Attaching Embroidery Foot "U"

• When attaching a presser foot, always press
accidentally press the "Start/Stop" button and
possibly cause injury.
• Be sure to use embroidery foot "U" when doing
embroidery. Using another presser foot may cause
the needle to strike the presser foot, causing the
needle to bend or break and possibly cause injury.
LSN
a
Press the "Needle Position" button to raise
the needle.
b
Press
→ The Presser foot/Needle exchange screen appears
and all keys and operation buttons are locked.
c
Raise the presser foot lever.
d
Press the black button on the presser foot
holder to remove the presser foot.
a
a Black button
b Presser foot holder
LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur
CAUTION
in the operation panel. You may
.
b
Tel: 03-91025766/ 5767
e
Use the included screwdriver to loosen the
presser foot holder screw, and then remove
the presser foot holder.
a Presser foot holder
b Screwdriver
c Presser foot holder screw
f
Attach embroidery foot "U" so that the
presser foot holder screw fits into the notch in
the foot.
* Make sure that embroidery foot "U" is vertical when
it is installed.
g
Hold the embroidery foot in place with your
right hand, and then use the included
screwdriver to securely tighten the presser
foot holder screw.
• Use the included screwdriver to firmly tighten the
screw of the presser foot holder. If the screw is loose,
the needle may strike the presser foot and possibly
cause injury.
h
Press
screen that appeared.
→ All keys and operation buttons are unlocked, and the
previous screen is displayed.
Fax: 03-91025768 H/P: 012-6552245
BEFORE EMBROIDERING
a
b c
CAUTION
, or in the
5
