On-Board Connectors & Sockets
P-EXP Utility EXPansion Interface Connector (LPC, USB, HD Audio, SMBus),
P-HSE High Speed Expansion Connector (3 x SATA, 4 x USB), interface to optional low profile mezzanine
module or side board
P-PCIE PCI Express® Expansion Interface Connector, interface to optional side board
P-DP3 Digital Display Interface Connector, interface to optional 3
P1 CompactPCI
P2-P4 CompactPCI
P5 CompactPCI
P6 CompactPCI
P-SODM 204-pin DDR3L ECC Memory Module SDRAM PC3L-12800 Socket (ECC SODIMM)
P-XDP CPU Debug Port
1)
Connector populated on customers request only

Pin Headers

P-FPH Pin header suitable for Front Panel Handle switch cable harness
P-ISP PLD glue logic device programming connector, not populated

Jumpers

DS-P Switches to configure link width and speed on P-PCIE
J-GP Jumper to reset UEFI BIOS Setup to EKF Factory Defaults
J-MFG Jumper to enter Manufacturing Mode, not populated
J-RTC Jumper to reset RTC circuitry (part of PCH), not populated
