Revolabs Fusion™
STEP 1: Fusion Set-Up
Hardware
Decide if want to place Fusion Base Station horizontally or vertically on a flat surface. To set-
up vertically, place the Fusion Base Station vertical stand on the bottom of the Fusion unit.
Tighten bolt into Fusion Base Station.
Fusion Base Station Placement
WARNING: Do not put Fusion Base Station behind metal doors.
If you are putting the Fusion Base Station into a cabinet with non-metal doors, you need to use
the Remote IR Sensor (part number 07-IRREMO-01) for remote to work. (Refer to page 22)
Power
Plug AC power adapter power cord into the back of the Fusion Base Station and into wall
outlet.
Plug AC wall adapter into the power outlet and the other end into the microphone Charger
Base.
Place wireless microphones in the Charger Base, let charge overnight or at least eight hours.
Indicator lights on the Base Station Charger Base and microphones should be lit, verifying all
units are operating.
NOTE: Wait (approximately 30 seconds) until the Fusion Base Station has powered up and
the status lights have stopped flashing, before continuing on with next steps,
Page 7
