Configuring Lines

BIDIR Settings

When the
both directions in its original format. This raw TCP/IP connection can be initiated from either the
Terminal Server or the configured host.
Configure the following parameters:
Host Name
Port

UDP Settings

When the
the UDP settings.
Configure the following parameters:
Start IP Address
End IP Address
Port
Direction
68
Line Service is set to BIDIR
The name of the target host.
The port number the target host is listening on for incoming connections.
is set to
Line Service UDP
The first host IP address in the range of IP addresses (for IPV4 or IPV6)
that the Terminal Server will listen for messages from and/or send
messages to.
The last host IP address in the range of IP addresses (for IPV4, not
required for IPV6) that the Terminal Server will listen for messages from
and/or send messages to.
The port that the Terminal Server will use to receive messages from or relay
messages to servers/hosts.
The direction in which information is received or relayed:
None—UDP service not enabled.
In—LAN to serial.
Out—Serial to LAN.
Both—Messages are relayed both directions.
Terminal Server User Guide
, a bidirectional connection is created, with data flowing in
, the Terminal Server processes UDP packets according to
