Troubleshooting the Power Subsystem
The GS60E power supplies accept three-phase AC and produce 48 VDC
power.
Each power supply has two LEDs that indicate normal
conditions and faults.
Figure 2–7 Power Subsystem
VAUX LED (top)
Front
Rear
Power
Supplies
48V LED (bottom)
Main Circuit Breaker
AC Power Line Cord
SM27-99
2-12
Service Manual
