d
Press
LSN
→ The pattern selection screen appears.
e
Select an embroidery pattern to be retrieved.
* If you decide not to retrieve the pattern, press
.
a
b
e
f
a PHC data
b PES data
c Large-size embroidery pattern data
d DST data
e Amount of memory currently being used
f Total amount of "Removable Disk" memory available
for saving patterns
Memo
• If there are 13 or more patterns saved in
"Removable Disk", the patterns cannot be displayed.
When the message "Only 12 patterns can be saved.
Reduce the number of patterns." appears, delete
patterns from "Removable Disk" so that it contains
no more than 12 patterns. Then, close the error
message, repeat the procedure starting from step
d
and then press
• For details on large-size embroidery patterns, refer
to PE-DESIGN Instruction Manual.
LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur
.
c
d
to retrieve the pattern.
Tel: 03-91025766/ 5767
USING THE MEMORY FUNCTION
f
Press .
a Amount of memory used by the selected pattern
→ The sewing screen appears.
Β
• When disconnecting the USB cable:
Before disconnecting the USB cable, click the
"Unplug or Eject Hardware" icon in the taskbar of
®
Windows Me/2000 or the "Safely Remove
Hardware" icon in the taskbar of Windows
Then, when the removable disk has been removed
safely, disconnect the USB cable from the computer
and the machine.
With Windows 98SE, check that the Access
lamp is not flashing before disconnecting the
USB cable from the computer and the
machine.
Note
• Be sure to perform the operation described above
before disconnecting the USB cable from the
computer and the machine, otherwise the computer
may malfunction, the data may not be written
correctly, or the data or data writing area on the
machine may be damaged.
• The pattern retrieved from the computer is only
temporarily written to the machine. It is erased from
the machine when the machine is turned off. If you
wish to keep the pattern, store it in the machine (see
"Saving Embroidery Patterns in the Machine's
Memory" on page 141).
Fax: 03-91025768 H/P: 012-6552245
a
CAUTION
®
5
XP.
145
