13.3 Main Parts
Power Supply
(hidden)
CPU Board
Intermec EasyCoder 601 XP – Service Manual Ed. 2
This illustration shows the complete electronics compartment, but
with the Centronics interface board removed to improve the view
of the CPU board.
Ribbon Unwind Unit
Paper Rewind Motor
Chapter 13
Ribbon Rewind Unit
Print Unit Stepper Motor
Electronics Compartment
84
