Revolabs Fusion™
STEP 3: Pairing Microphones to Fusion Base Station if
Necessary
If you selected your microphones separately with the 01-8FUSION(EU)-NM or 01-4FUSION
(EU)-NM Fusion part numbers, you must first establish a connection between your
microphones to the Fusion Base Station. This is called "pairing".
Pairing creates a link with a unique electronic serial number between the Solo wireless
microphone and the Fusion Base Station. When the microphone and Base Station have been
previously paired, the microphone will automatically try to connect to the Base Station
whenever it is lifted from the Charger Base.
Note: Microphones in new systems must be paired to the Base Station with each microphone
assigned to a unique channel on the base unit.
Remember, microphones are always muted (flashing RED LED light) when they are removed from the
Charger Base and the MUTE button needs to be pressed to make it "live" (flashing GREEN LED).
A microphone that is not paired will be indicated by either cycling RED-GREEN, or RED-YELLOW-
GREEN LED patterns. A Base Station LED that is not paired to a microphone will not show any activity
on the LED (make sure unit is first powered on by observing GREEN power LED on the front panel).
When the microphone and Fusion Base Station are paired, both microphone and channel LEDs will flash
RED as microphones are removed from the Charger Base and flash GREEN when un-muted.
To pair the microphone to the Fusion Base Station:
Turn the microphone OFF (no LED activity). If the microphone is ON, press and hold the
MUTE button for 10 seconds until the LED turns solid RED (do not release when you hear two
beeps). Release the button to turn the unit off.
(Continued on next page.)
