Revolabs Fusion™ Microphone System - Sony XG-80 Setup Guide

OTES A ND

A UTIONS

This setup guide will guide you through the steps needed to properly connect a

Revolabs Fusion System to a Sony XG-80 video codec.

1. Connecting the Cables

2. Configuring the XG-80 Video Codec

It is important to carefully follow these instructions in order and completely .

Note:

Otherwise your Fusion Microphone System and/or the video codec may not function

properly. Please read through these instructions completely before proceeding.

Contact Revolabs technical support if you have any questions.

Requirements for connecting systems:

1. Revolabs Fusion 4 or 8 channel microphone system

2. Sony XG-80 video codec

3. QTY 1 Female XLR – 1/8" stereo male cable (i.e. Calrad 10-145)

4. QTY 1 RCA-RCA male cable

5. Amplified speakers

Table of Contents

Need help?

Do you have a question about the Fusion and is the answer not in the manual?

Page 1 It is important to carefully follow these instructions in order and completely . Note: Otherwise your Fusion Microphone System and/or the video codec may not function properly. Please read through these instructions completely before proceeding. Contact Revolabs technical support if you have any questions.
Page 2 2. Connect a Male RCA-RCA audio cable between the “CONF IN” port on the Fusion and the L “AUDIO OUT” port on the XG-80. 3. Connect a Male RCA audio cable between the “Room Out” port on the Fusion and the Speakers.
Page 3 7. Verify INPUT as MONAURAL 8. Increase Sony volume level on remote to maximum NOTE: You must use your Fusion remote control to control the room volume for both the audio and video conference calls. Adjusting the volume in the...
