  • Page 1 User Guide ® PC6-TANGO • CompactPCI PlusIO CPU Card ® ™ Intel Atom E3900 Series Processor (Apollo Lake-I SoC) Document No. 8565 • Edition 4 • 8 December 2017 Preliminary...

  • Page 2: Table Of Contents

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Contents About this Manual ............5 Edition History .
  • Page 3 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Hot Swap Detection ........... 40 Power Supply Status (PWR_FAIL#) .
  • Page 4 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) CompactPCI J1 ..........86 CompactPCI J2 (PlusIO) .

  • Page 5: About This Manual

    PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) About this Manual This manual describes the technical aspects of the PC6-TANGO, required for installation and system integration. It is intended for the experienced user only. Edition History Contents/Changes...

  • Page 6: Related Documents

    PCL-CAPELLA Mezzanine Side Card www.ekf.com/p/pcl/pcl.html PCS-BALLET Mezzanine Side Card www.ekf.com/p/pcs/pcs.html PR1-RIO Rear I/O Module www.ekf.com/p/pr1/pr1.html SCS-TRUMPET Mezzanine Side Card www.ekf.com/s/scs/scs.html Ordering Information For popular PC6-TANGO SKUs please refer to www.ekf.com/liste/liste_21.html#PC6 For popular Mezzanine Side Cards please refer to www.ekf.com/liste/liste_20.html#C40 © EKF ekf.com...

  • Page 7: Nomenclature

    This manual has been edited as carefully as possible. We apologize for any potential mistake. Information provided herein is designated exclusively to the proficient user (system integrator, engineer). EKF can accept no responsibility for any damage caused by the use of this manual. © EKF...

  • Page 8: Standards

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Standards Reference Documents Term Document Origin CFast™ CFast™ Specification Rev. 1.0 www.compactflash.org ® CompactPCI CompactPCI Specification, PICMG® 2.0 R3.0, Oct. www.picmg.org 1, 1999 ® CompactPCI CompactPCI PlusIO Specification, PICMG® 2.30 www.picmg.org...

  • Page 9: Overview

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Overview The PC6-TANGO is a low power 4HP/3U Optionally available is an on-board 64GByte ® CompactPCI PlusIO CPU board, equipped with e•MMC flash memory chip. Further more, low ®...
  • Page 10 CompactPCI® Serial card slots. backplane segments. The PC6-TANGO is provided with a set of local The C48-M2 mezzanine module e.g. is expansion interface connectors, which can be equipped with two M.2 SATA Solid State Drives...

  • Page 11: Technical Features

    < +5V only board design for low cost system power supply < < PC6-TANGO can deliver +3.3V to CompactPCI® peripheral boards Processor Intel® Apollo Lake-I (APL-I) SoC E39xx Series < x7-E3950 • 4 Cores • 1.6/2.0GHz • 12W TDP/cTDP • 500/650MHz graphics • 2MB LLC <...

  • Page 12: Main Memory

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Feature Summary Main Memory Integrated memory controller up to 8GB DDR3L 1600 +ECC < Soldered memory for rugged applications < Mass Storage On-board CFast™ Card socket (SATA based CompactFlash) <...
  • Page 13 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Feature Summary APL SoC I/O Usage 4 x PCIe Gen2 to J2 backplane connector - usage for CompactPCI® Serial peripheral cards or rear I/O module < 1 x PCIe Gen2 to PCIe switch PI7C9X2G606PR 1:5 lanes (on-board PCIe devices) <...
  • Page 14 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Feature Summary Front Panel I/O (8HP) Option 2 x M12 X-coded receptacles for Gigabit Ethernet (as replacement for RJ45) < CompactPCI® & CompactPCI® PlusIO Backplane Resources < PICMG® CompactPCI® 2.0 CPU card & system slot controller for J1 based 32-bit CompactPCI® systems Support for up to seven CompactPCI®...
  • Page 15 MTBF tbd years < EC Regulatory EN55022, EN55024, EN60950-1 (UL60950-1/IEC60950-1) < RT OS Board Support Packages & Driver < Please refer to external document www.ekf.com/s/rtos_support.pdf Applications General low power industrial computing, for x86 based software < Rugged systems (e.g. transportation) <...

  • Page 16: Power Requirements

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Power Requirements Power Requirements Load Current [A] at +5V (+0.25V/-0.15V) Board SKU Maximum Performance Windows 10 Idle LFM / HFM / Turbo LFM / HFM / Turbo PC6-tbd...

  • Page 17: Block Diagram

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Block Diagram www.ekf.com/p/pc6/img/pc6_blk.pdf © EKF -17- ekf.com...

  • Page 18: Top View Component Assembly

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Top View Component Assembly © EKF -18- ekf.com...

  • Page 19: Bottom View Component Assembly

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Bottom View Component Assembly © EKF -19- ekf.com...

  • Page 20: Front Panel Connectors

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Front Panel Connectors ETH1/2 Dual Gigabit Ethernet RJ-45 receptacles with integrated indicator LEDs (Option M12-X) DP1/2 DisplayPort digital video output receptacles USB1/2 Universal Serial Bus 3.0 stacked type A receptacles (USB 3.1 Gen1 5Gbps)

  • Page 21: On-Board Connectors & Sockets

    P-SPI SPI Flash device programming connector, not populated Jumpers J-GP Jumper to reset UEFI/BIOS setup to EKF factory defaults, IEEE 1588 Pulse per Second output J-MFG Jumper to enter manufacturing mode, not populated J-RTC Jumper to reset RTC circuitry (part of SoC), not populated ©...

  • Page 22: Microprocessor

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Microprocessor The PC6-TANGO is equipped with an Intel® Atom™ E39xx series processor (code name Apollo Lake-I aka 'APL-I'). This system-on-chip (SoC) provides integrated graphics, an ECC memory controller and high speed I/O, resulting in a low power platform design. As of current, Intel® offers three CPU SKU versions suitable for the PC6-TANGO, differing mainly in the power consumption, caused by differences in the number of processor cores integrated and internal clock speed.

  • Page 23: Thermal Considerations

    This results in a reduction of power consumption and heat dissipation. Do not try to remove the PC6-TANGO heatsink by yourself, since it is bonded to the CPU by a Phase-Change-Material (PCM), in order to improve the heat flow between the APL and the heatsink.

  • Page 24: Main Memory

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Main Memory The PC6-TANGO features a total of 8GB DDR3L SDRAM with support of ECC (Error Correction Code). 8GB is the maximum memory size supported by the APL-I SoC. All 18 memory devices are directly soldered to the board (Memory Down), with a clock frequency of 1600MHz.

  • Page 25: Graphics Subsystem

    Intel® graphics. For industrial applications and optimum reliability however, Intel® recommends to operate the GPU at 400MHz fixed clock. The PC6-TANGO offers two DisplayPort (DP) receptacles in the front panel, for individual use or an extended desktop application. The VESA DDC standard is supported, allowing to read out important display parameters, e.g.

  • Page 26: Lan Subsystem

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) LAN Subsystem The Ethernet LAN subsystem is comprised of up to four Gigabit Ethernet ports. Two Intel® i210IT Gigabit Ethernet controllers are provided to support the front panel RJ45 jacks (backwards compatible to 10Base-T and 100Base-TX).

  • Page 27: Serial Ata Interface (Sata)

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Serial ATA Interface (SATA) The PC6-TANGO provides a total of up to four serial ATA (SATA) 6Gbps ports, suitable for attachment of mass storage devices. Two ports are derived directly from two the APL-I SoC; another two ports are available as an option via an on-board SATA controller.

  • Page 28: Pci Express® Interface

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) PCI Express® Interface The PC6-TANGO is provided with four PCI Express® (PCIe) Gen 2 lanes for rear I/O expansion, derived from the APL-I SoC (PCIe P0-P3), and available via the backplane connector J2. By software strapping, these lanes can be configured as 4 PCIe links x1, or one link x4, for use on a hybrid backplane with CompactPCI®...

  • Page 29: Universal Serial Bus (Usb)

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Universal Serial Bus (USB) The APL-I SoC on the PC6-TANGO is configured to support two USB 3.1 Gen1 Type-A front panel connectors (USB 3.1 was formerly known as USB 3.0 5Gbps SuperSpeed). Both front panel USB receptacles can source a minimum of 1.5A/5V each, over-current protected by electronic switches.

  • Page 30: Utility Interfaces

    The HD Audio port requires an additional audio codec, as provided e.g. on the PCS-BALLET side card. The LPC bus presents an easy way to add legacy interfaces to the system. EKF offers a variety of mezzanine expansion boards (side cards), to be attached on top of the PC6-TANGO, featuring all classic Super-I/O functionality, for example the PCS-BALLET.

  • Page 31: Real-Time Clock

    The PC6-TANGO is provided with a time-of-day clock and 100-year calendar, integrated into the APL-I SoC. A battery on the board supplies the clock circuitry whenever the computer main power is turned off. The PC6-TANGO uses a holder to retain a BR2032 lithium coin cell, giving an autonomy of more than 5 years.

  • Page 32: Spi Flash

    PC6-TANGO UEFI/BIOS binary are available from the EKF website. Read carefully the enclosed instructions. If the programming procedure fails e.g. caused by a power interruption, the PC6-TANGO may no more be operable. In this case you would have to send in the board, because the Flash device is directly soldered to the PCB and cannot be changed by the user.

  • Page 33: Cfast

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) CFast™ The PC6-TANGO is provided with a CFast™ host connector, for user replaceable mass storage. It is suitable for CFast™ 2.0 cards, which have the same dimensions as CompactFlash™ cards, but are operated in SATA mode.

  • Page 34: Reset

    The healthy state of the PC6-TANGO is indicated by the LED PG (Power Good) located in the front panel. This bicoloured LED signals different states of the board (see section below). As soon as this LED begins to lite green, all power voltages are within their specifications and the reset signal has been deasserted.
  • Page 35 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) <4s © EKF -35- ekf.com...

  • Page 36: Watchdog

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Watchdog An important reliability feature is a software programmable watchdog function. The PC6-TANGO contains two of these watchdogs. One is part of the APL-I SoC and also known as TCO Watchdog. A detailed description is given in the Apollo Lake data sheet.

  • Page 37: Front Panel Leds

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Front Panel LEDs The PC6-TANGO is equipped with five LEDs which can be observed from the front panel. Three of these LEDs are labelled according to their primary meaning, but should be interpreted altogether for...

  • Page 38: Gp (General Purpose) Led

    GP (General Purpose) LED This programmable bicolour LED can be observed from the PC6-TANGO front panel. The status of the red part within the LED is controlled by the GPIO16 of the APL-I SoC. Setting GPIO16 to “1" will switch on the red LED.

  • Page 39: Eb (Ethernet Backplane) Led

    GREEN no link link YELLOW link link GREEN/YELLOW Blinking of the LED EB in the appropriate colour means that there is activity on the port. The backplane Ethernet ports are offered as an PC6-TANGO option. © EKF -39- ekf.com...

  • Page 40: Hot Swap Detection

    On the PC6-TANGO DEG# is pulled to VCC and FAL# is routed to APL-I SoC GPIO17. As an option a circuit can be stuffed on PC6-TANGO to use this signal as an output to drive PSON# of a power supply. With this option and the related external wiring it is possible to switch off the main power supply when the system powers down to state S4.

  • Page 41: Mezzanine Side Board Options

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Mezzanine Side Board Options The PC6-TANGO is provided with several stacking connectors for attachment of a mezzanine expansion module (aka side board), suitable for a variety of readily available mezzanine cards (please refer to www.ekf.com/c/ccpu/mezz_ovw.pdf for a more comprehensive overview).
  • Page 42 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Sample Low Profile Mezzanine Module 4HP Assembly Sample Mezzanine Side Card 8HP Assembly © EKF -42- ekf.com...
  • Page 43 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) P-EXP I/F Type Controller LPC (Low Pin Count) APL-I SoC HD Audio APL-I SoC APL-I SoC (I2C Port 0) 2 x USB 2.0 APL-I SoC UART Rx/Tx TTL...

  • Page 44: Compactpci ® Plusio

    CompactPCI® PlusIO (PICMG® 2.30) is a standard for rear I/O across J2. High speed signal lines (PCI Express®, SATA, Gigabit Ethernet and USB) are passed from the PC6-TANGO through the special UHM J2 connector to the backplane, for usage either with a PlusIO rear I/O transition module, or CompactPCI®...
  • Page 45 PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Warning: ® Do not operate the standard PC6-TANGO in systems with a 64-bit CompactPCI backplane. The J2/P2 ® pin assignment of a 64-bit CPCI backplane differs substantially from a CompactPCI...
  • Page 46 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) CompactPCI® PlusIO Rack Small CompactPCI® PlusIO Box © EKF -46- ekf.com...
  • Page 47 PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) ® As an alternate, the PC6-TANGO can be combined with a CompactPCI PlusIO rear I/O transition module, such as the PR1-RIO, which is provided with I/O connectors (on-board and back-panel) for all high speed signals.

  • Page 48: Installing And Replacing Components

    Store the board only in its original ESD protected packaging. Retain the original packaging (antistatic bag and antistatic box) in case of returning the board to EKF for repair. © EKF -48-...

  • Page 49: Installing The Board

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Installing the Board Warning This procedure should be done only by qualified technical personnel. Disconnect the system from its power source before doing the procedures described here. Failure to disconnect power, or telecommunication links before you open the system or perform any procedures can result in personal injury or equipment damage.

  • Page 50: Removing The Board

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Removing the Board Warning This procedure should be done only by qualified technical personnel. Disconnect the system from its power source before doing the procedures described here. Failure to disconnect power, or telecommunication links before you open the system or perform any procedures can result in personal injury or equipment damage.

  • Page 51: Emc Recommendations

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) EMC Recommendations In order to comply with the CE regulations for EMC, it is mandatory to observe the following rules: The chassis or rack including other boards in use must comply entirely with CE...

  • Page 52: Replacement Of The Battery

    CMOS RAM. Most versions of PC6-TANGO are delivered with a battery holder which allows easy replacement of the coin cell. Be sure to use a BR2032 cell as spare part to ensure an extended temperature range. Be careful when removing the old cell and inserting the new one.

  • Page 53: Technical Reference

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Technical Reference Local PCI Devices The following table shows the on-board PCI devices and their location within the PCI configuration space. Most devices are part of the APL-I SoC.

  • Page 54: Local Smb/I 2 C Devices

    Local SMB/I C Devices The PC6-TANGO contains devices that are attached to the APL-I SoC System Management Bus (SMBus). These are the SPD EEPROM for the on-board memory, the PLD (MachXO2) glue logic including a set of board control and status registers, the CPU PMIC, a PCIe clock buffer, a general purpose serial EEPROM and two general purpose, non-volatile electronic jumpers.

  • Page 55: Board Control And Status Registers (Bcsr)

    PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Board Control and Status Registers (BCSR) A set of board control and status registers allow to program special features on the PC6-TANGO: Assert a full reset < Control activity of front panel reset and power event button <...

  • Page 56: Write/Read Control Register 0

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Write/Read Control Register 0 Write: SMBus Address 0xA0 Default after reset: 0x00 Read: SMBus Address 0xA1 Description CMD_CTRL0 GPLED 0=Green part of the front panel LED GP is off (Default)

  • Page 57: Read/Clear Status Register 0

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Read/Clear Status Register 0 Write: SMBus Address 0xB0 Read: SMBus Address 0xB1 Description CMD_STAT0 PF18S 0=Normal operation 1=Last system reset may be caused by a power failure of the +V1.8S voltage regulator...

  • Page 58: Read/Clear Status Register 1

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Read/Clear Status Register 1 Write: SMBus Address 0xB2 Read: SMBus Address 0xB3 Description CMD_STAT1 WDGARMD 0=Normal operation 1=The watchdog is armed and has to be retriggered within its time-out period...

  • Page 59: Read Pld Revision Register

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Read PLD Revision Register Write: Not allowed Read: SMBus Address 0xC1 Description CMD_PLDREV PLDREV Read PLD Revison Number © EKF -59- ekf.com...

  • Page 60: Gpio Usage

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) GPIO Usage GPIO Usage APL-I SoC GPIO Usage APL-I SoC GPIO Type Function Description 0-15 Not connected on PC6 GP_LED_RED General Purpose Red LED Control (via PLD) CPCI_FAL...
  • Page 61 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) GPIO Usage APL-I SoC GPIO Type Function Description ISH 9 SPEAKER Native: Speaker output (to P-EXP Pin 39 via MOSFET) © EKF -61- ekf.com...

  • Page 62: J-Gp Uefi/Bios Defaults & Ieee 1588 Pulse Per Second

    The jumper J-GP may be used to reset the UEFI/BIOS configuration settings to a default state. The UEFI/BIOS on PC6-TANGO stores most of its settings in an area within the UEFI/BIOS flash, e.g. the actual boot devices. Using the jumper J-GP is only necessary, if it is not possible to enter the setup of the UEFI/BIOS.

  • Page 63: Manufacturer Mode Jumper (J-Mfg)

    The jumper J-MFG is used to bring the board into the manufacturer mode. This is necessary only on board production time and should not used by customers. For normal operation the jumper should be removed. The pin header J-MFG is not stuffed on the PC6-TANGO by default. J-MFG...

  • Page 64: Rtc Reset (J-Rtc)

    UEFI/BIOS POST after power on. Note that installing of jumper J-RTC will neither set UEFI/BIOS Setup to EKF Factory Defaults nor resets the time and date register values of the RTC (Real Time Clock). To reset the RTC core the board must be removed from the system rack. Short-circuit the pins of J-RTC for about 1 sec.

  • Page 65: Connectors

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Connectors Caution Some of the internal connectors provide operating voltage (3.3V, 5V and 12V) to devices inside the system chassis, such as internal peripherals. Not all of these connectors are short circuit protected. Do not use these internal connectors for powering devices external to the computer chassis.

  • Page 66: Front Panel Connectors

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Front Panel Connectors The PC6-TANGO front panel is provided with dual receptacles for monitors (DisplayPort), USB devices (Type-A 5Gbps), and networking (RJ45 GbE). In addition, a Micro SD card slot is available.

  • Page 67: Displayport Connectors

    +3.3V via current-limited electronic power switch. This voltage is switched on in S0 state only. Most professional monitors are equipped with a DisplayPort connector input. For attachment of either VGA, DVI or HDMI type display to the PC6-TANGO, there are suitable adapters and also adapter cables available.

  • Page 68: Usb Connectors

    USB Connectors The Intel® APL-I SoC incorporates an USB 3.0 xHCI host controller (USB 3.1 Gen1 SuperSpeed 5Gbps). Two ports are directly available on the PC6-TANGO front panel (type A receptacle), for attachment of external USB devices. P-USB • Dual USB 3.0 Receptacle USB 3.0 dual Type-A receptacle, stacked, 18-position...

  • Page 69: Ethernet Connectors Rj45

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Ethernet Connectors RJ45 All Ethernet ports on the PC6-TANGO are based on individual I210IT PCIe to Ethernet controllers, i.e. offer different MAC addresses, hence suitable for simple network attachment or flexible usage as router or gateway.

  • Page 70: Option M12 X-Coded Ethernet Receptacles

    MDX3- brown MDX2- white/blue MDX2+ blue Suitable industrial Gigabit Ethernet M12 cable assemblies can be ordered from EKF, or directly from well-known cable and connector manufacturers e.g. Metz, Phoenix, Escha and many others. Ordering Information Cable Assemblies Gigabit Ethernet cable M12 to M12: #271.14.008.xx (xx=length/meter) Gigabit Ethernet cable M12 to RJ-45: #271.15.008.xx (xx=length/meter)
  • Page 71 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) J-GP J-RTC P-DP1 P-DP2 CFast Socket P-USB Intel® Atom™ Dual 01 M12 © EKF P-ETH ekf.com PC - 6 TANGO P-FPH PC6-TANGO • © • ekf.com Front Panel...

  • Page 72: Microsd Card Holder

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) microSD Card Holder The PC6-TANGO is provided with a front panel microSD card slot (push-push type, w. card detect switch). microSDHC Host Connector • 218.6.010.1 DAT2 DAT3 +3.3V...

  • Page 73: Cfast™ Card Holder

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) CFast™ Card Holder By default, the PC6-TANGO is provided with a CFast™ host connector. It is suitable for CFast™ cards, which have the same dimensions as CompactFlash™ cards, but are operated in SATA mode. Industrial CFast™...
  • Page 74 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) The fixation alternate of the CFast™ card is a small L-shape mounting block (similar picture below). The threaded mounting element is fastened by a metric screw (M2x4) from the bottom side of the PCB.
  • Page 75 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) P-CF CFast™ Host Connector • 218.5.024.21 Part No. 218.5.024.21 • CFast™ Host Connector © EKF • ekf.com SATA_TXP (A+) SATA_TXN (A-) SATA_RXN (B-) SATA_RXP (B+) CDI (GND) DEVSLP...

  • Page 76: Mezzanine Connectors

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Mezzanine Connectors The PC6-TANGO is equipped with two connectors for optional mezzanine expansion. The connector P-HSE is used for SATA based mass storage, available as low profile module (4HP assembly), e.g. C48-M2 (dual M.2 SATA SSD). The legacy connector P-EXP is provided mainly for custom specific side card design (8HP assembly).

  • Page 77: Expansion Interface P-Exp

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Expansion Interface P-EXP P-EXP +3.3V CLK (25MHz) RST# LPC_AD0 LPC_AD1 LPC_AD2 LPC_AD3 LPC_FRAME# +3.3V LPC_SERIRQ EXP_SMI# SIO_CLK (14.3MHz) UART0_TXD UART0_RXD USB_EXP2- USB_EXP1- USB_EXP2+ USB_EXP1+ USB_EXP_OC# EXP_RST# 1.27mm I2C_SCL...

  • Page 78: High Speed Expansion Connector P-Hse

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) High Speed Expansion Connector P-HSE High Speed Expansion P-HSE SATA_HSE1_TXP SATA_HSE1_TXN SATA_HSE1_RXN SATA_HSE1_RXP SATA_HSE2_TXP SATA_HSE2_TXN SATA_HSE2_RXN SATA_HSE2_RXP a25 b25 +3.3VS +5VS +3.3VS +5VS +3.3VA +5VA +12V +12V Power rail switched on in state S0 only (switched)
  • Page 79 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) C47-MSATA Mezzanine Storage Module Based on the Connector HSE C48-M2 Mezzanine Storage Module Based on the Connector HSE © EKF -79- ekf.com...

  • Page 80: Pin Headers & Debug

    The jumper P-FPH is used for attachment of an external SPDT switch. By default, P-FPH is connected across a short cable harness to a microswitch, which is integrated into the PC6-TANGO front panel handle (ejector lever). The switch performs a power button event (e.g. system shutdown) by short- circuiting the pins 1 and 3 of P-FPH when activated (hold unlock button of front panel handle depressed momentarily).

  • Page 81: Pld Programming Header P-Pld

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) PLD Programming Header P-PLD The PC6-TANGO is provided with a powerful PLD (Programmable Logic Device) which replaces legacy glue logic. The programming header P-PLD is not stuffed (in use for manufacturing only). Its footprint is situated at the bottom side of the board.

  • Page 82: Firmware Programming Header P-Spi

    TXE) is stored in a Serial Flash memory. Updates are normally done by software. For debug and manufacturing a pin header P-SPI is provided (not stuffed by default) at the bottom side of the board. P-SPI 240.1.08. I • © EKF • ekf.com +1.8V SPI_SO SPI_SI...

  • Page 83: Processor Debug Header P-Mipi

    PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Processor Debug Header P-MIPI The PC6-TANGO can be equipped with a 60-position processor debug header for JTAG based hard- and software debugging (Samtec QSH series connector aka MIPI-60 specified by the MIPI Alliance Debug Working Group *).

  • Page 84: Power Terminal Block

    (option rear I/O module via J2). Note that in this configuration the platform reset signal is missing (located on J1 pin C5). Using an adapted programming of the PLD on PC6-TANGO could solve this problem. Please discuss your needs with sales@ekf.de before ordering.

  • Page 85: Backplane Connectors

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Backplane Connectors The backplane connector suite is comprised of two hard metric 2.0mm connectors. While the J1 connector is compliant to CompactPCI® PICMG® 2.0, the J2 connector pin assignment follows an enhancement specification named CompactPCI®...

  • Page 86: Compactpci J1

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) CompactPCI J1 REQ64# ENUM# 3.3V V(I/O) ACK64# 3.3V 3.3V 3.3V M66EN C/BE0# AD12 V(I/O) AD11 AD10 3.3V AD15 AD14 AD13 SERR# 3.3V C/BE1# 3.3V IPMB SCL IPMB SDA...
  • Page 87 +12V passed through to mezzanine connectors P-HSE and P-EXP, not required for PC6-TANGO basic operation The 3.3V pins can be sourced by the PC6-TANGO itself (power output via resettable fuse 2.0A), for +5V only power supply designs (consider power 3.3V power requirements of peripheral boards).

  • Page 88: Compactpci J2 (Plusio)

    Please note, that the CompactPCI® PlusIO specification refers to SATA data rates of 1.5Gbps and 3Gbps. EKF has tested successfully also 6G over the backplane with sample devices, but cannot guarantee this data rate under any condition. Other devices and other backplane brands/types in use may cause a different result.
  • Page 89 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) CLK6 2_ETH_B+ 1_ETH_D+ 1_ETH_B+ CLK5 2_ETH_B- 1_ETH_D- 1_ETH_B- 2_ETH_A+ 1_ETH_C+ 1_ETH_A+ 2_ETH_D+ 2_ETH_C+ 2_ETH_A- 1_ETH_C- 1_ETH_A- 2_ETH_D- 2_ETH_C- PRST# RST# REQ6# GNT6# 1) 4) reserved 4_PE_CLK- 2_PE_CLK+ DEG#...
  • Page 90 88SE9170 SATA controller. Since the CompactPCI® PlusIO specification refers to SATA 3Gbps, the Marvell SATA controller will be initialized for 3G operation. On request, the PC6-TANGO is available with 6Gbps data rate for J2 SATA, but should be validated by the customer for the targeted environment.

  • Page 91: Mechanical Drawing

    ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Mechanical Drawing The following drawing shows the positions of mounting holes and expansion connectors on the PC6-TANGO. 100.0mm 3.57/5.5mm © EKF -91- ekf.com...
  • Page 92 ® PC6-TANGO • CompactPCI PlusIO • Intel® Atom™ E39xx Processor (APL-I SoC) Industrial Computers Made in Germany boards. systems. solutions. Beyond All Limits: EKF High Performance Embedded EKF Elektronik GmbH Phone +49 (0)2381/6890-0 Philipp-Reis-Str. 4 (Haus 1) Fax +49 (0)2381/6890-90 Lilienthalstr.
