Multiple Fusion Systems

There are two settings that must be adjusted when more than one Fusion system is used within a 100' (30.5 m)
range: frequency and transmit power level. These settings will enable several Fusion systems to be used near
each other, but not interfere with each other. Interference between systems can cause occasional audio noise
and signal dropouts on affected systems. Building conditions may influence this distance.
NOTE: Even using the settings below, the 8-Microphone Fusion System requires 40 feet (12.2 m)
between systems.
Setting the Transmit Power Level for Multiple Fusion Systems
In confined settings where multiple Fusion systems are used, or where audio interference is likely, it may be
necessary to reduce the transmit power levels. The transmit power level between the microphones and Fusion
Base Station can be set to the following three levels:
•
Highest power level (default) – 100 feet (30.5 m) maximum operating distance between Microphone and
Fusion Base Station DIP Switches #1 and #2 are OFF (page 18).
•
Medium power level – 30 feet (9 m) maximum operating distance between Microphone and Fusion Base
Station . DIP Switch #1 is ON and DIP Switch #2 is OFF (page 18).
•
Lowest power level – 8 feet (2.4 m) maximum operating distance between Microphone and Fusion Base
Station . DIP Switch #2 is ON and DIP Switch #1 is OFF (page 18).
Frequency Settings
Frequency should be alternated to different frequency ranges, A and B. So an example of five conference rooms
in a row would be configured:
1 2
Conference
Room
Frequency A B
To configure the Fusion to frequency mode A, Dip Switch #3 is ON and DIP Switch #4 is OFF. Frequency
mode B - Dip Switch #4 is ON and DIP Switch #3 is OFF. (page 18).
NOTE: The Fusion system must be powered off and back on for any DIP Switch changes to take
effect.
3 4 5
A B A
