Brother computerized sewing and embroidery machine Operation Manual page 36

c
Use the included screwdriver to turn the
needle clamp screw toward the front of the
machine to loosen it, and then remove the
needle.
Note
LSN
Do not apply extreme force when loosening or
tightening the needle clamp screw, otherwise damage
to the machine may result.
d
With the flat side of the needle facing the
back, insert the new needle until it touches
the needle stopper. Use the screwdriver to
securely tighten the needle clamp screw.
a
a
Needle stopper
b
Hole for setting the needle
c
Flat side of needle
• Be sure to push in the needle until it touches the
stopper, and securely tighten the needle clamp
screw with a screwdriver. If the needle is not
completely inserted or the needle clamp screw is
loose, the needle may break or the machine may be
damaged.
e
Press
screen.
→ All keys and operation buttons are unlocked, and
the previous screen is displayed.
LINGS SERVICE NETWORK (M) SDN BHD, NO 24 Jalan Damai Perdana 1/8C, Bandar Damai Perdana, 56000 Cheras, W.P. Kuala Lumpur
b
c
CAUTION
, or press
Tel: 03-91025766/ 5767
in the
Fax: 03-91025768 H/P: 012-6552245
CHANGING THE NEEDLE
1
35
