Table of Contents

   Also See for Brother computerized sewing and embroidery machine

   Related Manuals for Brother computerized sewing and embroidery machine

   Summary of Contents for Brother computerized sewing and embroidery machine

  • Page 1 LINGS SERVICE NETWORK (M) SDN BHD NO 24 Jalan Damai Perdana 1/8C Bandar Damai Perdana 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using this machine, basic safety precautions should always be taken, including the following: Read all instructions before using. DANGER - To reduce the risk of electric shock: The machine should never be left unattended while plugged in. Always unplug the machine from the electrical outlet immediately after using and before cleaning.
  • Page 3 FOR USERS IN THE UK, EIRE, MALTA AND CYPRUS ONLY If this machine is fitted with a three-pin non-rewireable BS plug then please read the following. IMPORTANT If the available socket outlet is not suitable for the plug supplied with this equipment, it should be cut off and an appropriate three-pin plug fitted.
  • Page 4 • The included interface cable should be used in order to ensure compliance with the limits for a Class B digital device. • Changes or modifications not expressly approved by Brother Industries, Ltd. could void the user's authority to operate the equipment.
  • Page 5 If the problem persists, please consult your local authorized Brother dealer. For additional product information and updates, visit our web site at www.brother.com The contents of this manual and specifications of this product are subject to change without notice.
  • Page 6: How To Use This Manual

    HOW TO USE THIS MANUAL Chapters 1 and 2 describe to the first-time user the initial operations for using this machine and the basic sewing operations. To sew utility stitches Continue with chapter 3 to learn how to select a stitch and sew using the various stitches. Chapter 2 Chapter 1 Chapter 3...
  • Page 7: Table Of Contents

    Contents CONTENTS NAMES OF MACHINE PARTS AND THEIR Smocking..............69 Fagoting..............70 FUNCTIONS ............9 Tape or Elastic Attaching........... 71 Machine ..............9 Heirloom Stitching............ 72 Needle and Presser Foot Section ....... 10 Buttonhole Stitches ........... 74 Embroidery Unit ............10 Bar Tacks ..............
  • Page 8 Contents Embroidering Small Fabrics and Fabric Edges ..123 CARE AND MAINTENANCE ......176 ATTACHING THE EMBROIDERY FRAME ..124 Cleaning the LCD ............ 176 EDITING THE PATTERN ........125 Cleaning the Machine Casing ........176 Cleaning the Race ........... 176 Changing the Embroidery Frame Display....125 ADJUSTING THE SCREEN.........
  • Page 9 LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 10: Names Of Machine Parts And Their Functions

    NAMES OF MACHINE PARTS AND THEIR FUNCTIONS NAMES OF MACHINE PARTS AND THEIR FUNCTIONS Machine ■ Front View ■ Right-side/Rear View a Handle a Top cover When transporting the machine, carry it by this handle. Open the top cover to thread the machine and wind the bobbin. b Handwheel b Thread guide plate Turn the handwheel toward you to sew one stitch or to raise or...
  • Page 11: Needle And Presser Foot Section

    NAMES OF MACHINE PARTS AND THEIR FUNCTIONS Needle and Presser Foot Section Embroidery Unit a Buttonhole lever a Carriage Lower the buttonhole lever when sewing buttonholes and bar The carriage moves the embroidery frame automatically when tacks. embroidering. b Presser foot holder b Release button (located under the embroidery unit) The presser foot is attached to the presser foot holder.
  • Page 12: Operation Buttons

    NAMES OF MACHINE PARTS AND THEIR FUNCTIONS Operation Buttons Included Accessories The accessories are stored in the flat bed attachment. Open the flat bed attachment as shown below. a “Start/Stop” button When this button is pressed, the machine sews a few stitches at a low speed, then begins sewing at the speed set by the sewing speed controller.
  • Page 13 NAMES OF MACHINE PARTS AND THEIR FUNCTIONS 75/11 2 needles 90/14 2 needles 90/14 2 needles: Ball point needle (gold colored) LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 14 NAMES OF MACHINE PARTS AND THEIR FUNCTIONS Part Code Memo Part Name U.S.A./ Others (For U.S.A. only) Canada Foot controller: Model T 1 Embroidery foot “U” XD0313-051 This foot controller can be used with this 2 Buttonhole foot “A” X57789-151 machine model NV1500D/NV1500.
  • Page 15: Options

    NAMES OF MACHINE PARTS AND THEIR FUNCTIONS Options Note • Embroidery cards purchased in foreign countries may not work with your machine. • Visit your authorized dealer for complete listing of optional accessories available for your machine. Part Code Part Name U.S.A./ Others Canada...
  • Page 16: Chapter 1 Getting Ready

    Chapter Getting Ready TURNING THE MACHINE ON/OFF............16 LCD SCREEN..................17 ■ Display Precautions......................17 ■ Key Functions ........................18 Using the Machine Setting Mode Key..............20 Using the Machine Operation Mode Key ..............22 ■ Contents of Each Category ....................22 Using the Pattern Explanation Key ................23 LOWER/UPPER THREADING ..............24 Winding the Bobbin ....................24 ■...
  • Page 17: Turning The Machine On/off

    TURNING THE MACHINE ON/OFF TURNING THE MACHINE ON/OFF WARNING • Use only regular household electricity as the power source. Using other power sources may result in fire, electric shock, or damage to the machine. • Turn the main power to OFF and remove the plug in the following circumstances: When you are away from the machine After using the machine When the power fails during use...
  • Page 18: Lcd Screen

    LCD SCREEN LCD SCREEN ■ Display Precautions • Only touch the display with your finger or the touch pen included with the machine. Do not use a mechanical pencil, screwdriver or any other hard or sharp objects. In addition, do not press the display with extreme pressure, otherwise damage to the display may result.
  • Page 19: Key Functions

    LCD SCREEN ■ Key Functions With your finger or the touch pen, press a key at the top of the display ( ) to change the screen that is displayed. Operation panel Name Function Page Machine setting mode Press this key to change the needle stop position, turn the buzzer on/off, adjust the pattern or screen, and change other machine settings.
  • Page 20 LCD SCREEN Screen Name Function Page Screen lock key Press this key to lock the screen. When the screen is locked, the various settings, such as the stitch width and stitch length, are locked and cannot be changed. Press this key again to unlock the settings. Sewing type selection Press this key when you need help selecting the appropriate stitch pattern for the sewing application and when you need instructions on how to sew the selected...
  • Page 21: Using The Machine Setting Mode Key

    LCD SCREEN Using the Machine Setting Mode Key Press to change the needle stop position, turn the buzzer on/off, adjust the pattern or screen, and change other basic machine settings. Select whether the needle stops in the raised or lowered position when the machine is stopped. Select whether to use the sewing speed controller or to adjust the zigzag width (see page 64).
  • Page 22 Memo The latest version of software is installed in your machine. Check with your local authorized Brother dealer or at www.brother.com for notification of available updates (see page 189). LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur...
  • Page 23: Using The Machine Operation Mode Key

    LCD SCREEN Using the Machine Operation Mode Key Basic machine operations and other information based on the contents of this Operation Manual are stored in this machine. Press to open the screen shown below. Six categories are displayed at the top of the screen. Press a key to see more information about that category.
  • Page 24: Using The Pattern Explanation Key

    LCD SCREEN Example: Displaying information about upper Using the Pattern Explanation Key threading Press To learn more about the uses for a stitch pattern, select Press the stitch, and then press to see a description of → A list of basic operations appears in the lower half of the selected stitch.
  • Page 25: Lower/upper Threading

    LOWER/UPPER THREADING LOWER/UPPER THREADING Set the supplemental spool pin in the “up” Winding the Bobbin position. This section describes how to wind thread onto a bobbin. With this machine, you can use the supplemental spool pin to wind the bobbin while sewing using the main spool pin.
  • Page 26 LOWER/UPPER THREADING While holding the thread from the spool in Slide the bobbin holder to the left until it your right hand, hold the end of the thread snaps into place. with your left hand, and then pass the thread * When the bobbin holder is set to the left, it works as a through the thread guide.
  • Page 27: Winding The Bobbin Using The Spool Pin

    LOWER/UPPER THREADING ■ Winding the Bobbin Using the Spool Pin Slide the spool cap as far as possible onto the spool pin, and then return the spool pin to its The main spool pin cannot be used to wind the original position.
  • Page 28: Setting The Bobbin

    LOWER/UPPER THREADING Lightly hold down the bobbin with your right Setting the Bobbin hand, and then, while slightly pulling the thread with your left hand, guide it through This section describes how to set a bobbin wound with the groove. thread into the machine.
  • Page 29: Upper Threading

    LOWER/UPPER THREADING Guide the bobbin thread through the groove, Upper Threading following the arrow in the illustration. This section describes how to thread the machine and Note the needle. The machine is marked with numbers that • Do not cut the thread with the cutter. indicate the threading order.
  • Page 30 LOWER/UPPER THREADING Press the “Needle Position” button to raise While holding the thread from the spool in the needle. your right hand, hold the end of the thread with your left hand, and then guide the thread through the groove, following the arrows in the illustration.
  • Page 31 LOWER/UPPER THREADING Pass the thread through the thread guide disks Release the needle threader lever. (marked “7”). → The thread passes through the eye of the needle. * Make sure that the thread passes through the groove in the thread guide. Carefully pull the end of thread that was * Make sure that the thread securely enters the thread guide disks, otherwise the needle may not be threaded.
  • Page 32: Using The Twin Needle

    LOWER/UPPER THREADING Pass the thread through the needle bar thread Using the Twin Needle guide, and then thread the needle on the left side. Using the twin needle, you can sew two parallel lines of the same stitch. Although the same bobbin thread is used, interesting patterns can be sewn by threading each needle with a different color of thread.
  • Page 33 LOWER/UPPER THREADING While holding the thread from the spool with Press to select the setting for twin both hands, pull the thread through the lower needle sewing. notch in the thread guide plate, then through * The stitch width becomes narrower than with single needle the upper notch.
  • Page 34: Changing The Presser Foot

    CHANGING THE PRESSER FOOT CHANGING THE PRESSER FOOT CAUTION • Always press in the operation panel before changing the presser foot. If is not pressed and the “Start/Stop” button or another button is pressed, the machine will start and may cause injury. •...
  • Page 35: Changing The Needle

    CHANGING THE NEEDLE CHANGING THE NEEDLE CAUTION • Always press in the operation panel before changing the needle. If is not pressed and the “Start/ Stop” button or another operation button is pressed accidentally, the machine will start and injury may result. •...
  • Page 36 CHANGING THE NEEDLE Use the included screwdriver to turn the needle clamp screw toward the front of the machine to loosen it, and then remove the needle. Note Do not apply extreme force when loosening or tightening the needle clamp screw, otherwise damage to the machine may result.
  • Page 37: About The Needle

    CHANGING THE NEEDLE ■ About the Needle The sewing machine needle is probably the most important part of the sewing machine. Choosing the proper needle for your sewing project will result in a beautiful finish and fewer problems. Below are some things to keep in mind about needles.
  • Page 38: Chapter 2 Sewing Basics

    Chapter Sewing Basics SEWING ....................38 Sewing a Stitch......................38 ■ Using the Foot Controller....................39 ■ Using the Knee Lifter.......................40 Sewing Reinforcement Stitches ................40 Sewing Curves......................40 Changing Sewing Direction..................40 ■ Sewing a Seam Allowance of 0.5 cm or Less ..............40 Sewing Heavyweight Fabric ..................41 ■...
  • Page 39: Sewing

    SEWING SEWING CAUTION • To avoid injury, pay special attention to the needle while the machine is in operation. Keep your hands away from moving parts while the machine is in operation. • Do not stretch or pull the fabric during sewing. Doing so may lead to injury. •...
  • Page 40: Using The Foot Controller

    SEWING ■ Using the Foot Controller To stop sewing, press the “Start/Stop” button again. You can also use the foot controller to start and stop sewing. CAUTION • Do not allow fabric pieces and dust to collect in the foot controller. Doing so could cause a fire or an electric shock.
  • Page 41: Sewing Reinforcement Stitches

    SEWING ■ Using the Knee Lifter Sewing Reinforcement Stitches Using the knee lifter, you can raise and lower the presser foot with your knee, leaving both hands free to handle the fabric. Generally stitching must be secured at the beginning and end with reverse/reinforcement stitches.
  • Page 42: Sewing Heavyweight Fabric

    SEWING While keeping the black button on the left Sewing Heavyweight Fabric side of presser foot “J” pressed in, lower the presser foot lever. ■ If the Fabric Does Not Fit Under the Presser Foot The presser foot lever can be raised to two different positions.
  • Page 43: Adjusting Stitch Settings

    ADJUSTING STITCH SETTINGS ADJUSTING STITCH SETTINGS When a stitch is selected, the most appropriate stitch width, stitch length, and upper thread tension are automatically set. However, if needed, you can change any of the settings as described in this section. Note •...
  • Page 44: Adjusting The Thread Tension

    USEFUL FUNCTIONS ■ Upper Thread Is Too Tight Adjusting the Thread Tension If the bobbin thread can be seen on the surface of the fabric, press . Each press of the key reduces The default thread tension, which is automatically set, the setting and makes the thread tension more loose.
  • Page 45: Automatic Thread Cutting

    USEFUL FUNCTIONS Place the fabric under the presser foot with the Press to select the automatic thread needle at the starting point of the stitching, and cutting setting. then press the “Start/Stop” button. The machine will automatically sew reverse stitches (or reinforcement stitches), and then begin sewing.
  • Page 46: Locking The Screen

    USEFUL FUNCTIONS Locking the Screen If the screen is locked before starting to sew, the various settings, such as the stitch width and stitch length, are locked and cannot be changed. This prevents screen settings from accidentally being changed or the machine from being stopped while large pieces of fabric or other projects are being sewn.
  • Page 47 USEFUL FUNCTIONS LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 48: Chapter 3 Utility Stitches

    Chapter Utility Stitches ■ Hemstitching (3) (Drawn Work (2)) .....73 SELECTING A UTILITY STITCH ...48 Buttonhole Stitches...........74 ■ Stitch Selection Screens ........48 ■ Sewing Stretch Fabrics .........77 ■ Buttons That Do Not Fit into the Button Holder Selecting a Stitch Pattern........49 Plate ..............77 ■...
  • Page 49: Selecting A Utility Stitch

    SELECTING A UTILITY STITCH SELECTING A UTILITY STITCH ■ Stitch Selection Screens Press to display the previous or next page. Straight/Overcasting/Quilting Stitches Decorative Stitches Heirloom Stitches Buttonholes/Bar tacks Multi-Directional Sewing LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 50: Selecting A Stitch Pattern

    SELECTING A UTILITY STITCH Selecting a Stitch Pattern Saving Stitch Settings This machine is preset with the default settings for the Turn on the machine, and then lightly press stitch width (zigzag width), stitch length, thread tension, the display. automatic thread cutting, automatic reverse/ reinforcement stitching, etc.
  • Page 51: Using The Sewing Type Selection Key

    SELECTING A UTILITY STITCH Press Memo • The next time that the same straight stitch is selected, the stitch length is set to 2.0 mm. • All stitch settings (stitch width (zigzag width), stitch length, thread tension, automatic thread cutting, and automatic reverse/reinforcement stitching) are saved, not just the setting that was changed.
  • Page 52: Sewing The Stitches

    SEWING THE STITCHES SEWING THE STITCHES Straight Stitches Note When using the twin needle (see page 31), be sure to attach presser foot “J”. Stitch width Stitch length Stitch Stitch Name Presser Applications Twin [mm (inch.)] [mm (inch.)] Foot needle Auto.
  • Page 53: Changing The Needle Position (left Or Middle Needle Position Stitches Only)

    SEWING THE STITCHES Select a stitch pattern. At the end of the stitching, hold the “Reverse/ Reinforcement Stitch” button pressed to sew reverse stitches (or reinforcement stitches). Press the “Thread Cutter” button to trim the threads. * If the automatic thread cutting setting is selected before sewing, the machine will automatically sew reverse stitches (or reinforcement stitches) at the Attach presser foot “J”.
  • Page 54: Darts Seams

    SEWING THE STITCHES Darts Seams Memo For a standard 16 mm (approx. 5/8 inch) seam allowance, set the width to 0 mm on the screen. While Press , and then attach presser foot “J”. sewing, align the edge of the fabric with the 16mm (approx.
  • Page 55: Gathering

    SEWING THE STITCHES Pull the bobbin threads to create the desired Gathering amount of gathering, and then tie the threads. Sew gathers on sleeves, the waist of a gathered skirt, etc. Select a straight stitch, and then attach presser foot “J”. Smooth the gathers by ironing them.
  • Page 56: Pintucks

    SEWING THE STITCHES Lay both seam allowances on the side of the Pintucks shorter one (cut seam allowance) and iron them flat. Use pin tucks to decorate blouses. Mark the positions of the folds on the wrong side of the fabric. a Wrong side of fabric Fold the longer seam allowance around the shorter one, and then sew along the edge of...
  • Page 57: Zigzag Stitches

    SEWING THE STITCHES Zigzag Stitches Zigzag stitches are useful for a variety of applications, including overcasting and sewing appliqués and patchwork. Note When using the twin needle (see page 31), be sure to attach presser foot “J”. Stitch Width Stitch Length Stitch Presser Twin...
  • Page 58: Elastic Zigzag Stitches

    SEWING THE STITCHES ■ Patchwork (Crazy Quilts) ■ Sewing Curves Turn back the desired width of fabric, place it over a Shorten the stitch length setting to obtain a fine different piece of fabric, and then sew the two fabric stitch.
  • Page 59: Overcasting

    SEWING THE STITCHES Overcasting Sew overcasting at the beginning and end of seams for skirts or pants, and at the beginning and end of all cuttings. Depending on the selected stitch, use presser foot “G” or “J” or the side cutter attachment. ■...
  • Page 60: Overcasting Using Presser Foot "j

    SEWING THE STITCHES ■ Overcasting Using Presser Foot “J” Stitch width Stitch length Stitch Presser Twin [mm (inch.)] [mm (inch.)] Stitch Name Applications Foot needle Auto. Manual Auto. Manual Overcasting stitch Reinforced seaming of stretch 0.0 - 7.0 0.5 - 4.0 fabric (3/16) (0 - 9/32)
  • Page 61: Overcasting Using The Side Cutter

    SEWING THE STITCHES ■ Overcasting Using the Side Cutter By using the side cutter, you can do overcasting while cutting the fabric. CAUTION • Make sure to only select one of the stitches listed below. Using another stitch may cause the needle to hit the presser foot and break, possibly causing injury.
  • Page 62 SEWING THE STITCHES Select a stitch. Start sewing. → A seam allowance is cut while the stitching is sewn. Note If the width has been adjusted, turn the handwheel by hand to check that the needle does not touch the side cutter.
  • Page 63: Quilting

    SEWING THE STITCHES Quilting You can make beautiful quilts quickly and easily with this machine. When making a quilt, you will find it convenient to use the knee lifter and foot controller to free your hands for other tasks (see “Using the Foot Controller”...
  • Page 64: Quilting

    SEWING THE STITCHES ■ Quilting Place one hand on each side of the presser foot to hold the fabric secure while sewing. Sewing together the quilt top, batting, and backing is called quilting. You can sew the quilt with the Memo walking foot to keep the quilt top, batting, and backing from sliding.
  • Page 65: Satin Stitching

    SEWING THE STITCHES Check the needle drop point, and then sew Set “WIDTH CONTROL” to “ON”. The along the edge of the appliqué while making sewing speed will be adjusted using the foot sure that the needle drops slightly off the edge controller.
  • Page 66: Free-motion Quilting

    SEWING THE STITCHES ■ Free-motion Quilting Lower the feed dog position switch, located at the rear of the base of the machine, to With free-motion quilting, the feed dogs can be lowered (using the feed dog position switch) so that the fabric can be moved freely in any direction.
  • Page 67: Blind Hem Stitches

    SEWING THE STITCHES Blind Hem Stitches Select a blind hem stitch to sew the hems or cuffs of dresses, blouses, pants, or skirts. Stitch Stitch Name Presser Applications Stitch Width Stitch Length Twin Foot [mm (inch)] [mm (inch)] Needle Auto Manual Auto Manual...
  • Page 68: Appliqués

    SEWING THE STITCHES Remove the basting, and then turn over the Appliqués fabric. Use a temporary spray adhesive or basting to attach the appliqué to the fabric. a Wrong side of fabric b Surface of fabric Memo a Appliqué Blind hem stitches cannot be sewn if the needle does b Fabric glue not catch the fold on the left side.
  • Page 69: Shell Tuck Stitching

    SEWING THE STITCHES ■ Sewing Sharp Curves Attach presser foot “J”, and then sew along the edge of the fabric, making sure that the Stop the machine with the needle in the fabric needle drops slightly off the edge. outside the appliqué. Raise the presser foot and turn the fabric a little bit at a time while sewing for an attractive finish to the seam.
  • Page 70: Top Stitching

    SEWING THE STITCHES Leave a seam when sewing the scallop Turn the fabric over so that the surface faces stitches so that the pattern is not sewn up, and then sew over the seam with the directly on the edge of the fabric. center of the presser foot aligned with the seam.
  • Page 71: Fagoting

    SEWING THE STITCHES Pull the bobbin threads to create the desired Fagoting amount of gather, and then smooth the gathers by ironing them. Stitching across an open seam is called fagoting. It is used on blouses and children’s clothing. Separate the two pieces of fabric by about 4 mm (approx.
  • Page 72: Tape Or Elastic Attaching

    SEWING THE STITCHES Press Tape or Elastic Attaching Note Elastic tape is sewn onto the fabric unstretched. For details on the stitch patterns, refer to the “STITCH Select a straight stitch, and then attach SETTING CHART” at the end of this manual. presser foot “J”.
  • Page 73: Heirloom Stitching

    SEWING THE STITCHES Select a stitch, attach presser foot “N”, and Heirloom Stitching then start sewing. * Select a stitch between 3-01 and 3-22. By sewing with the wing needle sold separately, the Drawn Work (1 needle holes are enlarged, creating a lace-like decorative stitch.
  • Page 74: Hemstitching (3) (drawn Work (2))

    SEWING THE STITCHES ■ Hemstitching (3) (Drawn Work (2)) Pull out several threads from the fabric to leave a 3 mm (approx. 1/8 inch) area open. Memo For best result, use loosely woven fabrics. Memo Drawn work can also be sewn using the wing needle (sold separately).
  • Page 75: Buttonhole Stitches

    SEWING THE STITCHES Buttonhole Stitches Select the desired buttonhole stitch according to your application and the size of the button. Stitch Width Stitch Length Stitch Presser Twin [mm (inch)] [mm (inch)] Stitch Name Applications Foot Needle Auto Manual Auto Manual Narrow rounded Buttonhole on light to medium 3.0 - 5.0...
  • Page 76 SEWING THE STITCHES Select a stitch, and then attach presser foot Hold the outside frame of the buttonhole foot “A”. toward the back with your finger, and then lower the presser foot so that the mark on the Mark the position and length of the fabric aligns with the marks on the buttonhole buttonhole on the fabric.
  • Page 77 SEWING THE STITCHES Gently hold the end of the upper thread, and Insert a pin along the inside of a bar tack at then start sewing. the end of the buttonhole, and then insert the seam ripper into the center of the buttonhole * Once sewing is completed, the machine and cut towards the pin.
  • Page 78: Sewing Stretch Fabrics

    SEWING THE STITCHES ■ Sewing Stretch Fabrics ■ Buttons That Do Not Fit into the Button Holder Plate When sewing a buttonhole on stretch fabrics, press Use the markings on the presser foot scale to set the , and use a gimp thread. size of the buttonhole.
  • Page 79: Darning

    SEWING THE STITCHES ■ Darning Use darning stitches for mending and other applications. Stitch Stitch Name Presser Applications Stitch Width Stitch Length Twin Foot [mm (inch)] [mm (inch)] Needle Auto Manual Auto Manual Darning Darning of medium weight fabric 2.5 - 7.0 0.4 - 2.5 (1/4) (3/32 - 1/4)
  • Page 80: Bar Tacks

    SEWING THE STITCHES Pull down the buttonhole lever. Gently hold the end of the upper thread, and then start sewing. * The buttonhole lever should be positioned behind the metal bracket on the buttonhole foot, as shown * Once sewing is completed, the machine in the illustration.
  • Page 81: Bar Tacks On Thick Fabrics

    SEWING THE STITCHES Position the fabric so that the opening of the Gently hold the end of the upper thread, and pocket moves toward you during sewing. then start sewing. Hold the outside frame of the buttonhole foot * Once sewing is completed, the machine toward the back with your finger, check the automatically sews reinforcement stitches, then first needle drop point, and then lower the...
  • Page 82: Button Sewing

    SEWING THE STITCHES Button Sewing Buttons with 2 or 4 holes can be sewn on. Note Make sure that the automatic thread cutting setting is not selected when sewing on buttons. Stitch width Stitch length Stitch Presser Twin [mm (inch.)] [mm (inch.)] Stitch Name Applications...
  • Page 83: Eyelets

    SEWING THE STITCHES ■ Attaching a 4-Hole Button When sewing is finished, pull the two ends of the upper thread between the button and the Sew the two holes toward the front. Then, raise the fabric, wind them around the shank, and then presser foot, move the fabric so that the needle goes tie them together.
  • Page 84: Multi-directional Sewing (straight Stitch And Zigzag Stitch)

    SEWING THE STITCHES Use the eyelet punch to cut a hole in the Press , and then attach presser foot “N”. center of the stitching. Multi-Directional Sewing (Straight Stitch and Zigzag Stitch) Use these stitch patterns to attach patches or emblems Memo to pant legs, shirt sleeves, etc.
  • Page 85: Zipper Insertion

    SEWING THE STITCHES Press , and then sew seam 4. Press open the seam allowance, align the seam with the center of the zipper, and then * The fabric will move sideways, so guide the fabric baste the zipper in place. with your hands to sew straight.
  • Page 86: Side Zipper

    SEWING THE STITCHES ■ Side Zipper Remove presser foot “J”, and then attach the presser foot holder to the pin on the right side Use for side zippers on skirts or dresses. of zipper foot “I”. Press * Be sure to select the straight stitch with the middle needle position.
  • Page 87 SEWING THE STITCHES Close the zipper, turn the fabric over so that the surface faces up, and then baste the other side of the zipper to the fabric. a Front of garment (wrong side of fabric) b Back of garment (surface of fabric) c Basting d Front of garment (surface of fabric) Remove the presser foot, and then attach the...
  • Page 88: Chapter 4 Character/decorative Stitches

    Chapter Character/ Decorative Stitches SELECTING STITCH PATTERNS............88 ■ Stitch Selection Screens ......................88 Selecting Decorative Stitch Patterns/7 mm Decorative Stitch Patterns/Satin Stitch Patterns/ 7 mm Satin Stitch Patterns/Cross Stitch Patterns/Utility Decorative Stitch Patterns....89 Alphabet Patterns........................89 SEWING STITCH PATTERNS ...............91 Sewing Attractive Finishes......................91 Basic Sewing ..........................91 Adjusting Patterns ........................92 EDITING STITCH PATTERNS...............94...
  • Page 89: Selecting Stitch Patterns

    SELECTING STITCH PATTERNS SELECTING STITCH PATTERNS ■ Stitch Selection Screens Press to display the screen shown below. a Decorative stitch patterns b 7 mm decorative stitch patterns c Satin stitch patterns d 7 mm satin stitch patterns e Cross stitch patterns f Utility decorative stitch patterns g Alphabet patterns (gothic font) h Alphabet patterns (handwriting font)
  • Page 90: Selecting Decorative Stitch Patterns/7 Mm

    SELECTING STITCH PATTERNS To combine patterns, select the next pattern. Selecting Decorative Stitch Patterns/ * Press to check the selected pattern 7 mm Decorative Stitch Patterns/ combination. Satin Stitch Patterns/ * If the wrong pattern was selected, press 7 mm Satin Stitch Patterns/Cross erase the pattern, and then select the new stitch pattern.
  • Page 91 SELECTING STITCH PATTERNS Press Press to display a selection screen of characters, and then select a character. Repeat this step until you have selected all of the characters. * If a wrong character was selected, press to erase the character, and then select the new character. * To select a different character style, press and then select the new character style.
  • Page 92: Sewing Stitch Patterns

    Thin paper Thread #50 - #60 Needle With lightweight, regular, or stretch fabrics: Brother ballpoint needle (golden colored) With heavyweight fabrics: home sewing machine needle 90/14 Presser foot Monogramming foot “N”. Using another presser foot may give inferior results.
  • Page 93: Adjusting Patterns

    SEWING STITCH PATTERNS Press the “Start/Stop” button to stop the Adjusting Patterns machine, and then press the “Reverse/ Reinforcement Stitch” button to sew reinforcement stitches. Depending on the type and thickness of the fabric being sewn, the sewing speed, whether or not stabilizer material is used, etc., the desired result may not be achieved.
  • Page 94 SEWING STITCH PATTERNS Press Sew the pattern again. If the pattern still is not sewn correctly, adjust it again. Continue making adjustments until the pattern is sewn correctly. Memo You can sew with the setting screen on the display. After the pattern is sewn correctly, quit making adjustments.
  • Page 95: Editing Stitch Patterns

    EDITING STITCH PATTERNS EDITING STITCH PATTERNS Using the editing functions, you can change the patterns in a variety of ways, such as resizing them or flipping them to create a mirror image. Memo Depending on the pattern that is selected, some editing functions may not be available. ■...
  • Page 96: Changing The Pattern Size

    EDITING STITCH PATTERNS Changing the Pattern Size Creating a Vertical Mirror Image After selecting a stitch pattern, press until the After selecting a stitch pattern, press to flip the desired size is selected. pattern vertically. Memo • Stitch patterns entered after the pattern size was changed are added at the selected size until it is changed again.
  • Page 97: Selecting A Single/repeating Pattern

    EDITING STITCH PATTERNS Selecting a Single/Repeating Pattern Changing the Thread Density (Satin Stitch Patterns Only) Press to select whether the pattern is sewn repeatedly or once. After selecting a stitch pattern, press until the desired stitching density is selected. CAUTION Memo •...
  • Page 98: Combining Stitch Patterns

    COMBINING STITCH PATTERNS COMBINING STITCH PATTERNS You can combine many varieties of stitch patterns, such as character stitches, cross stitches, satin stitches, or stitches you design with MY CUSTOM STITCH function (see chapter 7 for information about MY CUSTOM STITCH). You can also combine stitch patterns of different sizes, mirror image stitch patterns, and others.
  • Page 99: Combining Stitch Patterns Of Different Sizes

    COMBINING STITCH PATTERNS Press Combining Stitch Patterns of Different Sizes Example: Press Press To repeatedly sew the pattern combination, Press press so that it appears as → The larger size pattern appears. Memo • Press to erase the last pattern entered. Patterns are erased one at a time.
  • Page 100: Combining Stitch Patterns Of Different Orientations

    COMBINING STITCH PATTERNS Press Press again, and then press so that it appears as Press → The second pattern is displayed in the smaller size. To repeatedly sew the pattern combination, press so that it appears as Press again, and then press so that it →...
  • Page 101: Combining Stitch Patterns Of Different Lengths

    COMBINING STITCH PATTERNS To repeatedly sew the pattern combination, Combining Stitch Patterns of Different press so that it appears as Lengths Press → The combination appears as a repeating pattern. Memo • Press to erase the last pattern entered. Patterns are erased one at a time. •...
  • Page 102: Creating Step Patterns (7 Mm Satin Stitch Patterns Only)

    COMBINING STITCH PATTERNS Press again, and then press three Creating Step Patterns (7 mm Satin Stitch Patterns Only) times so that it appears as Stitch patterns that are shifted to create a step-shaped pattern are called step patterns. Step patterns can be created by using shift 7 mm satin stitch patterns.
  • Page 103: Examples Of Pattern Combinations

    COMBINING STITCH PATTERNS ■ Examples of Pattern Combinations Press , and then press → → → → → The next pattern is moved to the right. Press again, and then press → → → → → → → → → →...
  • Page 104: Using The Memory Function

    • Compatible operating systems: Microsoft Windows 98SE/Me/2000/XP Press (Windows 98SE requires a driver. Download the driver from our Web site (www.brother.com). In addition, only Windows 98 Second Edition can use the driver.) ■ Precautions on Using the Computer to Create and Save Data •...
  • Page 105: If The Memory Is Full

    USING THE MEMORY FUNCTION ■ If the Memory Is Full Select a stitch pattern to be deleted. If this screen appears while you are trying to save a * Press to display the pattern saved in that pattern on the machine’s memory, the memory is pocket.
  • Page 106: Saving Stitch Patterns To The Computer

    USING THE MEMORY FUNCTION Press Plug the USB cable connectors into the corresponding USB ports on the computer * If you decide not to delete the stitch pattern, press and on the machine. * The USB cable can be plugged into the USB ports on the computer and machine whether or not they are turned on.
  • Page 107: Retrieving Stitch Patterns From The Machine's Memory

    USING THE MEMORY FUNCTION Press Retrieving Stitch Patterns from the Machine’s Memory → Press to return to the previous screen without saving the stitch pattern. Press → The stitch pattern is temporarily saved to → The pocket selection screen appears. “Removable Disk”...
  • Page 108: Retrieving Stitch Patterns From The Computer

    USING THE MEMORY FUNCTION Move/copy the pattern data to “Removable Press Disk”. * Press to delete the stitch pattern. → Stitch pattern data in “Removable Disk” is written to the machine. → The selected stitch pattern is retrieved and the Note sewing screen appears.
  • Page 109 USING THE MEMORY FUNCTION * Press to return to the previous screen without saving the stitch pattern. CAUTION • When disconnecting the USB cable: Before disconnecting the USB cable, click the "Unplug or Eject Hardware" icon in the taskbar of ®...
  • Page 110: Chapter 5 Embroidery

    Chapter Embroidery BEFORE EMBROIDERING ......110 SEWING AN EMBROIDERING PATTERN ..131 Attaching Embroidery Foot “U”........111 Sewing Attractive Finishes ..........131 ■ Embroidery Needle Plate Cover ..........131 Attaching the Embroidery Unit ........112 Sewing Embroidery Patterns ..........132 ■ Removing the Embroidery Unit ..........113 Embroidering Appliqué...
  • Page 111: Before Embroidering

    BEFORE EMBROIDERING BEFORE EMBROIDERING The embroidering procedures are listed below. 6, 8 1, 2 Step # Operation Page Attach embroidery foot “U”. Insert a 75/11 home sewing machine needle.* Attach the embroidery unit. Wind the bobbin with embroidery bobbin thread, and then set the bobbin. 24,27 Attach stabilizer material to the fabric, and then hoop it in the embroidery frame.
  • Page 112: Attaching Embroidery Foot "u

    BEFORE EMBROIDERING Use the included screwdriver to loosen the Attaching Embroidery Foot “U” presser foot holder screw, and then remove the presser foot holder. CAUTION • When attaching a presser foot, always press in the operation panel. You may accidentally press the “Start/Stop” button and a Presser foot holder possibly cause injury.
  • Page 113: Attaching The Embroidery Unit

    BEFORE EMBROIDERING Insert the embroidery unit connector into the Attaching the Embroidery Unit connection port, and then lightly push in the embroidery unit until it snaps into place. CAUTION • Do not move the machine with the embroidery unit attached. The embroidery unit could fall off and cause injury.
  • Page 114: Removing The Embroidery Unit

    BEFORE EMBROIDERING ■ Removing the Embroidery Unit Press Press , and then press → The carriage moves to the storage position. CAUTION • Always remove the embroidery frame before pressing . Otherwise, the frame may strike the embroidery foot, and possibly cause injury. •...
  • Page 115: Selecting Embroidery Patterns

    SELECTING EMBROIDERY PATTERNS SELECTING EMBROIDERY PATTERNS ■ Copyright Information The embroidery patterns stored in the machine and on embroidery cards (sold separately) are intended for private use only. Any public or commercial use of copyrighted patterns is an infringement of copyright law and is strictly prohibited.
  • Page 116: One-point Patterns/floral Patterns

    SELECTING EMBROIDERY PATTERNS Continue with “VIEWING THE SEWING One-point Patterns/Floral Patterns SCREEN” on page 119. * To select a different embroidery pattern, press Select a type of embroidery pattern. . (After a confirmation message to delete the selected pattern appears, the pattern selection screen appears.) Select an embroidery pattern.
  • Page 117: Alphabet Patterns

    SELECTING EMBROIDERY PATTERNS Alphabet Patterns Press to display a selection screen of characters, and then select a Press character to be embroidered. * To change the size, press until the desired size is selected. * If a wrong character was selected, press erase the character.
  • Page 118: Frame Patterns

    SELECTING EMBROIDERY PATTERNS Continue with “VIEWING THE SEWING Frame Patterns SCREEN” on page 119. * To select a different character, press . (After Press a confirmation message to delete the selected pattern appears, the pattern selection screen In the top part of the screen, select a frame appears.) shape.
  • Page 119: Embroidery Cards

    SELECTING EMBROIDERY PATTERNS Continue with “VIEWING THE SEWING Press SCREEN” on page 119. * To select a different embroidery pattern, press . (After a confirmation message to delete the selected pattern appears, the pattern selection screen appears.) → The pattern selection screen for the card appears. Follow the procedure described in “One- point Patterns/Floral Patterns”...
  • Page 120: Viewing The Sewing Screen

    VIEWING THE SEWING SCREEN VIEWING THE SEWING SCREEN Using the editing keys, you can change the patterns in a variety of ways, such as resizing them or rotating them. Shows the code for the appropriate presser foot. When embroidering, be sure to use embroidery foot “U”.
  • Page 121: Preparing The Fabric

    PREPARING THE FABRIC PREPARING THE FABRIC CAUTION • Use fabrics with a thickness of less than 3 mm (approx. 1/8 inch). Using fabrics thicker than 3 mm (approx. 1/8 inch) may cause the needle to break. • When using layers with thicker batting etc., you can sew more attractive embroidery by adjusting the embroidery presser foot height in the embroidery settings screen (see below).
  • Page 122: Hooping Fabric In The Embroidery Frame

    PREPARING THE FABRIC Hooping Fabric in the Embroidery Frame ■ Types of Embroidery Frames Extra Large Large Medium (Sold Separately) Small (Sold Separately) Embroidering area: Embroidering area: Embroidering area: Embroidering area: 26 cm × 16 cm (approx. 10 - 1/4 18 cm ×...
  • Page 123: Inserting The Fabric

    PREPARING THE FABRIC ■ Inserting the Fabric Gently stretch the fabric, and then securely tighten the frame adjustment screw so that Note the fabric remains stretched. If the fabric is not taut, the pattern may be misaligned or the fabric may pucker. Follow the procedure described below to gently stretch the fabric in the embroidery frame so that the fabric is not loose.
  • Page 124: Embroidering Small Fabrics And Fabric Edges

    PREPARING THE FABRIC ■ Embroidering Small Fabrics Place the embroidery sheet in the inner frame, and then align the guide lines on the When embroidering small pieces of fabric, use embroidery sheet with the marks on the temporary spray adhesive to attach the small piece fabric.
  • Page 125: Attaching The Embroidery Frame

    ATTACHING THE EMBROIDERY FRAME ATTACHING THE EMBROIDERY FRAME Note Before attaching the embroidery frame, set the bobbin. Press the “Presser Foot Lifter” button to raise Lower the frame-securing lever so that it is level the presser foot. with the frame to secure the embroidery frame in the embroidery frame holder.
  • Page 126: Editing The Pattern

    EDITING THE PATTERN EDITING THE PATTERN CAUTION • After the size of the pattern has been changed, check the icons for the embroidery frames that can be used and use only the indicated frames. If a frame other those indicated is used, the presser foot may strike the embroidery frame, possibly causing injuries.
  • Page 127: Rotating The Pattern

    EDITING THE PATTERN Press to move the pattern. Press * Each press of the key rotates the pattern 90 degrees. * Press to move the pattern in the direction of the arrow on the key. * Press to center the pattern. a Degree of rotation Note •...
  • Page 128: Creating A Horizontal Mirror Image

    EDITING THE PATTERN Press Creating a Horizontal Mirror Image Press Change the size of the pattern. * Press to reduce the size of the pattern. Press * Press to enlarge the size of the pattern. * Press to return the pattern to its original size. →...
  • Page 129: Changing The Stitching Density (alphabet And Frame Patterns Only)

    EDITING THE PATTERN Changing the Stitching Density Changing the Color of Single (Alphabet and Frame Patterns Only) Characters Combined alphabet patterns can be sewn with each Press letter in a different color. If “MULTI COLOR” is set, the machine stops after each character is sewn so that the thread can be changed to one of a different color.
  • Page 130: Checking The Pattern

    CHECKING THE PATTERN CHECKING THE PATTERN Press to select the position to be Checking the Embroidering Position checked. The embroidery frame is moved to indicate the embroidering position. Closely watch the frame to check that the pattern will be sewn at the correct place. Press →...
  • Page 131: Previewing The Pattern

    CHECKING THE PATTERN Press to select the frame used Previewing the Pattern in the preview. * Embroidery frame icons that appear in dashed line Press cannot be selected. * Press to enlarge the preview of the embroidery pattern. Memo • Press the “Start/Stop” button to sew the pattern as it appears in this screen.
  • Page 132: Sewing An Embroidering Pattern

    SEWING AN EMBROIDERING PATTERN SEWING AN EMBROIDERING PATTERN Sewing Attractive Finishes There are many factors that go into sewing beautiful embroidery. Using the appropriate stabilizer (see page 120) and hooping the fabric in the frame (see page 121) are two important factors mentioned earlier. Another important point is the appropriateness of the needle and thread being used.
  • Page 133: Sewing Embroidery Patterns

    SEWING AN EMBROIDERING PATTERN Trim off the excess thread at the beginning of Sewing Embroidery Patterns the stitching. If the thread is hidden under the presser foot, raise the presser foot, and then cut the thread. Example: To embroider Press the “Start/Stop” button again to start embroidering.
  • Page 134: Embroidering Appliqué Patterns

    SEWING AN EMBROIDERING PATTERN After sewing is finished, remove the appliqué Embroidering Appliqué Patterns fabric from the embroidery frame, and then carefully cut along the stitching. There are some patterns which call for an appliqué inside the pattern. Note When sewing an embroidery pattern with an appliqué, Carefully cut out the appliqué...
  • Page 135: If The Bobbin Runs Out Of Thread

    SEWING AN EMBROIDERING PATTERN Apply a thin layer of adhesive or spray If the Bobbin Runs Out of Thread adhesive to the back of the appliqué piece, and then attach it to the base fabric at the appliqué position sewn in step If the bobbin begins to run out of thread during embroidering, the machine stops and the following message appears.
  • Page 136: If The Thread Breaks During Sewing

    SEWING AN EMBROIDERING PATTERN Press the “Presser Foot Lifter” button to lower Press to move the the presser foot. needle back 2 or 3 stitches before the point To return to the point in the pattern where where the thread broke. sewing was stopped, follow steps through in the next section.
  • Page 137: Restarting From The Beginning

    SEWING AN EMBROIDERING PATTERN Restarting from the Beginning Adjusting the Thread Tension When embroidering, the thread tension should be set so Press that the upper thread can be slightly visible from the wrong side of the fabric. With some fabric and thread combinations, the thread tension may need to be adjusted.
  • Page 138: Automatic Thread Cutting

    SEWING AN EMBROIDERING PATTERN ■ If the Upper Thread Is Too Tight Press The upper thread is too tight when the bobbin thread is visible from the right side of the fabric. Press in the tension display. * Each press of the key increases the value and tightens the upper thread tension.
  • Page 139: Changing The Embroidering Speed

    SEWING AN EMBROIDERING PATTERN Changing the Embroidering Speed Changing the Thread Color Display From the following, select the thread color that appears Press in the embroidery color order display. You can change the thread color display on embroidery screen, to the Press in the “MAX EMBROIDERY thread color name, each time to embroider or the...
  • Page 140 SEWING AN EMBROIDERING PATTERN Example: Displaying the thread number of Press “EMBROIDERY” Press Press beside on P. 2 of the screen to select the “#123”. → The thread color display is changed. → “EMBROIDERY” appears at the bottom. Press to select the thread brand. Memo Colors on the screen may vary slightly from actual spool colors.
  • Page 141: Using The Memory Function

    • Compatible operating systems: Microsoft Windows 98SE/Me/2000/XP (Windows 98SE requires a driver. Download the driver from our Web site (www.brother.com). In addition, only Windows 98 Second Edition can use the driver.). ■ Precautions on Using the Computer to Create and Save Data •...
  • Page 142: Saving Embroidery Patterns In The Machine's Memory

    USING THE MEMORY FUNCTION ■ If the Memory Is Full Saving Embroidery Patterns in the If the following screen appears, either the maximum Machine’s Memory number of patterns have been saved or the pattern that you want to save takes a lot of memory, and the machine cannot save it.
  • Page 143: Saving Embroidery Patterns To The Computer

    USING THE MEMORY FUNCTION Press Saving Embroidery Patterns to the Computer Using the included USB cable, connect the sewing machine to your computer so that embroidery patterns can be retrieved from and saved to your computer. Note Do not turn off the machine while the “Saving” screen is displayed, otherwise you may lose the pattern that you are saving.
  • Page 144: Retrieving Patterns From The Machine's Memory

    USING THE MEMORY FUNCTION With the pattern that you want to save Retrieving Patterns from the displayed in the sewing screen, press Machine’s Memory Press Press * Press to return to the previous screen without saving the pattern. → The pocket selection screen appears. Select a pattern to be retrieved.
  • Page 145: Retrieving Patterns From The Computer

    USING THE MEMORY FUNCTION Press Retrieving Patterns from the Computer Plug the USB cable connectors into the corresponding USB ports on the computer and on the machine (see page 142). The “Removable Disk” icon appears in “My Computer” on the computer. →...
  • Page 146 USING THE MEMORY FUNCTION Press Press → The pattern selection screen appears. a Amount of memory used by the selected pattern → The sewing screen appears. Select an embroidery pattern to be retrieved. * If you decide not to retrieve the pattern, press Β...
  • Page 147: Embroidery Applications

    EMBROIDERY APPLICATIONS EMBROIDERY APPLICATIONS Apply a thin layer of fabric glue or temporary Using a Frame Pattern to Make an spray adhesive to the back of the appliqué piece cut out in step , and then attach the Appliqué (1) appliqué...
  • Page 148: Using A Frame Pattern To Make An Appliqué (2)

    EMBROIDERY APPLICATIONS Remove the embroidery frame from the Using a Frame Pattern to Make an machine, and then cut around the outside of the stitching. Appliqué (2) This is a second method for making appliqués using embroidery patterns. With this method, there is no need to change the fabric in the embroidery frame.
  • Page 149 EMBROIDERY APPLICATIONS LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 150: Chapter 6 Embroidery Edit

    Chapter Embroidery Edit AVAILABLE EDITING FUNCTIONS...........150 ■ Combined Patterns ......................150 ■ Move Patterns .......................150 ■ Rotate Patterns ......................150 ■ Enlarge or Reduce Patterns....................150 ■ Create Mirror Images ....................150 ■ Change Character Spacing ....................150 ■ Change Character Appearance/Layout................150 SELECTING PATTERNS TO EDIT ............151 Selecting One-point Patterns/Floral Patterns/Frame Patterns .......151 Alphabet Patterns....................152 EDITING PATTERNS................154...
  • Page 151: Available Editing Functions

    AVAILABLE EDITING FUNCTIONS AVAILABLE EDITING FUNCTIONS With the Embroidery Edit functions, you can change the size of patterns, rotate patterns, adjust the character spacing and layout, and perform many other editing operations. In addition, characters and patterns can be combined and rearranged within the 26 cm ×...
  • Page 152: Selecting Patterns To Edit

    SELECTING PATTERNS TO EDIT SELECTING PATTERNS TO EDIT Attach the embroidery unit, prepare the machine for embroidering according to the instructions on page 110, and then press to display the screen shown below. One-point patt erns One-point patterns Memo Floral patterns Alphabet patterns For details on the pattern selection screen, see page 114 or the Quick Reference Guide.
  • Page 153: Alphabet Patterns

    SELECTING PATTERNS TO EDIT Press Alphabet Patterns With the Embroidery Edit functions, you can edit the appearance of a character at the same time that you enter it. Press → The selected pattern appears in the screen. Continue with “EDITING PATTERNS” on page 154.
  • Page 154 SELECTING PATTERNS TO EDIT Press to change the layout of the Press pattern. → The embroidery edit screen appears. Layout of characters Continue with see “EDITING PATTERNS” on Memo page 154. The layout of the characters appears in the upper-left corner of the screen.
  • Page 155: Editing Patterns

    EDITING PATTERNS EDITING PATTERNS Shows the size of the entire combined pattern. Shows the size of the pattern currently selected. Shows the distance from the center of frame. Shows the degree of rotation for the selected pattern. ■ Key Functions Name Function Page...
  • Page 156: Moving The Pattern

    EDITING PATTERNS Select the angle that the pattern is rotated. Moving the Pattern * Press to rotate the pattern 90 degrees to the left. Press to move the pattern in the direction * Press to rotate the pattern 90 degrees to the right.
  • Page 157: Changing The Size Of The Pattern

    EDITING PATTERNS Changing the Size of the Pattern Press Press Select the direction in which the size is changed. * Press to reduce the pattern proportionately. * Press to enlarge the pattern proportionately. * Press to reduce the pattern vertically. * Press to enlarge the pattern vertically.
  • Page 158: Changing The Configuration Of Character Patterns

    EDITING PATTERNS Changing the Configuration of Changing the Character Spacing Character Patterns Press Press Press Select the layout. * Press to widen the character spacing. * After selecting an arc layout, press * Press to tighten the character spacing. expand the arc. * After selecting an arc layout, press * Press to return the pattern to its original...
  • Page 159: Changing The Color Of Each Character In A Pattern

    EDITING PATTERNS Press to embroider the edited Changing the Color of Each Character in a Pattern pattern. * Press to return to the embroidery edit screen. Press so that it appears as . The machine will stop after each character is embroidered so the thread can be changed.
  • Page 160: Combining Patterns

    COMBINING PATTERNS COMBINING PATTERNS This section will describe how to combine characters and embroidery patterns. Press Editing Combined Patterns Press Press Press on P. 1 of the screen. LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 161 COMBINING PATTERNS Press Enter “WELCOME”. * For details on selecting characters, see page 116. * After entering “W“, press to change the size to M, then enter the remaining characters. * Press to view an image of all entered characters. Press Press LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P.
  • Page 162 COMBINING PATTERNS Press to change the layout of the Press characters. * For details, see page 157. Press Press to adjust the position of the characters. LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 163: Sewing Combined Patterns

    USING THE MEMORY FUNCTION Sewing Combined Patterns Embroider according to the color order on the right side of the screen. Combined patterns will be embroidered in the order that they were entered. In this example, the embroider order will be as follows. For details, see “Sewing Embroidery Patterns”...
  • Page 164: Chapter 7 My Custom Stitch

    Chapter MY CUSTOM STITCH DESIGNING A STITCH..............164 ■ Examples of Custom Stitches ..................165 ENTERING STITCH DATA ..............166 ■ Key Functions ........................166 ■ Moving a Point ......................168 ■ Moving Part or All of the Design ...................169 ■ Inserting New Points .....................170 USING STORED CUSTOM STITCHES ..........171 Saving Custom Stitches in the Machine’s Memory ..........171 ■...
  • Page 165: Designing A Stitch

    DESIGNING A STITCH DESIGNING A STITCH Decide the spacing of the stitch. ™ By using the MY CUSTOM STITCH function, you can register stitches you have created yourself. * By adjusting the spacing of a stitch, you can create various patterns with one stitch.
  • Page 166: Examples Of Custom Stitches

    DESIGNING A STITCH ■ Examples of Custom Stitches Stitch Stitch Stitch Stitch Stitch Stitch Stitch Stitch Stitch Stitch Stitch Stitch LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 167: Entering Stitch Data

    ENTERING STITCH DATA ENTERING STITCH DATA ■ Key Functions This area displays the stitch being created. Displays the number of the present set point over the total number of points in the stitch. Displays the y-coordinate of over the x-coordinate of Display Key Name Explanation...
  • Page 168 ENTERING STITCH DATA Press Press to add the point indicated by Press Select whether one stitch or three stitches will be sewn between the first two points. * To sew three stitches, press the key so that it appears as to move to the coordinates of the first point on the grid sheet.
  • Page 169: Moving A Point

    ENTERING STITCH DATA ■ Moving a Point Press Press to move to the point that you want to move. * To move to the first point, press * To move to the last point, press * You can also move by using the touch pen.
  • Page 170: Moving Part Or All Of The Design

    ENTERING STITCH DATA ■ Moving Part or All of the Design Press to move the section. Press to move to the first point of the section that you want to move. * To move to the first point, press * To move to the last point, press * You can also move by using the touch pen.
  • Page 171: Inserting New Points

    ENTERING STITCH DATA ■ Inserting New Points Press to move to a place on to move the point. the design where you want to add a new point. * To move to the first point, press * To move to the last point, press * You can also move by using the touch pen.
  • Page 172: Using Stored Custom Stitches

    USING STORED CUSTOM STITCHES USING STORED CUSTOM STITCHES Press Saving Custom Stitches in the * Press to return to the previous screen without Machine’s Memory saving the custom stitch. Stitch patterns created using the MY CUSTOM STITCH™ function can be saved for later use. The machine’s memory can hold up to 16 custom stitches.
  • Page 173: Saving Custom Stitches To The Computer

    USING STORED CUSTOM STITCHES Select a custom stitch to be deleted. Press * If you decide not to delete the custom stitch, press * Press to display the custom stitch saved in that pocket. If the entire saved custom stitch cannot be displayed, press to view the entire custom stitch.
  • Page 174: Retrieving Custom Stitches From The Machine's Memory

    USING STORED CUSTOM STITCHES Press Retrieving Custom Stitches from the * Press to delete the custom stitch. Machine’s Memory Press → The selected custom stitch is retrieved and the sewing screen appears. → The pocket selection screen appears. Retrieving Custom Stitches from the Computer Select a custom stitch to be retrieved.
  • Page 175 USING STORED CUSTOM STITCHES LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 176: Chapter 8 Appendix

    Chapter Appendix CARE AND MAINTENANCE ..............176 Cleaning the LCD ....................176 Cleaning the Machine Casing ................176 Cleaning the Race ....................176 ADJUSTING THE SCREEN ..............178 Screen Visibility Is Low ..................178 Touch Panel Is Malfunctioning ................178 TROUBLESHOOTING ...............180 ERROR MESSAGES................183 ■ Alarm ..........................187 SPECIFICATIONS................188 UPGRADING YOUR MACHINE’S SOFTWARE .........189 LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P.
  • Page 177: Care And Maintenance

    CARE AND MAINTENANCE CARE AND MAINTENANCE CAUTION • Be sure to unplug the machine before cleaning it. Otherwise, electric shock or injury may result. Grasp the bobbin case, and then pull it out. Cleaning the LCD If the surface of the LCD is dirty, lightly wipe it with a soft dry cloth.
  • Page 178 • For a new bobbin case (part code: XC3153- 151(green marking on the screw) (for sewing and embroidering with bobbin thread recommended by Brother) or XC8167-151 (pink marking on the screw) (for embroidering with bobbin threads from other manufacturers)), contact your nearest authorized dealer (see page 131).
  • Page 179: Adjusting The Screen

    ADJUSTING THE SCREEN ADJUSTING THE SCREEN Screen Visibility Is Low Touch Panel Is Malfunctioning If the screen is difficult to read when the machine is If the screen does not respond correctly when a key is turned on, follow the procedure described below. pressed (the machine does not perform the operation or performs a different operation), follow the procedure Turn off the machine, hold your finger...
  • Page 180 ADJUSTING THE SCREEN Using the included touch pen, lightly touch × the center of each , in order from 1 to 5. * If the buzzer sounds one time after you press number 5, the operation is finished, and “SUCESS” appears on the screen.
  • Page 181: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING If you have a minor problem with your sewing machine, check the following solutions. If the solutions suggested do not correct the problem, contact your authorized dealer. Memo This machine is equipped with a simple troubleshooting feature that can be used in case minor problems occur during sewing.
  • Page 182 TROUBLESHOOTING Problem Cause Solution Page High-pitched sound while Dust or lint is caught in the feed dogs. Remove the dust or lint. sewing Pieces of thread are caught in the race. Clean the race. The upper threading is incorrect. Check the procedure for threading the machine and rethread it correctly.
  • Page 183 TROUBLESHOOTING Problem Cause Solution Page Needle breaks The needle is installed incorrectly. Reinstall the needle correctly. The needle clamp screw is not tightened. Tighten the needle clamp screw. The needle is bent or blunt. Replace the needle with a new one. The thread or needle is not suitable for the type Check the table of fabric, thread and needle of fabric being sewn.
  • Page 184: Error Messages

    ERROR MESSAGES ERROR MESSAGES If the “Start/Stop button” or the “Reverse/Reinforcement Stitch” button is pressed before the machine is correctly set up or if an incorrect operation is performed, the machine stops and informs you of the error with an alarm and an error message.
  • Page 185 ERROR MESSAGES This message is displayed when This message is displayed when the pattern selected in embroidery the “Start/Stop” button is pressed mode is larger than the while a pattern is being edited in embroidering area of the medium embroidery edit mode. embroidery frame while the small or medium embroidery frame is attached.
  • Page 186 ERROR MESSAGES This message is displayed when This message is displayed when a more than 12 patterns have been stitch other than a buttonhole stitch saved in “Removable Disk”. is selected and the “Start/Stop” button or the “Reverse/ Reinforcement Stitch” button is pressed while the buttonhole lever is lowered.
  • Page 187 ERROR MESSAGES This message is displayed when This message is displayed when the bobbin thread is running out. you try to retrieve a pattern downloaded as one for a different machine. This message is displayed when This message is displayed when the bobbin is being wound, and the the combined character pattern in motor locks because the thread is...
  • Page 188: Alarm

    ERROR MESSAGES This message is displayed when This message is displayed when a the motor locks up due to tangled button on the screen is pressed thread or for other reasons related while the needle is lowered. to thread delivery. If data is being written to or deleted This message is displayed when from “Removable Disk”...
  • Page 189: Specifications

    SPECIFICATIONS SPECIFICATIONS Item Specification 51.1 cm (W) × 30.5 cm (H) × 25.8 cm (D) (approx. 20-1/8 inches Sewing Machine Dimensions (W) × 12 inches (H) × 10-1/8 inches (D)) 58.2 cm (W) × 31.9 cm (H) × 28.4 cm (D) (approx. 22-7/8 inches Case dimensions (W) ×...
  • Page 190: Upgrading Your Machine'ssoftware

    UPGRADING YOUR MACHINE’S SOFTWARE UPGRADING YOUR MACHINE’S SOFTWARE You can use a computer to download software upgrades for your sewing machine. Note There are two upgrade files. Be sure to download both files successively. Memo • When the machine’s software is upgraded, saved combinations of character and decorative stitches are erased. However, saved embroidery patterns are not erased.
  • Page 191 UPGRADING YOUR MACHINE’S SOFTWARE When the following screen appears, upgrading is completed. Press LOAD after saving the upgrade file in the machine. Upgrade complete. Note If an error occurred, an error message appears in red. At this time, turn the machine off, and then start the procedure again from step Disconnect the USB cable, and turn the machine off, then on again.
  • Page 192: Stitch Setting Chart

    Stitch Setting Chart STITCH SETTING CHART Note When using the twin needle (see page 31), be sure to attach presser foot “J”. Stitch Width Stitch Length Stitch Presser Twin [mm (inch)] [mm (inch)] Stitch Name Applications Foot Needle Auto Manual Auto Manual Straight stitch (Left)
  • Page 193 Stitch Setting Chart Stitch Width Stitch Length Stitch Presser Twin [mm (inch)] [mm (inch)] Stitch Name Applications Foot Needle Auto Manual Auto Manual Overcasting stitch Reinforcing of heavyweight 2.5 - 5.0 1.0 - 4.0 fabric (3/16) (3/32 - 3/16) (3/32) (1/16 - 3/16) Overcasting stitch Reinforcing of medium,...
  • Page 194 Stitch Setting Chart Stitch Width Stitch Length Stitch Presser Twin [mm (inch)] [mm (inch)] Stitch Name Applications Foot Needle Auto Manual Auto Manual Blind hem stitch Hemming woven fabrics 1.0 - 3.5 3← − →3 (1/16) (1/16 - 1/8) Blind hem stitch Hemming stretch fabric 1.0 - 3.5 3←...
  • Page 195 Stitch Setting Chart Stitch Width Stitch Length Stitch Presser Twin [mm (inch)] [mm (inch)] Stitch Name Applications Foot Needle Auto Manual Auto Manual Hemstitching Decorative hems, triple straight 1.0 - 7.0 1.5 - 4.0 at left (1/16) (1/16 - 1/4) (3/32) (1/16 - 3/16) ( J )
  • Page 196 Stitch Setting Chart Stitch Width Stitch Length Stitch Presser Twin [mm (inch)] [mm (inch)] Stitch Name Applications Foot Needle Auto Manual Auto Manual Hemstitching Decorative hems, smocking 1.5 - 7.0 1.0 - 4.0 (15/ (1/16 - 1/4) (1/16) (1/16 - 3/16) Hemstitching Decorative hems, smocking 1.5 - 7.0...
  • Page 197 Stitch Setting Chart Stitch Width Stitch Length Stitch Presser Twin [mm (inch)] [mm (inch)] Stitch Name Applications Foot Needle Auto Manual Auto Manual Reverse (Straight) For attaching appliqué on tubular pieces of fabric and mitering — — — — corners Diagonally right up For attaching appliqué...
  • Page 198: Index

    Index INDEX elastic zigzag stitches ..............57 elongation key ................95 accessories ..................11 embroidery air vent ...................9 corners ................... 123 alarm ..................187 automatic thread cutting ............137 alphabet patterns key functions ................119 character/decorative stitches .............89 restarting from the beginning ..........136 appliqués ..............56 ribbons ...................
  • Page 199 Index horizontal mirror image key ..........95 presser foot code ..............17 presser foot holder ..............10 presser foot lever ..............9 presser foot lifter button ............11 image key ................130 presser foot/needle exchange key ......31 insert key ..................170 pretension disk ...............
  • Page 200 Index thread cutter ................9 thread cutter button ............11 thread density key ............. 128 thread guide ..............9 thread guide plate ............. 9 thread take-up lever check window ........9 thread tension ..............43 top cover ..................9 topstitching ...................69 touch pen ................13 holder ..................9 trial key ..................129 upgrading ...................189...
  • Page 201 LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 202 Quick Reference Guide Stichwortregister Guide de référence rapide Beknopte bedieningsgids Guida di riferimento rapido Guía de referencia rápida LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 203 Refer to the operation manual for detailed instruction. Also, there are differences in the keys and screens depending on the display language. In this guide, English screens are used for basic explanations. Einzelheiten entnehmen Sie bitte der Bedienungsanleitung. Je nachdem, welche Sprache für die Bildschirmanzeigen gewählt wurde, ergeben sich im Hinblick auf Tasten Schirmbilder eventuell Unterschiede.
  • Page 204 Contents Inhalt Winding the Bobbin............2 Aufspulen des Unterfadens ........... 2 Setting the Bobbin ............2 Einsetzen der Spule............2 Upper Threading ............3 Einfädeln des Oberfadens ..........3 Preparing to Embroider ..........4 Vorbereitung zum Sticken ..........4 Selecting Stitch Patterns ..........6 Wahl des Nähmusters ...........
  • Page 205: Bobinage De La Canette

    Winding the Bobbin Aufspulen des Unterfadens Bobinage de la canette Spoel opwinden Avvolgimento della spolina Devanado de la bobina Follow the numbered steps below in order. Refer to the operation manual for detailed instruction. Führen Sie die folgenden Schritte in der angegebenen Reihenfolge aus. Ausführliche Hinweise finden Sie in der Bedienungsanleitung. Suivez les étapes numérotées ci-dessous dans l'ordre.
  • Page 206 Upper Threading Einfädeln des Oberfadens Enfilage supérieur Inrijgen van de bovendraad Infilatura superiore Hilo superior LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 207 Preparing to Embroider Vorbereitung zum Sticken Préparation de la broderie Voorbereidingen voor borduren Preparativi per il ricamo Preparativos para bordar LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 208 LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 209: Selezione Degli Schemi Punto

    Selecting Stitch Patterns Wahl des Nähmusters Sélection des configurations de point Kiezen van de steekpatronen Selezione degli schemi punto Selección de tipos de puntada NUtility Stitches NNutzstiche NPoints utilitaires When switching on machine, the screen Nach dem Einschalten der Maschine Lorsque vous mettez la machine sous will display the name of the machine.
  • Page 210 NEmbroidery Patterns NStickmuster NMotifs de broderie NBorduurpatronen NSchemi di ricamo NPatrones de bordado NEmbroidery Edit Patterns NEditieren von Stickmustern NMotifs de modification de broderie NBorduurbewerkingspatronen NSchemi di modifica ricamo NPatrones de edición de bordado LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 211 Selecting Stitch Patterns Wahl des Nähmusters Sélection des configurations de point Kiezen van de steekpatronen Selezione degli schemi punto Selección de tipos de puntada NOthers NSonstige NAutres NOverige NAltro NOtros LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 212: Summary Of Stitch Patterns

    Summary of Stitch Patterns Nähmuster-Übersicht Sommaires des motifs de point Overzicht van de steekpatronen Sommario degli schemi punto Resumen de tipos de puntada NUtility Stitches NNutzstiche NPoints utilitaires NNaaisteken NPunti utili NPuntadas utiles NCharacter/Decorative Stitches NZeichenstichmuster/Dekorative Stichmuster NCaractères/points décoratifs NLetter/decoratieve steken NPunti per caratteri/decorazioni NPuntadas de letras/decorativas LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P.
  • Page 213 LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 214: Sommario Degli Schemi Di Ricamo

    Summary of Stitch Patterns Nähmuster-Übersicht Sommaires des motifs de point Overzicht van de steekpatronen Sommario degli schemi punto Resumen de tipos de puntada Summary of Embroidery patterns Stickmuster-Übersicht Sommaires des motifs de broderie Overzicht van de borduurpatronen Sommario degli schemi di ricamo Resumen de patrones de bordado LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P.
  • Page 215 LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 216 Summary of Embroidery patterns Stickmuster-Übersicht Sommaires des motifs de broderie Overzicht van de borduurpatronen Sommario degli schemi di ricamo Resumen de patrones de bordado LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 217: Embroidery Pattern Color Change Table

    Embroidery Pattern Color Change Table Stickmuster-Farbtabelle Tableau de changement de couleur des motifs de broderie Kleurwijzigingstabel voor de borduurpatronen Tabella di cambiamento colori degli schemi di ricamo Tabla de cambio de color para patrones de bordado NEmbroidery patterns NStickmuster NMotifs de broderie NBorduurpatronen NSchemi di ricamo NPatrones de bordado...
  • Page 218 No.15 No.20 No.25 13min 4min 2min (534) (473) (473) (800) (604) (604) (070) (624) Size (307) (354) 9.5cm 2.8cm (019) (706) COUNTRY (030) Size Size 6.2cm 3.8cm 8.8cm 8.8cm COUNTRY No.16 8min No.26 8min (079) No.21 2min (124) (328) (336) (323) Size (126)
  • Page 219 No.30 No.35 No.40 10min 16min 23min (513) (001) (001) (323) (010) (307) (534) (707) (707) (515) (030) (900) (534) (900) (515) (030) Size Size Size 7.7cm 9.7cm 6.0cm 8.8cm 7.7cm 9.5cm No.31 No.36 4min 16min No.41 19min (513) (208) (507) (001) (010) (800)
  • Page 220 Embroidery Pattern Color Change Table Stickmuster-Farbtabelle Tableau de changement de couleur des motifs de broderie Kleurwijzigingstabel voor de borduurpatronen Tabella di cambiamento colori degli schemi di ricamo Tabla de cambio de color para patrones de bordado No.45 No.50 No.56 7min 1min 4min (010)
  • Page 221 Embroidery Pattern Color Change Table Stickmuster-Farbtabelle Tableau de changement de couleur des motifs de broderie Kleurwijzigingstabel voor de borduurpatronen Tabella di cambiamento colori degli schemi di ricamo Tabla de cambio de color para patrones de bordado NFloral patterns NBlumenmuster NMotifs floraux NBloempatronen NSchemi floreale NPatrones en motivo floral...
  • Page 222 Color Thread Conversion Chart Stickgarn-Farbtabelle Tableau de conversion des fils de couleur Omzettingstabel voor kleurgaren Tabella di conversione dei fili colorati Tabla de conversión de hilos de color Madeira Madeira Sulky R.A. Color Name Embroidery Country Polyneon Rayon Rayon Polyster 1800 1000 1005...
  • Page 223 Color Thread Conversion Chart Stickgarn-Farbtabelle Tableau de conversion des fils de couleur Omzettingstabel voor kleurgaren Tabella di conversione dei fili colorati Tabla de conversión de hilos de color Madeira Madeira Sulky R.A. Embroidery Country Polyneon Rayon Rayon Polyster Fresh Green / Frisch Grün / Vert Frais / Licht Groen 1706 1102 1209...
  • Page 224 LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245...
  • Page 225 882-U70/U71 LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur XD0556-051 Tel: 03-91025766/ 5767 Fax: 03-91025768 H/P: 012-6552245 Printed in Taiwan...

This manual is also suitable for:

Nv1500dNv1500

Comments to this Manuals

Symbols: 0
Latest comments:
  • venkat Mar 21, 2017 02:47:
    nice site out here this can be used for good embroidery designs
