Read/Clear Status Register 1

Write: SMBus Address 0xB2
Read: SMBus Address 0xB3
Bit
7 WDGARMD
0=Normal operation
1=The watchdog is armed and has to be retriggered within its time-out period
6 WDGRST
0=Normal operation
1=Last system reset may be caused by a watchdog time-out
5 WDGHT
0=Normal operation
1=The watchdog already has elapsed half of its time-out period
4 PF5PS
0=Normal operation
1=Last system reset may be caused by a power failure of the +V5PS voltage regulator
3 PF5S
0=Normal operation
1=Last system reset may be caused by a power failure of the +V5S voltage regulator
2 PF33M
0=Normal operation
1=Last system reset may be caused by a power failure of the +V3.3M voltage regulator
1 PF33A
0=Normal operation
1=Last system reset may be caused by a power failure of the +V3.3A voltage regulator
0 PF33S
0=Normal operation
1=Last system reset may be caused by a power failure of the +V3.3S voltage regulator
Except of WDGHT and WDGARMD the bits in this register are sticky, i.e. their state will be kept even
if a system reset occurs. To clear the bits a write to the register with arbitrary data may be performed.

Read PLD Revision Register

Write: Not allowed
Read: SMBus Address 0xC1
Bit
7:0 PLDREV
Read PLD Revison Number
