User Guide • SC2-PRESTO • CompactPCI
Mezzanine Side Board Options
The SC2-PRESTO is provided with several stacking connectors for attachment of a mezzanine
expansion module (aka side board), suitable for a variety of readily available mezzanine cards (please
refer to www.ekf.com/c/ccpu/mezz_ovw.pdf for a more comprehensive overview). EKF furthermore
offers custom specific development of side boads (please contact sales@ekf.de).
2 x
USB
3.0
DP
1
VGA
DP
2
Dual
GbE
Most mezzanine expansion modules require an assembly height of 8HP in total, together with the
CPU carrier board (resulting from two cards at 4HP pitch each).
In addition, cropped low profile mass storage mezzanine modules can be attached to P-HSE, which
maintain the 4HP envelope, for extremely compact systems. Furthermore these small size modules
may be combined with the full-size expansion boards (that means an assembly comprised of 3 PCBs).
C4* Series Mezzanine Storage Modules
SCS-TRUMPET Mezzanine Side Card
© EKF
3 x SATA 6G
(PCH)
4 x USB
HSE
J-GP
J-RTC
P-HSE
P-USB
P-DP1
P-VGA
Top Side
P-DP2
Connector Assembly
Front Panel - Mezzanine - Backplane
J-MFG
P-ETH
P-FPH
SC2-PRESTO
Related Documents Mezzanine Modules and Side Cards
www.ekf.com/c/ccpu/c4x_mezz_ovw.pdf
www.ekf.com/s/csc/scs.html
®
Serial CPU Board • Intel® Core
LPC USB
SMBus
HD Audio
EXP
P-EXP
SC2-PRESTO
4th Generation
Intel® Core™ i7 CPU
©
EKF
Video
Flat-
DP 3
Panel
DP3
P-DP3
•
CompactPCI
®
Serial
• ©
-31-
TM
4xxx Processor
PCI Express®
Gen2
1 x 4 • 4 x 1
PCIE
GbE
P-PCIE
(1-2)
Clk PE (1-8)
2 x PE (7-8)
Gen2
2 Links x 1
4 x PE (3-6)
Gen2
4 Links x 1
3 x SATA (PCH)
•
ekf.com
4 x SATA (RAID)
1 x USB3 (2)
2 x USB2 (5-6)
PE Gen3 x 8 (2)
PE Gen3 ½ x 8 (1)
2 x USB2 (3-4)
PE Gen3 ½ x 8 (1)
1 x USB3 (1)
Sideband
Power
EKF
•
ekf.com
P6
P5
P4
P3
P2
P1
ekf.com
