Set-Up Guide

Tabletop Master Mute

Setting the Mute Option
Individual Muting (default)
In the default setting, each Solo microphone will mute only itself when its mute button on the microphone is pressed. To
mute all of the microphones, press the red MUTE button on the Remote Control; all microphones will flash red and no
individual microphone can be unmuted until the remote MUTE button is pressed again. All microphones will return to their
prior state. DIP switch #5 is OFF (page 18).
Tabletop Microphone Master Mute
In addition to the Remote Control MUTE button muting all of the microphones, the Solo Tabletop microphone MUTE button
will also act as a master mute and mute all active microphones. Pressing any Tabletop microphone MUTE button or the
Remote Control MUTE button will unmute all tabletop microphones. All wearable and handheld adapter microphones in use
will return to their prior state. DIP switch #5 is ON (page 18).
NOTE: The Fusion system must be powered off and back on for any DIP Switch changes to take effect.
