User Guide • SC2-PRESTO • CompactPCI
®
CompactPCI Serial

System Slot Controller

®
The PICMG CompactPCI
speed data-links PCI Express
®
CompactPCI Serial system slot controller, provides the resources of these interfaces. The backplane
distributes them in the form of point to point connections to the peripheral slots.
The SC2-PRESTO allocates most but not all communication channels defined by CompactPCI
on the backplane:
Two PCIe Links x8, 2.5GT/s, 5GT/s or 8GT/s (Fat Pipes)
<
Six PCIe Links x1, 2.5GT/s or 5GT/s
<
< Seven SATA Ports (6 x 6G, 1 x 3G)
Two USB 3.0 Ports
<
Six USB 2.0 Ports
<
Two Gigabit Ethernet Ports
<
These resources will be distributed on a typical 9-slot CompactPCI
© EKF
®
®
Serial specification defines a card slot system based on the modern high
®
, SATA, Ethernet and USB. The SC2-PRESTO, designed to act as a
Serial CPU Board • Intel® Core
®
Serial backplane as follows:
-37-
TM
4xxx Processor
®
Serial
ekf.com
