EKF PC7-FESTIVAL User Manual

Compactpci plusio cpu card

page of 108

/ 108
Contents
Table of Contents
Bookmarks

Table of Contents

Quick Links

Download this manual

User Guide

PC7-FESTIVAL • CompactPCI® PlusIO CPU Card

Intel® XEON® E3 v6 Family Mobile Workstation Processor

Table of Contents

Need help?

Do you have a question about the PC7-FESTIVAL and is the answer not in the manual?

Questions and answers

Summary of Contents for EKF PC7-FESTIVAL

Page 1 User Guide PC7-FESTIVAL • CompactPCI® PlusIO CPU Card Intel® XEON® E3 v6 Family Mobile Workstation Processor...
Page 2: Table Of Contents
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Contents About this Manual............... . 5 Edition History .
Page 3 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board GP (General Purpose) LED ..........46 HD (Hard Disk Activity) LED .
Page 4 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board P-EXP............. . . 95 P-GBE .
Page 5: About This Manual
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board About this Manual This manual describes the technical aspects of the PC7-FESTIVAL, required for installation and system integration. It is intended for the experienced user only. Edition History Contents/Changes Author Date...
Page 6: Related Documents
This manual has been edited as carefully as possible. We apologize for any potential mistake. Information provided herein is designated exclusively to the proficient user (system integrator, engineer). EKF can accept no responsibility for any damage caused by the use of this manual. © EKF - 6 - ekf.com...
Page 7: Standards
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Standards Reference Documents Term Document Origin PlusIO CompactPCI PlusIO Specification, PICMG® 2.30 www.picmg.org DisplayPort VESA DisplayPort Standard Version 1.2, www.vesa.org DisplayPort Alt Mode on USB Type-C Ethernet IEEE Std 802.3 standards.ieee.org...
Page 8: Overview
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Overview The PC7-FESTIVAL is a rich featured high On-board mass-storage solutions are based performance 4HP/3U CompactPCI® PlusIO CPU on low profile mezzanine expansion cards, board, equipped with an Intel® Xeon® E3 which can accommodate up to two M.2 style...
Page 9: Technical Features
SAC (Stand-Alone Computer) option w. two-pos. 5V/10A terminal block (J1/J2 removed) +12V is required additionally for PC7-FESTIVAL mezzanine assemblies with e.g. S20, S40, SCL ** * option different SKUs available with 25W processors also for +5V/3.3V backplane supply - specify when ordering on request: PC7-FESTIVAL +5V only can deliver +3.3V to backplane for CompactPCI®...
Page 10 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Feature Summary Processor Intel® Kaby Lake-H mobile platform with ECC (CM238 mobile workstation PCH) Intel® Xeon® processor E3 v6 family (mobile workstation) Xeon E3 1505L v6 P 2.2/3GHz P 8M P 4C/8T P DDR4 2400 ECC P 25W P GT2 - P630 P vPRO™/AMT Xeon E3 1505M v6 P 3/4GHz P 8M P 4C/8T P DDR4 2400 ECC P 45/35W P GT2 - P630 P vPRO™/AMT...
Page 11 P82-GBE - 2 x 2.5GBASE-T for J2 backplane connector, 1 x M.2 2280 NVMe® SSD socket 8HP/12HP Mezzanine side card options: P01-M12 - Replacement for PC7-FESTIVAL RJ45 GbE jacks by M12-X receptacles PCU-UPTEMPO - Side board w. 2 x M.2 SATA SSD sockets & front I/O PCZ-NVM - Side board w.
Page 12 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Feature Summary Networking Two networking interface controllers (NIC), 1000BASE-T, 100BASE-TX, 10BASE-T connections Port 1 equipped w. I219LM PHY (suitable for Intel® AMT) Port 2 equipped w. Intel® I210-IT -40°C to +85°C operating temperature GbE controller IPv4/IPv6 checksum offload, 9.5KB Jumbo Frame support, EEE Energy Efficient Ethernet...
Page 13 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Feature Summary Front I/O (4HP) 2 x Gigabit Ethernet RJ45 (1 = PCH & I219LM - iAMT, 2 = I210IT) 2 x DisplayPort (from processor integrated HD graphics engine, standard DP latching receptacles) 2 x USB 3.0...
Page 14 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Feature Summary Environmental & Regulatory Suitable e.g. for industrial, transportation & instrumentation applications Designed & manufactured in Germany ISO 9001 certified quality management Long term availability Rugged solution Coating, sealing, underfilling on request...
Page 15: Compactpci® Plusio
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board CompactPCI® PlusIO CompactPCI® PlusIO (PICMG® 2.30) is an CompactPCI® Serial (PICMG® CPCIS.0) defines enhancement to CompactPCI® Classic which a card slot based on PCI Express®, SATA, enables system expansion and rear I/O across Gigabit Ethernet and USB serial data lines.
Page 16 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Sample CompactPCI® PlusIO Rack SRP-BLUBOXX © EKF - 16 - ekf.com...
Page 17 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Sample Hybrid Backplane Sample Hybrid Backplane © EKF - 17 - ekf.com...
Page 18: Power Requirements
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Power Requirements Power Requirements Load Current [A] at +5.0 V * Maximum Performance Windows 10 Idle LFM / HFM / Turbo LFM / HFM / Turbo Board PC7-44XX 1.9 / 2.4 / 2.8 0.7 / 0.7 / 0.7...
Page 20: Backplane Resources
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Backplane Resources © EKF - 20 - ekf.com...
Page 23 7 slots for CompactPCI® Classic peripheral cards. If the PC7-FESTIVAL CPU card is equipped with a side card (8HP or even 12HP front panel), the adjacent CompactPCI® Serial backplane card slots should be positioned at the same clearance, to prevent loss of usable slots.
Page 24: Backplane Ethernet
(32-bit). On the right side CompactPCI® Serial peripheral cards can be plugged. When backplane Ethernet is required, the low profile mezzanine module P82-GBE can be assembled together with the PC7-FESTIVAL. Then, neighbouring to the CPU card slot, two CompactPCI® Serial slots would be Gigabit Ethernet enabled, via their J6 backplane connectors.
Page 25: Rear I/O
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Rear I/O The I/O resources provided by the PC7-FESTIVAL backplane connector J2 can also be used for an rear I/O module. EKF can offer custom specific RIO design - please contact sales@ekf.de.
Page 26: Top View Component Assembly
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Top View Component Assembly © EKF - 26 - ekf.com...
Page 27: Bottom View Component Assembly
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Bottom View Component Assembly © EKF - 27 - ekf.com...
Page 28: Front Panel Connectors
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Front Panel Connectors ETH 1/2 Dual Gigabit Ethernet RJ-45 receptacles with integrated indicator LEDs DP 1/2 DisplayPort digital video output receptacles USB 1/2 Universal Serial Bus 3.0 type A receptacles (USB 3.1 Gen1 SuperSpeed 5Gbps) ©...
Page 29: Front Panel Switches & Indicators
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Front Panel Switches & Indicators Front Panel Handle with integrated switch (programmable function, power event button by default) General Purpose bicolour LED Bicoloured LED indicating any activity on SATA ports LED indicating CPU over-temperature...
Page 30: On-Board Connectors & Sockets
P-ISP PLD glue logic device programming connector, not populated Jumpers J-GP Jumper to reset UEFI/BIOS Setup to EKF Factory Defaults, IEEE 1588 Pulse per Second Output J-MFG Jumper to enter Manufacturing Mode, not populated J-RTC Jumper to reset RTC circuitry (part of PCH), not populated ©...
Page 31: Microprocessor
The processors supported by the PC7-FESTIVAL are SKUs with a thermal design power (TDP) of 25- 45W. Due to the cTDP feature (configurable TDP) the power consumption of the 45W parts may be lowered by UEFI setup to fit the customers requirements (see table below).
Page 32: Thermal Considerations
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Thermal Considerations In order to avoid malfunctioning of the PC7-FESTIVAL, take care of appropriate cooling of the processor and system, e.g. by a cooling fan suitable to the maximum power consumption of the CPU chip actually in use.
Page 33: Main Memory
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Main Memory The PC7-FESTIVAL features two channels of DDR4 SDRAMs with support of ECC (Error Correction Code). One channel is realized with 18 memory devices soldered to the board (Memory Down) and delivers a capacity of up to 16GB with a clock frequency of 2400MHz (PC4-2400).
Page 34: Graphics Subsystem
(DDC channel, hot plug detection) are located within the PCH CM238. The PC7-FESTIVAL offers two DisplayPort interfaces with latching receptacle in the front panel. The latching feature prevents DisplayPort cables from detaching in vibrating or harsh environments.
Page 35: Lan Subsystem
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board LAN Subsystem The Ethernet LAN subsystem is composed of two Gigabit Ethernet ports: One Intel i219LM Physical Layer Transceiver (PHY) using the PCH CM238 internal MAC and one Intel i210IT Gigabit Ethernet Controller.
Page 36: Serial Ata Interface (Sata)
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Serial ATA Interface (SATA) The PC7-FESTIVAL provides a total of up to ten serial ATA (SATA) ports, derived from up to three independent SATA controllers. All of these ports support data transfer rates of 6Gbps (600MB/s), 3Gbps (300MB/s) or 1.5Gbps (150MB/s).
Page 37: Pci Express® Interface
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board PCI Express® Interface The PC7-FESTIVAL is provided with several PCI Express (PCIe) lanes for I/O expansion. The CM238 offers a total of up to sixteen PCI Express ports supporting PCIe Gen 3 speed (8GT/s).
Page 38: Universal Serial Bus (Usb)
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Universal Serial Bus (USB) The PC7-FESTIVAL is provided with fourteen USB ports. All of them are USB 2.0 capable, but six ports are also supporting the USB 3.0 SuperSpeed standard. Two USB 3.0 interfaces are routed to front panel connectors and one is connected to P-HSE1 interface.
Page 39: Utility Interfaces
The HD Audio port requires an additional audio codec, as provided e.g. on the SCS-TRUMPET side card. The LPC bus presents an easy way to add legacy interfaces to the system. EKF offers a variety of mezzanine expansion boards (side cards), to be attached on top of the PC7-FESTIVAL, featuring all classic Super-I/O functionality, for example the SCS-TRUMPET or PCS-BALLET.
Page 40: Real-Time Clock
In applications were the use of a battery is not permitted, a SuperCap can be soldered instead of the battery. It is also possible to use the PC7-FESTIVAL without any battery or SuperCap. In this case the Real- Time Clock can’t keep its time and date. Per default an error message is reported by the UEFI/BIOS...
Page 41: Spi Flash
If the programming procedure fails e.g. caused by a power interruption, the PC7-FESTIVAL may no more be operable. In this case you would possibly have to send in the board, because the Flash device is directly soldered to the PCB and cannot be changed by the user.
Page 42: Reset
The healthy state of the PC7-FESTIVAL is indicated by the LED PG (Power Good) located in the front panel. This bicoloured LED signals different states of the board (see section below). As soon as this LED begins to lite green, all power voltages are within their specifications and the reset signal has been deasserted.
Page 43 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board https://www.ekf.com/c/ccpu/img/reset_400.gif © EKF - 43 - ekf.com...
Page 44: Watchdog
An important reliability feature is a software programmable watchdog function. The PC7-FESTIVAL contains two of these watchdogs. One is part of the CM238 PCH and also known as TCO Watchdog. A detailed description is given in the CM238 data sheet. Operating systems like Linux offer a driver interface to the TCO watchdog.
Page 45: Front Panel Leds
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Front Panel LEDs The PC7-FESTIVAL is equipped with four LEDs which can be observed from the front panel. Three of these LEDs are labelled according to their primary meaning, but should be interpreted...
Page 46: Pg (Power Good) Led
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board PG (Power Good) LED The PC7-FESTIVAL offers a bicolour LED labelled PG located within the front panel. After system reset, this LED defaults to signal different power states: Sleep state S3, S4 or S5...
Page 47: Hd (Hard Disk Activity) Led
On the PC7-FESTIVAL DEG# is pulled to VCC and FAL# is routed to GPP_D0 of the CM238 PCH. As an option a circuit can be stuffed on PC7-FESTIVAL to use this signal as an output to drive PSON# of a power supply. With this option and the related external wiring it is possible to switch off the mainpower supply when the system powers down to state S4.
Page 48: Mezzanine Side Board Options
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Mezzanine Side Board Options The PC7-FESTIVAL is provided with several stacking connectors for attachment of a mezzanine expansion module (aka side board), suitable for a variety of readily available mezzanine cards (for a more comprehensive overview, please refer to www.ekf.com/s/mezzanine_connectors.pdf).
Page 49: Low Profile Nvme® Mezzanine Mass Storage 4Hp
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Low Profile NVME® Mezzanine Mass Storage 4HP S48-SSD • Dual M.2 NVMe SSD Low Profile Mezzanine 4HP Assembly • PC7-FESTIVAL w. S48-SSD © EKF - 49 - ekf.com...
Page 51: Low Profile Sata Mezzanine Mass Storage 4Hp
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Low Profile SATA Mezzanine Mass Storage 4HP C48-M2 • Low Profile Mezzanine Dual M.2 SATA SSD 4HP Assembly • PC7-FESTIVAL w. C48-M2 © EKF - 51 - ekf.com...
Page 53: Side Card Assemblies 8/12Hp
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Side Card Assemblies 8/12HP SCJ-VEENA • Quad 2.5GBASE-T NICs & M.2 NVMe 8HP Assembly • PC7-FESTIVAL w. SCJ-VEENA © EKF - 53 - ekf.com...
Page 54 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board 8HP Assembly • PC7-FESTIVAL w. SCJ-VEENA 8HP Assembly • PC7-FESTIVAL w. SCJ-VEENA © EKF - 54 - ekf.com...
Page 55 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board 8HP Assembly • PC7-FESTIVAL w. PCU-UPTEMPO (Similar Photo) 8HP Assembly • PC7-FESTIVAL w. PCU-UPTEMPO (Similar Photo) © EKF - 55 - ekf.com...
Page 56 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board 8HP Assembly w. PCZ-NVM 8HP Assembly w. PCZ-NVM © EKF - 56 - ekf.com...
Page 57 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board 8HP Assembly w. PCZ-NVM 12HP Assembly w. PCZ-NVM & C32-FIO © EKF - 57 - ekf.com...
Page 58 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Mezzanine Connectors Related Documents www.ekf.com/s/mezzanine_connectors.pdf P-EXP I/F Type Controller LPC (Low Pin Count) HD Audio PCH (I C[0]) 2 x UART (TTL) P-HSE1 I/F Type Controller 4 x PCIe Gen3 or 4 x SATA 6Gbps 2 x USB 2.0, 1 x USB 3.0...
Page 59: Compactpci® Plusio
CompactPCI® and CompactPCI® Serial, with the PC7-FESTIVAL in the middle as controller for both backplane segments. The PC7-FESTIVAL can be used in any system with a CompactPCI® PlusIO backplane according to the PICMG® 2.30 specification. Hybrid backplanes allow the configuration of systems with CompactPCI®...
Page 60: Supplementary Information
Except of PCI Express, hot-plug is enabled on all interfaces by default. For PCI Express the UEFI/BIOS (Build #138 or later) setup of the PC7-FESTIVAL provides settings to switch on or off the hot-plug feature, for Fat Pipe or Standard peripheral slots on different menu places: After Power-On press function key <F2>...
Page 61: Installing And Replacing Components
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Installing and Replacing Components Before You Begin Warning: The procedures in this chapter assume familiarity with the general terminology associated with industrial electronics and with safety practices and regulatory compliance required for using and modifying electronic equipment. Disconnect the system from its power source and from any telecommunication links, networks or modems before performing any of the procedures described in this chapter.
Page 62: Installing The Board
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Installing the Board Warning: This procedure should be done only by qualified technical personnel. Disconnect the system from its power source before doing the procedures described here. Failure to disconnect power, or telecommunication links before you open the system or perform any procedures can result in personal injury or equipment damage.
Page 63: Removing The Board
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Removing the Board Warning: This procedure should be done only by qualified technical personnel. Disconnect the system from its power source before doing the procedures described here. Failure to disconnect power, or telecommunication links before you open the system or perform any procedures can result in personal injury or equipment damage.
Page 64: Emc Recommendations
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board EMC Recommendations In order to comply with the CE regulations for EMC, it is mandatory to observe the following rules: The chassis or rack including other boards in use must comply entirely with CE...
Page 65: Replacement Of The Battery
CMOS RAM. The battery should last during the lifetime of the PC7-FESTIVAL. However, some versions of PC7-FESTIVAL are delivered with a battery holder which makes it possible for the user to replace the coin cell. Use a CR2032 cell as replacement part to ensure an extended temperature range.
Page 66: Technical Reference
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Technical Reference Local PCI Devices The following table shows the on-board PCI devices and their location within the PCI configuration space. Several devices are part of the processor and platform controller hub CM238.
Page 67: Local Smb/I 2 C Devices
Local SMB/I C Devices The PC7-FESTIVAL contains devices that are attached to the System Management Bus (SMBus). These are the SPD EEPROMs for the on-board memory or the possibly plugged SODIMM, a general purpose serial EEPROM containing board configuration data, the supply voltage/temperature controlling device NCT7491, a set of board control and status registers as well as two general purpose, non-volatile electronic jumpers.
Page 68: Hardware Monitor Nct7491
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Hardware Monitor NCT7491 Attached to the SMBus, the PC7-FESTIVAL is provided with the hardware monitor NCT7491. This device is capable to observe the temperatures of the board, processor cores, and on-board memory, as well as several supply voltage rails with a resolution of 10 bit.
Page 69 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Board Control and Status Registers (BCSR) A set of board control and status registers allow to program special features on the PC7-FESTIVAL: Assert a full reset Control activity of front panel reset and power event button...
Page 70: Write/Read Control Register 0
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Write/Read Control Register 0 Write: SMBus Address 0xA0 Default after reset: 0x00 Read: SMBus Address 0xA1 Description CMD_CTRL0 GPLED 0=Green part of the front panel LED GP is off (Default) 1=Green part of the front panel LED GP is on...
Page 71: Read/Clear Status Register 0
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Read/Clear Status Register 0 Write: SMBus Address 0xB0 Read: SMBus Address 0xB1 Description CMD_STAT0 PF18S 0=Normal operation 1=Last system reset may be caused by a power failure of the +V1.8S voltage regulator...
Page 72: Read/Clear Status Register 1
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Read/Clear Status Register 1 Write: SMBus Address 0xB2 Read: SMBus Address 0xB3 Description CMD_STAT1 WDGARMD 0=Normal operation 1=The watchdog is armed and has to be retriggered within its time-out period WDGRST...
Page 73: Read Pld Revision Register
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Read PLD Revision Register Write: Not allowed Read: SMBus Address 0xC1 Description CMD_PLDREV PLDREV Read PLD Revison Number © EKF - 73 - ekf.com...
Page 74: Gpio Usage
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board GPIO Usage GPIO Usage CM238 PCH GPIO Usage CM238 PCH GPIO USAGE Function Description Group A (GPP_A) Native RCIN# Keyboard Reset, to P-EXP Pin 13 A1-A4 Native LPC_AD[0-3] LPC Address/Data Lines...
Page 75 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board GPIO Usage CM238 PCH GPIO USAGE Function Description Group C (GPP_C) Native SMBCLK SMBus Clock Line Native SMBDATA SMBus Data Line GPIO Not used on PC7, pulled to +3.3V Native SML0CLK...
Page 76 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board GPIO Usage CM238 PCH GPIO USAGE Function Description Group D (GPP_D) GPIO CPCI_PS_FAL_ON# Sense CompactPCI PlusIO Power Failure, J2 Pin C15 GPIO PM_MEMTS# Memory Thermal Sensor Event GPIO HM_INT# Hardware Monitor NCT7491 Alert Line...
Page 77 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board GPIO Usage CM238 PCH GPIO USAGE Function Description Group F (GPP_F) Native SATA#PCIE34 Shorted to GPP_E2 F1-F9 GPIO Not connected on PC7 Native SGPIO_CLOCK CompactPCI PlusIO GPIO Bus CLOCK (J2 D14 SATA_SCL)
Page 78 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board GPIO Usage CM238 PCH GPIO USAGE Function Description Deep Sleep Well Group (GDP Native BATLOW# Not used on PC7 (pulled via resistor to +3.3V) Native ACPRESENT Not used on PC7 (pulled via resistor to +3.3V)
Page 79: Configuration Jumpers
The jumper J-GP may be used to reset the UEFI/BIOS configuration settings to a default state. The UEFI/BIOS on PC7-FESTIVAL stores most of its settings in an area within the UEFI/BIOS flash, e.g. the actual boot devices. Using the jumper J-GP is only necessary, if it is not possible to enter the setup of the UEFI/BIOS.
Page 80: Manufacturer Mode Jumper (J-Mfg)
The jumper J-MFG is used to bring the board into the manufacturer mode. This is necessary only on board production time and should not used by customers. For normal operation the jumper should be removed. The pin header J-MFG is not stuffed on the PC7-FESTIVAL by default. J-MFG...
Page 81: Rtc Reset (J-Rtc)
CPU fails to enter the UEFI/BIOS POST after power on. Note: The installing of jumper J-RTC will neither set UEFI/BIOS Setup to EKF Factory Defaults nor resets the time and date register values of the RTC (Real Time Clock). To reset the RTC core the board must be removed from the system rack.
Page 82: Connectors
Front Panel Connectors The basic PC7-FESTIVAL front panel connectors are comprised of each two DisplayPort, USB3 Type-A and RJ45 Ethernet jacks. If low profile mezzanine modules are employed, one or two Type-C receptacles may be available for front I/O in addition. Documentation on the Type-C connectors is not provided in this manual - please refer to the particular mezzanine module in use.
Page 83: Displayport Connectors
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board DisplayPort Connectors The Intel graphics processing unit (GPU) on the PC7-FESTIVAL processor carrier card incorporates up to three external DisplayPort video channels. Two video outputs are available via the CPU card front panel (standard DisplayPort receptacles, reverse mount).
Page 84: Usb Connectors
USB Connectors The Intel® CM238 Platform Controller Hub incorporates a four-port USB 3.0 xHCI host controller. Two ports are directly available on the PC7-FESTIVAL front panel (type A receptacle), for attachment of external USB devices. P-USB • Dual USB 3.0 Receptacle USB 3.0 dual type A receptacle, stacked, 18-position...
Page 85: Ethernet Connectors
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Ethernet Connectors Gigabit Ethernet Ports 1/2 (P-ETH, RJ-45) NC1_MDX0+ NC1_MDX0- NC1_MDX1+ NC1_MDX2+ Port 1 NC1_MDX2- NC1_MDX1- NC1_MDX3+ NC1_MDX3- NC2_MDX0+ NC2_MDX0- NC2_MDX1+ NC2_MDX2+ Port 2 NC2_MDX2- NC2_MDX1- NC2_MDX3+ NC2_MDX3- The lower green LED indicates LINK established when continuously on, and data transfer (activity) when blinking.
Page 86: Option M12 X-Coded Ethernet Receptacles
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Option M12 X-Coded Ethernet Receptacles As an ordering option, the PC7-FESTIVAL RJ45 jacks can be replaced by M12 X-coded receptacles. A small mezzanine module (P01-M12) is soldered to the RJ45 footprint, resulting in an 8HP front panel assembly.
Page 87 MDX3- brown MDX2- white/blue MDX2+ blue Suitable industrial Gigabit Ethernet M12 cable assemblies can be ordered from EKF, or directly from well-known cable and connector manufacturers e.g. Metz, Phoenix, Escha and many others. Ordering Information Cable Assemblies Gigabit Ethernet cable M12 to M12: #271.14.008.xx (xx=length/meter) Gigabit Ethernet cable M12 to RJ-45: #271.15.008.xx (xx=length/meter)
Page 89 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board The P01-M12 connector option can be combined with low profile mezzanine modules, e.g. S48-SSD or P82-GBE. © EKF - 89 - ekf.com...
Page 91: Mezzanine Connectors
CPU board. From PCB Rev.3 off, there is an optional GBE mezzanine connector for use with the P82-GBE low profile module. EKF offers low profile mezzanine modules which fit into the 4HP envelope of the CPU carrier card, with varying B2B clearance from 9.5mm to 10.8mm, and also side cards for additional 4HP mounting pitch (8HP in total assembly, 18.7mm B2B).
Page 92 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Board to Side Card Type-C Ethernet Series Board HSE1 HSE2 Option 8HP Profile Front I/O Backplane Space (HSE2) S1 - S5 9.5mm SATA x4 3) D1 - D4 PCIe x4, S1 - S5 10.0mm...
Page 93: P-Hse1
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board P-HSE1 High Speed Expansion P-HSE1 CFG_12 CFG_34 1_SATA_PCIE_TXP 3_SATA_PCIE_TXP 1_SATA_PCIE_TXN 3_SATA_PCIE_TXN 1_SATA_PCIE_RXN 3_SATA_PCIE_RXN 1_SATA_PCIE_RXP 3_SATA_PCIE_RXP 2_SATA_PCIE_TXP 4_SATA_PCIE_TXP 2_SATA_PCIE_TXN 4_SATA_PCIE_TXN 2_SATA_PCIE_RXN 4_SATA_PCIE_RXN 2_SATA_PCIE_RXP 4_SATA_PCIE_RXP 1_USB2_P 2_USB3_TXP 1_USB2_N 2_USB3_TXN 2_USB2_P 2_USB3_RXP 2_USB2_N 2_USB3_RXN...
Page 94: P-Hse2
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board P-HSE2 High Speed Expansion P-HSE2 1_PCIE_TXP 3_PCIE_TXP 1_PCIE_TXN 3_PCIE_TXN 1_PCIE_RXN 3_PCIE_RXN 1_PCIE_RXP 3_PCIE_RXP 2_PCIE_TXP 4_PCIE_TXP 2_PCIE_TXN 4_PCIE_TXN 2_PCIE_RXN 4_PCIE_RXN 2_PCIE_RXP 4_PCIE_RXP DP_LANE0_P DP_LANE2_P DP_LANE0_N DP_LANE2_N DP_LANE1_P DP_LANE3_P DP_LANE1_N DP_LANE3_N PCIE_CLK_P DP_AUX_P...
Page 95: P-Exp
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board P-EXP P-EXP • Expansion Board Interface (LPC/HD-Audio/UART) 1.27mm Socket 2 x 20 (276.53.040.01) +3.3VS CLK_24MHZ (CLK_33MHz) PLTRST# LPC_AD0 LPC_AD1 LPC_AD2 LPC_AD3 LPC_FRAME# (LPC_DRQ#) +3.3VS SERIRQ PME# SMI# CLK_14MHZ 2_UART_TXD (FWH_ID0) 2_UART_RXD...
Page 96: P-Gbe
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board P-GBE This optional connector is only used for an assembly of the PC7-FESTIVAL CPU card and the P82-GBE low profile module, for passing two ethernet ports from the mezzanine module to the backplane connector J2 on the CPU carrier card.
Page 97 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board GBE Connector for J2 Rear I/O Dual GbE w. P82-GBE Low Profile Mezzanine Module © EKF - 97 - ekf.com...
Page 98: Pin Headers & Debug
PC7-FESTIVAL front panel handle (ejector lever). The switch performs a power button event (e.g. system shutdown) by short-circuiting the pins 1 and 3 of P-FPH when activated (hold unlock button of front panel handle depressed momentarily).
Page 99: Pld Programming Header P-Isp
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board PLD Programming Header P-ISP The PC7-FESTIVAL is provided with a powerful PLD (in-System Programmable Logic Device) which replaces legacy glue logic. The programming header P-ISP is not stuffed (in use for manufacturing only).
Page 100: Processor Debug Header P-Xdp
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Processor Debug Header P-XDP The PC7-FESTIVAL may be equipped with a 60-position processor debug header for hard- and software debugging (specified by Intel® as XDP-60 Pin Platform Connection). The connector is suitable for installation of a flat cable, in order to attach an JTAG debugger (emulator) such as the Intel®...
Page 101: Backplane Connectors
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Backplane Connectors The backplane connector suite is comprised of two hard metric 2.0mm connectors. While the J1 connector is compliant to CompactPCI® PICMG® 2.0, the J2 connector pin assignment follows an enhancement specification named CompactPCI®...
Page 102: Compactpci J1
Various PCI control signals pulled up with 1kOhm to V(I/O). This value is specified for +5V V(I/O) but works as well with +3.3V V(I/O) under all environments which have been tested by EKF. On request, 2.7kOhm P/U resistors can be stuffed.
Page 103 +12V passed through to mezzanine connectors P-HSE and P-EXP, not required for PC7-FESTIVAL basic operation The 3.3V pins can be sourced by the PC7-FESTIVAL itself, for +5V only power supply designs (consider power 3.3V power requirements of peripheral boards). © EKF - 103 - ekf.com...
Page 104: Compactpci J2 (Plusio)
(PCIe Gen1 2.5GT/s, SATA 1.5Gbps). This does not affect peripherals attached via the P-HSE mezzanine connector. The CompactPCI® PlusIO specification refers to SATA data rates of 1.5Gbps and 3Gbps. EKF has tested successfully also 6Gbps over the backplane with sample devices, but cannot guarantee this data rate under any conditions.
Page 105 REQ1# GNT1# REQ2# signals marked grey/italic are not connected The PC7-FESTIVAL does not provide backplane Ethernet by on-board controllers. As an option, the CPU card can be combined as an assembly with the P82-GBE low profile mezzanine module, which is populated with two I226-IT Ethernet controllers for 2.5GbE (4-speed, 10/100/1G/2.5G).
Page 106 RST# would be available on pin J1 C5. Without J1 however, the RST# output must be derived from J2 C17 as an alternate. Hence, if J1 is not populated on the PC7-FESTIVAL, backplane slots which are based on PCI Express® (typically configured according to CompactPCI® Serial) must be connected to J2/P2 C17 as platform reset.
Page 107: Mechanical Details
User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Mechanical Details © EKF - 107 - ekf.com...
Page 108 User Guide • PC7-FESTIVAL • CompactPCI® PlusIO CPU Board Industrial Computers Made in Germany boards. systems. solutions. Beyond All Limits: EKF High Performance Embedded Document No. 9858 • Edition 4.2 • 18 October 2022 EKF Elektronik GmbH phone +49 (0)2381/6890-0 Philipp-Reis-Str.
