5.1.2

How to Replace the Boot Processor

Check the console firmware version in the existing and replacement
modules and, if they differ, use the LFU update command to bring the
replacement module to the current version.
EEPROM on the replacement module.
Example 5–2 Replacing the Boot Processor
F E D C B A
+ +
. . . . . .
. . . . . .
. . . . . .
Compaq AlphaServer GS60E 2-6/700/8, Console V5.5-25
SROM V2.3, OpenVMS PALcode V1.68-101, Tru64 UNIX PALcode V1.61-101
System Serial = NI84177052, OS = OpenVMS,
P00>>> boot dkd400
Building FRU table............
(boot dkd400.4.0.5.0 -flags 0,a0)
[LFU boots]
UPD> update kn7cg-ab0
WARNING: updates may take several minutes to complete for each device.
Confirm update on: kn7cg-ab0
5-4 Service Manual
9 8 7 6 5 4
A M M M .
o + + + .
. . . . .
o + + + .
. . . . .
o + + + .
. . . . .
+ + + + + .
. . . . .
. . . . . .
. . . . . .
. . . . . .
B0 A1 A0
. 4GB 4GB 4GB
3:11:57
š
š
[Y/(N)] y
DO NOT ABORT!
Build the replacement
3 2 1 0 NODE #
. P P P TYP
. ++ ++ ++ ST1
. EE EE EB BPD
. ++ ++ ++ ST2
. EE EE EB BPD
. ++ ++ ++ ST3
. EE EE EB BPD
. . . + C0 PCI +
. . . EISA +
. . . . C1
. . . . C2
. . . . C3
. . . . . ILV
. . . . . 12GB
—
26-OCT-1999 12:06:03
➄
December 7, 1999
