Table 5-1 Cables
Cable Number Connects
17-04713-02 Cabinet Control Logic (CCL) panel to TLSB card cage.
17-04941-01 DC distribution module to TLSB card cage (48 V).
17-04942-01 J9, J10 of DC distribution module and CD-ROM
tray to blowers.
17-04943-01 J17 of DC distribution module to OCP module.
17-04800-02 CCL panel to J6 of DC distribution module.
17-03961-10 CCL panel to J14 of DC distribution module.
17-03961-10 CCL panel to J15 of DC distribution module.
17-03961-10 CCL panel to J16 of DC distribution module.
17-04945-01 CCL panel and J6 of DC distribution module to
DWLPBs (48 V)
17-04670-02 CD tray to KFE72-KA PCI module.
17-03566-15 CD tray to KFE72-KA and KZPBZ-CX
17-03511-05 CCL panel to optional expander cabinet.
17-04950-01 CD tray internal cabling.
17-04100-01 CD tray internal cabling (optional floppy drive).
17-04101-01 CD tray internal cabling (optional floppy drive).
17-03531-02 CD tray internal cabling (CD-ROM drive).
17-04952-01 CD tray internal cabling (CD-ROM drive).
17-03530-01 CD tray internal cabling.
Removal and Replacement Procedures 5-43
