Set-Up Guide
Programming Port: DIP Switches
The Fusion Base Station factory default settings are all OFF. The left Programming Port (#8, page 6) is end-user
configurable. Programming Port (#9, page 6) on the right is reserved for Revolabs Use Only.
NOTE: The Fusion system must be powered off and back on for any DIP Switch changes to take effect.
OFF
ON
7 8
1 2 3 4 5 6
Transmit Power Medium
Transmit Power Low
Frequency A Mode
Frequency B Mode
Tabletop Master Mute
Phone Auto Answer
IR Remote
Hearing Assistance
Page 18
