Zipper Insertion; Centered Zipper - Brother computerized sewing and embroidery machine Operation Manual

SEWING THE STITCHES
g
Press
* The fabric will move sideways, so guide the fabric
with your hands to sew straight.
Memo
Zigzag stitches can also be used with multi-directional
sewing.
LSN

Zipper Insertion

■ Centered Zipper

Use for bags and other such applications.
a
Press
* Be sure to select the straight stitch with the middle
needle position.
Memo
For details on the stitch patterns, refer to the "STITCH
SETTING CHART" at the end of this manual.
b
Attach presser foot "J", sew straight stitches
up to the zipper opening, and then sew
basting stitches to the top of the fabric.
a Wrong side of fabric
b End of zipper opening
c Basting
d Reverse stitching
LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur
84
, and then sew seam 4.
.
c
a
b
d
Tel: 03-91025766/ 5767
c
Press open the seam allowance, align the
seam with the center of the zipper, and then
baste the zipper in place.
a Wrong side of fabric
b Basting
c Zipper teeth
d
Remove presser foot "J", and then attach the
pin on the right side of zipper foot "I" to the
presser foot holder.
b
a Right side
b Left side
c Needle drop point
• When using zipper foot "I", make sure the straight
stitch, middle needle position is selected. Turn the
handwheel to make sure the needle does not strike
the presser foot. If another stitch is selected, the
needle will strike the presser foot, causing the needle
to break and possibly causing injury.
e
Topstitch around the zipper, and then remove
the basting.
• Make sure the needle does not strike the zipper
during sewing. If the needle strikes the zipper, the
needle may break, leading to injury.
Fax: 03-91025768 H/P: 012-6552245
b
a
a
c
a
CAUTION
CAUTION
c
