User Guide • SC2-PRESTO • CompactPCI
®
CompactPCI Serial Backplane Connector P2
P2 CompactPCI
P2 A B
8 GND IO 1)
1) 1)
7 IO IO
6 GND 2_PE_TX06+
3) 3)
5 2_PE_TX04+ 2_PE_TX04-
4 GND 2_PE_TX02+
3 2_PE_TX00+ 2_PE_TX00-
3)
2 GND 1_PE_TX06+
1 1_PE_TX04+ 1_PE_TX04-
1)
Not connected.
2)
The PCI Express Lanes 1_PE_* and 2_PE_* are derived from the Core
3) Polarity inversion was made on these lanes on SC2-PRESTO for better routing. This is allowed according the "PCI Express Base Specification 3.0" and has no effect on function or
performance of the link. The pin-out shown is as per specification.
© EKF
®
Serial System Slot Backplane Connector • EKF Part #250.3.1208.20.00 96 pos. 12x8, 16mm Width, Type B
C D E
IO 1) GND 2_USB2+
1) 1)
GND IO IO
2_PE_TX06- GND 2_PE_RX06+
3)
GND 2_PE_RX04+ 2_PE_RX04-
2_PE_TX02- GND 2_PE_RX02+
GND 2_PE_RX00+ 2_PE_RX00-
3)
1_PE_TX06- GND 1_PE_RX06+
GND 1_PE_RX04+ 1_PE_RX04-
TM
processor and capable to transfer 8GT/s.
® Serial CPU Board • Intel® Core
F G
2_USB2- GND 3_USB2+
1)
GND IO
3) 2_PE_RX06- 3) GND 2_PE_TX07+
3) 3)
GND 2_PE_TX05+ 2_PE_TX05-
3) 2_PE_RX02- 3) GND 2_PE_TX03+
GND 2_PE_TX01+ 2_PE_TX01-
1_PE_RX06- GND 1_PE_TX07+
GND 1_PE_TX05+ 1_PE_TX05-
-78-
TM 4xxx Processor
H I J
3_USB2- IO 1)
1) 1)
IO GND IO
2_PE_TX07- GND
3)
GND 2_PE_RX05+
2_PE_TX03- GND
GND 2_PE_RX01+
3) 3)
1_PE_TX07- GND
GND 1_PE_RX05+
K L
4_USB2+ 4_USB2-
1)
IO GND
2_PE_RX07+ 3) 2_PE_RX07- 3)
2_PE_RX05- GND
2_PE_RX03+ 2_PE_RX03-
2_PE_RX01- GND
1_PE_RX07+ 1_PE_RX07-
1_PE_RX05- GND
