Bad/No Symbol Qualification
2D Symbology Qualification
Note: in the cases where Symbol Size Status, Dimension Status, or Orientation Status
is enabled, the reader will always check the finder pattern regardless of Finder Pattern
Status setting.

Finder Pattern Status

Definition: Checks for the presence of finder pattern.
<K718,finder pattern
Serial Cmd: 2,symbol size tolerance,dimension mode,dimension 1,dimension 2,dimen-
sion tolerance,orientation mode,orientation value>
Default: Disabled
Options: 0 = Disabled

Symbol Size Mode (2D Symbology Qualification)

Note: if Symbol Size 1 is larger than Symbol Size 2, it will be automatically reversed in
the algorithm.
Specifies the outputs resulting from the results of searches for Symbol Size
Definition:
1 and Symbol Size 2.
<K718,finder pattern
Serial Cmd: 2,symbol size tolerance,dimension mode,dimension 1,dimension 2,dimen-
sion tolerance,orientation mode,orientation value>
Default: Disabled
0 = Disabled
1 = Bad/No Symbol Output
Options:
2 = Object Qualification
3 = Enable Both
Disabled
Decoded messages are output, but no attempt to qualify symbols or output Bad or No
Symbol messages is undertaken.
Bad/No Symbol Output
Checks first for decodes. If no symbol is decoded, checks for symbol size. If both Symbol
Size 1 and Symbol Size 2 requirement are met, a Bad Symbol message is output. If both
are not met, outputs a No Symbol message.
Object Qualification
Checks first for matches to symbol size. If qualified, attempts to decode. If no decodes are
found within the specified read cycle parameters, outputs a Noread message.
Enable Both
Same as Object Qualification, except that if no objects qualify, then a No Symbol message
is output; if at least one object qualifies, then a Bad Symbol message is output.
5-12
status,symbol size mode,symbol size 1,symbol size
1 = Enabled
status,symbol size mode,symbol size 1,symbol size
