Set-Up Guide

Remote IR Sensor

Setting the Remote IR Sensor Option
Front Panel IR Sensor (default)
If the Fusion Base Station is within view of the Remote Control, the front panel IR Sensor will accept all Remote Control
functions. DIP switch #7 is OFF (page 18).
Remote IR Sensor
If the Fusion Base Station is in a cabinet and behind a door (non-metal), the front panel IR Sensor cannot work. The Remote
IR Sensor cable (part number: 07-IRREMO-01) must be used to position the Fusion IR Sensor outside of the cabinet. Plug the
serial plug end into the IR Remote connector on the back panel of the Fusion Base Station (page 9), bring IR Sensor end out
of cabinet, and secure with Velcro. then set DIP switch #7 to ON (page 18).
NOTE: The Fusion system must be powered off and back on for any DIP Switch changes to take effect.
Page 22
