE ENABLED
Selects remote transmitter coding function
ACTIVITY REPORTS Select report to be output
ACTIVITY REPORT ID
Selects ID for controller, sent with activity report
VACATION MODE
Selects vacation mode - disables remote control
BATTERY/SOLAR MODE
Selects Battery Backup/Solar operation
PASSWORD
Selects password protection for all changes
OPN INPUT N/O OPERATION
Selects operating polarity of OPN input
24 Easy Slider - Sliding Gate Opener
Activity reports
This parameter enables activity report outputs. Contact
ATA for more details.
Activity report ID
This parameter sets the ID of the controller that is sent
with the activity report. Contact ATA for more details.
Vacation mode
Vacation mode can be turned on or off using
this parameter.
Battery/solar mode
The controller can be instructed to turn off the battery
backup facilities so that the control board can be shut down
without having to disconnect the battery backup system.
Password protection
The password feature enables all parameters and
configuration settings to be protected unless a
password is entered. When this feature is turned on
the user is requested to enter the desired password
to be used. The password protection feature has a
time-out that expires after 60 seconds of inactivity.
Alternately the user may log out manually by pressing
exit when the main screen is displayed.
Open input polarity
The OPN input is normally configured for N/C operation.
This parameter allows its operation to be changed to N/O.
Min Max
OPN & CLS stop
CLS to stop
CLS to reverse
Off On
Off On
Off 255
0 65535
Off On
Off On
Off On
Off On
Owner Installation Instructions
Default Step Unit Menu No.
CLS to 7
reverse
Off 7
On 7
Off 1 7
0 1 7
Off 7
On 7
Off 7
Off 7
