Revolabs Fusion User Manual

Wireless microphone system
Hide thumbs Also See for Fusion:

Advertisement

Quick Links

See also: Setup Manual
Revolabs Fusion™ Wireless
Microphone System
User's Guide
Rev 1.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Fusion and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Revolabs Fusion

Summary of Contents for Revolabs Fusion

  • Page 1 Revolabs Fusion™ Wireless Microphone System User’s Guide Rev 1.1...

  • Page 2: Table Of Contents

    Table of Contents Using the Fusion IR Remote Control Using the Fusion Charger Base Using the Revolabs Solo™ Microphones Wearable Microphone Tabletop Microphone XLR Adapter for Dynamic Microphone Indicator Lights Page 2...
  • Page 3 Lifesize, Polycom, Sony, and Tandberg. It includes a remote control . Decide on where you want to put the Fusion system, whether you want to place it vertically or horizontally, plug in the cables and you are ready to have great wireless audio in any conference room.

  • Page 4: Using The Fusion Ir Remote Control

    User’s Guide Using the Fusion™ IR Remote Control Phone Dial Pad Vol +: increases volume Call: dial-tone End: hang-up Vol -: decreases volume Flash: phone function Redial: phone function Dial a Call To make a call, push “Call” to get dial tone, then dial the phone number on the Phone Dial Pad.
  • Page 5 Revolabs Fusion™ NOTE: In the default setting, each Solo microphone will mute only itself when its MUTE button on the microphone is pressed. To mute all of the microphones, press the red MUTE button on the Remote Control; all microphones will flash red and no individual microphone can be unmuted until the remote MUTE button is pressed again.

  • Page 6: Using The Fusion Charger Base

    User’s Guide Using the Fusion™ Charger Base When microphones are not in use, they should be properly inserted into the Charger Base. It is important to ensure that the system microphones are inserted fully in the base so that charging will occur.
  • Page 7 The batteries of microphones left in the Charger Base remain solid GREEN. Important: The Lithium Polymer rechargeable batteries that power the microphones are not user serviceable. Please contact Revolabs (www.revolabs.com) or your AV service provider for replacement instructions and to assure the proper disposal method is used.

  • Page 8: Using The Revolabs Solo™ Microphones

    Solo Universal Wireless Adapter for Handheld Microphone Using Revolabs Solo™ Wearable Wireless Microphone The Revolabs Solo™ Wearable Microphones, shown in the following figure, are paired to the Base Station and can be worn on the user’s shirt pocket, lapel or on a lanyard.
  • Page 9 Revolabs Fusion™ Revolabs Solo™ Wearable Microphones turn on and mute automatically when removed from Charger Base, to reduce noise while being attached. The microphone has a clip on the back which allows the microphone to be easily attached onto a shirt pocket, blouse, lapel or lanyard.

  • Page 10: Tabletop Microphone

    4. Audio jack — accepts a 2.5mm plug 5. Charging port — docks to Charger Base 6. Rubber feet — non-slip, vibration absorbing pads To use the Revolabs Solo™ Tabletop Microphone: • Remove the microphone from the Charger Base to turn on and automatically mute the microphone (indicated by a flashing RED LED) during placement on the conference table.
  • Page 11 Revolabs Fusion™ • With the microphone in position, un-mute the microphone by pressing and releasing the Mute button (confirm by viewing flashing GREEN LED). • To turn microphone off, return the microphone unit to the Charger Base or press and hold the Mute button for ~10 seconds until the LED turns solid RED and release button.

  • Page 12: Xlr Adapter For Dynamic Microphone

    User’s Guide Using the Solo XLR Microphone Wireless Adapter The Revolabs Solo™ Universal Wireless Adapter for Handheld Microphones, shown in the following figure, is connected to your existing handheld dynamic microphones for wireless freedom during open microphone meetings, Q&A sessions, classrooms, etc.
  • Page 13 Revolabs Fusion™ To turn the Adapter off, return the microphone unit to the Charger Base or press and hold the Mute button for ~10 seconds until the LED turns solid RED and release button. Important: Always remove the microphone from the Adapter by pressing the latch switch and separating the parts before returning the Adapter to the Charger Base.

  • Page 14: Indicator Lights

    User’s Guide Indicator Lights Equipment Use Microphone LED Base Station Meaning LEDs Microphone in Solid RED Charging in Progress Charger Base Solid GREEN* Charging Complete Microphone not in Microphone powered OFF Charger Base or battery discharged One RED flash RED Flashing Microphone master muted every 1.5 seconds by remote control or...
  • Page 15 Fusion Base Station prior to first use. © 2008 REVOLABS, INC. All rights reserved. No part of this document may be reproduced in any form or by any means without express written permission from Revolabs, Inc. Product specifications are...
