Compaq AlphaServer GS60E Service Manual page 33

Six status indicator LEDs (see Figure 2-1) show the state of the system. Table
2-1 describes the conditions indicated by the lights.
NOTE: With the keyswitch in the On position, if all six LEDs are blinking, one
or more of the power supplies has failed or there is a missing power
supply. With the keyswitch in the Off position, the LEDs will also blink
but do not provide power supply status.
Table 2–2 Operator Control Panel LEDs at Power-Up
Keyswitch
On; On/Off
Action Button On
Off
Set circuit
breaker to On
Turn On
keyswitch to
On and press
On button
System self- On
test starts
Module On
passes self-
test
Module fails On
self-test
Power supply On
problem
On
Operating
system boots
Run Power Fault
Blink Blink Blink
Off On Blink
Off On On
Off On Off
Off On On
Blink Blink Blink
On On Off
Troubleshooting with LEDs
On Secure Reset
Blink Blink Blink
On Off Off
On Off Off
On Off Off
On Off Off
Blink Blink Blink
On Off Off
2-3
