Set-Up Guide
STEP 3 Continued: Pairing Microphones to Fusion Base
Station if Necessary
Place the microphone unit into pairing mode by holding the MUTE button down for seven seconds. The LED will
turn solid RED. Release the MUTE button. The microphone is now in pairing mode.
Within one minute, push and hold the button for the desired channel on the Base Station (refer to page 5) for seven
seconds to enter into pairing mode then release. The LED for that channel will be solid red until pairing starts, as
indicated by a quick GREEN flash, then switching to flashing RED on both the microphone and the Base Station
(muted audio). Pairing is now complete.
The Fusion Base Station has four or eight indicator LED lights (one for each microphone) and pairing push buttons
on the front panel. When the LED is flashing GREEN or RED, that channel is active and connected to a wireless
microphone (GREEN is for live audio, RED is for muted). When the LED is OFF, the channel is inactive (the
microphone is out of range or turned off).
