1. Models and Options

1.1 Identification

Intermec EasyCoder 601 XP – Service Manual Ed. 2
Presently, the EasyCoder 601 XP only comes in one main model;
a combined direct thermal/thermal transfer printer with a setup
keyboard and a 12 dots/mm printhead.
The printer can use 100 – 240 V AC, 50 – 60 Hz mains supply. There
is no voltage switch-over.
The machine sign on the printer's rear plate contains type, part
number, serial number, and signs of approval.
