Microprocessor

The SC2-PRESTO is equipped with an Intel® Core
(code name "Haswell"). These low power processors provide integrated graphics, memory controller
and voltage regulators, which results in a very efficient platform design.
TM
The Core i7/i5/i3 processor family includes units with several thermal design power (TDP) classes to
fit the customers requirements: 47W, 37W and 25W. The processors are housed in a Micro FC-BGA
package for direct soldering to the PCB, i.e. the chip cannot be removed or changed by the user.
The processors supported by the SC2-PRESTO are running at core clock speeds up to 2.4GHz for quad
core and up to 2.7GHz on dual core devices. Due to Enhanced Intel® SpeedStep® and Intel® Turbo
Boost Technology each core can decrease or increase its nominal operating frequency. The clock speed
is chosen depending on the power states of the processor cores/graphics engine, the currently
required performance, and the actual core temperature.
Power is applied across the CompactPCI
generated by a switched voltage regulator according to Intels VR12.5 voltage regulator specification.
Processor Physical
Number Cores
i7-4700EQ
4
2)
i5-4400E 2
i5-4422E 2
2002E 2
1)
The processors listed are units with long life support.
2)
This processor may run with different TDPs configurable by BIOS settings.
© EKF
®
TM
Intel® Core
Core Clock Cache
nom./max. [MB]
[GHz]
2.4/3.4 400-1200
6
2.2/3.2 400-1150
2.7/3.3 3 400-1000
1.8/2.9 3 400-900
1.5/1.5 2 400-900
®
Serial CPU Board • Intel® Core
TM th
i7, i5 or i3 4
connector P1 (12V). The processors core voltage are
Processors Supported
Gfx Junction TDP
Clock Temp. [W]
[MHz] [°C]
47
100
37
100 37
100 25
100 25
-19-
TM
4xxx Processor
generation mobile ECC processor
1)
CPU ID Stepping
40661h C-0
40661h C-0
40661h C-0
40661h C-0
SPEC
Code
SR17L
SR17M
SR1T1
SR17P
