7. Transfer Ribbon Mechanism
7.1 Description
Intermec EasyCoder 601 XP – Service Manual Ed. 2
The thermal transfer ribbon mechanism is standard, but can be
omitted on special order. The mechanism consists of three main
units:
• Ribbon unwind unit (see chapter 7.2)
• Ribbon rewind unit (see chapter 7.3)
• Ribbon-end sensor (see chapter 7.4)
Ribbon Rewind Unit
Ribbon Unwind Unit
Ribbon End Sensor
(hidden)
Chapter 7
