1.2

TLSB System Bus

The TLSB card cage is a 7-slot card cage that contains slots for up to
four CPU modules, up to five memory array modules, and up to three
I/O modules. The TLSB bus interconnects the CPU, memory, and I/O
modules.
Figure 1–2 TLSB Card Cage
First Memory or
Additional I/O or CPU Module
Additional
Memory, I/O or
CPU Modules
Rear
4 5 6 7 8
Centerplane
Power Filter
3 2
Front
Additional
CPUs
or Memories
1-4 Service Manual
1 0
OM24-99
