TRANSMITTERS LIST MANAGEMENT (cont)
STEP 2. NAVIGATING THE LIST
The UP and DOWN buttons can be used to navigate through the
list by altering the transmitter number displayed. Note holding a
button down will step through the list faster. The longer the but-
ton is held the faster. Only locations which have a transmitter
stored will show the name and function fields.
Navigation Through List
#123 A & B SMITH
3
OSC PED LGT VAC
STEP 3. SELECTING LOCATION TO MODIFY.
When the desired location is displayed press the SET button to
display a menu of available functions that can be performed on
the location. The example uses transmitter number 123.
Selecting The Location
3
#123 A & B SMITH
OSC PED LGT VAC
STEP 4. SELECTING AN OPERATION
The three menus below are displayed by repeated presses of the
NEXT or PREV buttons. Pressing EXIT will return back to the
list (STEP 2). Pressing SET will execute the menu's operation.
Code / Replace Menu
MENU 1.1
Code

CODE OPERATION (LOCATION EMPTY)

If the code operation is selected on an empty transmitter location,
the BASIC CODE TRANSMITTER PROCEDURE will be initi-
ated with the transmitter being saved in the selected location. This
is useful when its is desired to associate the transmitter location
number with some aspect of the site at which the gate opener is
located. For example, the transmitter number could be set to
match the owner's apartment or unit number.
PRESS
PRESS
PRESS
TX# 123

CODE OPERATION (LOCATION USED)

If the code operation is selected for a location that already
contains a transmitter, then the BASIC CODE TRANSMITTER
PROCEDURE will be initiated and the new transmitter will
replace the existing one. Note that the button functions and name
of the existing transmitter will be transferred to the new
transmitter. This procedure is of great convenience when a
transmitter is lost and needs to be removed from the system for
security purposes, but at the same time a replacement needs to be
issued to the owner.

DELETE OPERATION

The delete operation is used to remove a transmitter from
memory along with the name and button function settings.
Delete Transmitter Menu
MENU 1.2
Delete TX#

EDIT OPERATION

The edit operation displays the transmitter record for editing pur-
poses. See TRANSMITTER EDIT PROCEDURE for details.
This operation is not available for transmitter locations which are
empty. The edit operation can be used to alter button functions
assigned to each button. It can also be used to alter the "NAME"
of the transmitter
Edit Transmitter Menu
MENU 1.3
Edit
STEP 6. EXITING THE LIST
To exit the transmitter list simple press EXIT to return to the Code
Transmitter Menu and then press EXIT again to return to the
MAIN SCREEN.
24
123
TX# 123
