Set-Up Guide

Specifications

Dimensions, (L, W, H) and Weight:
Fusion Base Station 16.45 x 8.46 x 1.7", 8.7 lbs
Charger Base 8.3 x 4.3 x 1.0", 1.0 lb
Wireless Microphones Wearable: 0.9 x 0.8 x 2.6", 0.05 lb
Tabletop: 1.5 x 0.8 x 3.3", 0.05 lb
XLR Adapter: 0.9 x 0.8 x 4.0, 0.05 lb
Radio Frequency:
01-8FUSION-XX 1.92 to 1.93 GHz (UPCS North America)
01-4FUSION-XX 1.92 to 1.93 GHz (UPCS North America)
01-8FUSIONEU-XX 1.88 to 1.90 GHz (DECT EU)
01-4FUSIONEU-XX 1.88 to 1.90 GHz (DECT EU)
Connectors:
Fusion Base Station
Charger Base DC power input port, Proprietary 4 pin microphone charge jacks
Power Requirements:
Fusion Base Station 100-240V AC, 50-60 Hz, 65W (power cable varies by country)
Charger Base 5V DC, 2 Amps (switching power supply varies by country)
Range: 100' (30 meters) approx. (no obstructions)
Maximum Microphones:
01-8FUSION(EU)-XX, 8 channels maximum
01-4FUSION(EU)-XX, 4 channels maximum
Battery: Lithium Polymer, 8 hours approx. talk time
Charge Time: 2 hours approx.
Audio Bandwidth 100-7000 Hz
Security: 128-bit DSAA (DECT Standard Authentication Algorithm) authentication
Page 30
41.8 x 21.5 x 8.7 cm, 3.95 kg
21.2 x 10.9 x 2.56 cm, 0.45 kg
IR Remote Serial DB9
CD Programming Serial DB9 - for Revolabs use only
Audio Control RJ45 – for Revolabs use only
Telephone Line-In RJ11
Telephone Set-In RJ11
Network RJ45 – for Revolabs use only
Conference Out XLR male
Aux In RCA Plug
Aux Out RCA Plug
Record Out RCA Plug
Room Out RCA Plug
Conference In RCA Plug
Conference Out RCA Plug
2.3 x 2.0 x 6.6 cm, 0.02 kg
3.8 x 2.0 x 8.4 cm, 0.02 kg
2.3 x 2.9 x 102 cm, 0.02 kg
