5.1 Internal Supply,
cont'd.
Intermec EasyCoder 601 XP – Service Manual Ed. 2
Two adapters (standard accessories) can be fitted onto the bobbins
in order to accept paper rolls with 76 mm (3") cores. Each adapter
is locked by means of a #T20 Torx screw. Be careful not to let the
screw hit the leaf springs or the cams of the bobbins.
3" Adapters
Chapter 5 Paper Supply
26
