SEWING AN EMBROIDERING PATTERN

Sewing Attractive Finishes

There are many factors that go into sewing beautiful embroidery. Using the appropriate stabilizer (see page 120)
and hooping the fabric in the frame (see page 121) are two important factors mentioned earlier. Another
important point is the appropriateness of the needle and thread being used. See the explanation of threads
below. Included with this machine are two bobbin cases. Follow the explanation below.
Thread
Upper thread
Bobbin thread
LSN
Memo
If you use threads other than those listed above, the embroidery may not sew out correctly.
Bobbin case
a
aMarking Green/Pink
See page 176 for how to remove the bobbin case.
Note
• Before embroidering, check that there is enough thread in the bobbin. If you continue sewing without enough thread in
the bobbin, the thread may tangle.
• Do not leave objects in the range of motion of the embroidery frame. The frame may strike the object and cause a poor
finish to the embroidery pattern.
• When embroidering on large garments (especially jackets or other heavy fabrics), do not let the fabric hang over the
table. Otherwise, the embroidery unit cannot move freely, and the pattern may not turn out as planned.

■ Embroidery Needle Plate Cover

Under some conditions, based on the type of fabric,
stabilizer, or thread being used, there may be some
looping in the upper thread. In this case, attach the
included embroidery needle plate cover to the
needle plate. Attach the cover by inserting the two
projections on the underside of the cover into the
notches on the needle plate as shown below.
b
a Groove
b Projections
c Notches
To remove the embroidery needle plate cover, place
your fingernail in the groove and lift the plate out.
LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur
Use embroidery thread, or country embroidery thread intended for use with this machine.
Other embroidery threads may not yield optimum results.
Use embroidery bobbin thread intended for use with this machine.
Standard bobbin case (green marking on the screw) is in the machine for sewing and embroidery. The bobbin
case originally installed in the machine has a green screw.
Alternate bobbin case (pink marking) is set with tighter tension for embroidery with different weights of
bobbin threads and a variety of embroidery techniques.
a
c
Tel: 03-91025766/ 5767
SEWING AN EMBROIDERING PATTERN
• Push the embroidery needle plate cover as far as
possible to attach it. If the embroidery needle plate
cover is not securely attached, it may cause the
needle to break.
Note
Do not use the embroidery needle plate cover for any
applications other than embroidery.
Fax: 03-91025768
H/P: 012-6552245
CAUTION
5
131
