Installation and Operation
Manual
REVOLABS SOLO
Wireless Microphone System
Models 02-DSKSYS, 04-DSKSYSEU
Please Note:
Microphones must be fully
charged and paired to the
.
Charger Base prior to first use
DESKTOP
™
Revolabs, Inc.
Revolabs, Inc.
Revolabs, Inc.
Revolabs, Inc.
© 2007 REVOLABS, INC. All rights reserved. No part
of this document may be reproduced in any form or by
any means without express written permission from
Revolabs, Inc. Product specifications are subject to
change without notice.
R e v o l a b s S o l o ™ D e s k t o p M a n u a l 0 2 - D S K M A N - P A P - 1 1
M f g P a r t # 9 1 - 8 6 0 1 - 1 0 N 0 0 M a y 2 0 0 7 ( R e v 2 . 3 )
