1.7

I/O Bus and In-Cab Storage Devices

Both the AlphaServer GS60E main cabinet and expander cabinets are
designed to hold PCI shelves and StorageWorks I/O shelves.
Figure 1–8 I/O Bus and In-Cab Storage
(Front View)
1-14 Service Manual
7-Slot System Bus
Up to 4 CPU Modules
(8 CPUs)
Up to 5 Memory Modules
(12 GB)
Up to 3 I/O Modules
Blowers
DWLPB PCI
CD Drive
(and optional
floppy drive)
StorageWorks
Shelf
Power Supplies
CCL Panel
AC Input Box
(Rear View)
SM18-99
