e
While holding the thread from the spool in
your right hand, hold the end of the thread
with your left hand, and then pass the thread
through the thread guide.
a
Thread guide
f
Pass the thread under the pin on the bobbin
LSN
winding thread guide, and then pass it around
the pretension disk.
* Make sure that the thread passes under the pretension disk.
a
a
Pin
b
Pretension disk
g
Wind the thread clockwise around the bobbin
four or five times.
3
h
Pass the end of the thread through the guide
slit in the bobbin winder seat, and then pull
the thread to the right to cut it with the
cutter.
a
a
Guide slit
b
Bobbin winder seat
• Be sure to follow the process described. If the thread
is not cut with the cutter, and the bobbin is wound,
when the thread runs low, it may tangle around the
bobbin.
LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur
a
b
2
1
b
CAUTION
Tel: 03-91025766/ 5767
i
Slide the bobbin holder to the left until it
snaps into place.
* When the bobbin holder is set to the left, it works as a
switch to make the bobbin wind automatically.
a
Bobbin holder (switch)
→ The bobbin stops spinning automatically when it is
full, and the bobbin holder returns to its original
position.
j
Cut the thread, and then remove the bobbin.
Note
When removing the bobbin, pull up only on the bobbin.
Do not pull on the bobbin winder seat, otherwise it may
become loose, resulting in damage to the machine.
• Setting the bobbin improperly may cause the thread
tension to loosen, breaking the needle and possibly
resulting in injury.
Fax: 03-91025768 H/P: 012-6552245
LOWER/UPPER THREADING
a
CAUTION
1
