HawkEye™ 40T User Manual
Rev 2.0.0, Jan 2009
EM-20954-1V200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HawkEye 40T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microscan HawkEye 40T

Summary of Contents for Microscan HawkEye 40T

  • Page 1 HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 EM-20954-1V200...
  • Page 2 Copyright and Disclaimer Copyright ©2009 by Microscan Systems, Inc. 1201 S.W. 7th Street, Renton, WA, U.S.A. 98057 (425) 226-5700 FAX: (425) 226-8682 All rights reserved. The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and/or service Microscan manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Microscan.
  • Page 3 permitted by law, this express warranty excludes all other warranties, express or implied, including but not limited to, implied warranties of merchantability and. Technical support questions may be directed to: helpdesk@microscan.com Register your product with Microscan: www.microscan.com/register fitness for a particular purpose. Microscan Systems Inc.

  • Page 5: Table Of Contents

    USB Cable Installation 1-13 USB Communication Settings 1-14 PS2 Cable Installation 1-15 PS2 Communication Settings 1-16 RS-232 Cable Installation 1-17 RS-232 Communication Data Bit Settings 1-19 RS-232 Communication Stop Bit Settings 1-19 Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 6 Code 39 Symbology 3-3 Code 93 Symbology 3-4 Code 128 Symbology 3-4 Interleaved 2 of 5 Symbology 3-5 PDF 417 Symbology 3-5 QR Code Symbology 3-6 UPC/EAN/JAN 3-7 All 1D Bar Codes 3-8 HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...
  • Page 7 Prefix Settings 7-1 Suffix Settings 7-3 Erase Prefix and Suffix Settings 7-4 Maintenance and Troubleshooting CHAPTER 8 Reset Reader to Factory Defaults 8-1 General Safety Information 8-2 HE40T Accessories 8-3 HE40T Maintenance 8-3 Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 8 Certification and Specifications APPENDIX B CE Compliance B-1 FCC Statement B-2 FDA Statement B-3 Safety Guidelines B-3 Specifications B-4 HawkEye™ 40T B-4 Physical Characteristics B-4 Performance Characteristics B-4 User Environment B-5 Index Index-1 HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 viii...

  • Page 9: Preface

    LASER RADIATION - AVOID LONG TERM VIEWING OF DIRECT LASER RADIATION - LASER CLASS 2M Wavelength 630 nm - Maximum radiant power: < 1mW EN 60825-1:2003 Note: LED Lighting Light Emitting Diode Class 1 according to EN 60825-1:2003 Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...

  • Page 10: Manual Conventions

    The following typographical conventions are used throughout this manual: • Items emphasizing important information are bolded. • Menu selections, menu items and entries in screen images are indicated as: Operation, Configure, etc. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 11: Getting Started

    Getting Started CHAPTER 1 The HawkEye™ 40T (HE40T) is a revolutionary new low cost bar code reader that employs Microscan’ industry leading Direct Part Mark (DPM) reading technology. Developed to be the first universal reader, no other single device performs as many functions. With a cost of ownership far less than comparable systems, the HE40T incorporates a unique dual path optical system, a 1.3 million...

  • Page 12: Unpacking

    • CodeXML Bluetooth modem Please keep your packing materials. The HE40T is shipped in an approved shipping container and should be used if you ever need to return your equipment for servicing. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 13: Attaching The H2 Cabled Handle

    The HE40T uses the battery compartment to “snap to” the handle. Figure 1–1 shows the H2 handle with flexible connector. Figure 1–2 shows the battery blank. H2 Handle with Flexible Connector FIGURE 1–1. Flexible Connector H2 Handle with Battery Blank FIGURE 1–2. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 14 Figure 1–3. The HE40T can be secured further with threaded screws on the under side of the handle, and on the end of the flexible connector, as shown in Figure 1–4. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 15: Attaching The Bh1/Bh2 Battery Handle

    The HE40T uses the battery compartment to “snap to” the handle. The BH1/BH2 handle is shown in Figure 1–5. The handle with battery is shown in Figure 1–6 BH1/BH2 Handle FIGURE 1–5. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 16 Insert the tab on the back of the handle into the reader, as shown in Figure 1–7. Snap the reader onto the handle, matching the battery compartment to the battery connectors, visible inside the handle, as shown in Figure 1–7. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...
  • Page 17 Attaching the BH1/BH2 Handle FIGURE 1–7. The HE40T can be secured further with threaded screws on the under side of the handle, as shown in Figure 1–8. Location of Threaded Screws FIGURE 1–8. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...

  • Page 18: Charging The Lithium Ion Battery

    Log Only Mode — In Log Only Mode, the reader will only store data into non volatile memory. You can only retrieve the data by scanning the Transfer All Stored Data in Memory code (see “Transferring and Deleting Data” on HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 19: Feedback

    There are three different codes to transfer and delete data in memory: • Transfer All Data in Memory — This code will send all data in memory every time the code is scanned. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...

  • Page 20: Auto Transfer Buffer Memory

    Send & Log Mode Mode (Default) Transfer Only Unsent Delete Scanned Data Transfer All Data Data in Memory from Memory in Memory Enable Auto Transfer Disable Auto Transfer Buffer Memory (Default) Buffer Memory HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 1-10...

  • Page 21: Rs-232 Considerations

    The cable has a locking mechanism that will firmly hold the cable in place (Figure 1–11). To detach the cable from the reader, you must pinch the plastic on the 8-pin DIN (Figure 1–11) and pull back to disengage the connector. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual 1-11...
  • Page 22 Install the optional cable clip to further secure the cable to the handle with two threaded screws, as shown in Figure 1–12. Securing Cable Clip with Two Threaded Screws FIGURE 1–12. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 1-12...

  • Page 23: Usb Cable Installation

    USB Cable Installation To connect the HE40T to your host computer via USB interface: Make sure the USB cable is sufficiently attached to your HE40T reader (Figure 1–11 and Figure 1–13). Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual 1-13...

  • Page 24: Usb Communication Settings

    USB Communication Settings • USB Keyboard Mode — Data is sent from the Reader and interpreted by the host just as if a US keyboard was being used to enter data. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 1-14...

  • Page 25: Ps2 Cable Installation

    PS2 cable (B). Connect the other connector to host computer into keyboard port (C). The HE40T is powered by the PS2 port and does not require a power supply. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual 1-15...

  • Page 26: Ps2 Communication Settings

    Note: Microscan does not guarantee compatibility with all models of laptops. PS2 Communication Settings Scan the codes in Figure 1–18 to set the reader to the PS2 communication setting: HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 1-16...

  • Page 27: Rs-232 Cable Installation

    RS-232 interface and utilizing Batch functionality with the BH1/BH2 battery handle, the HE40T will recharge the battery whenever the reader is attached to a RS-232 cable that is plugged into a wall socket. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual 1-17...
  • Page 28 Caution You must use a Microscan-approved power adapter. Reader failure due to use of incorrect power adapter will void all warranties. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 1-18...

  • Page 29: Rs-232 Communication Data Bit Settings

    RS-232 Communication Baud Rate Settings Scan the codes in Figure 1–23 to set the appropriate baud rate: Baud Rate Codes FIGURE 1–23. 1200 2400 4800 9600 57600 (Default) 115200 19200 38400 Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual 1-19...

  • Page 30: Rs-232 Communication Parity Settings

    Connecting With A QuickConnect Code ® If you purchased a CodeXML Bluetooth Modem or a Belkin Bluetooth adapter from Microscan or from an authorized distributor, a QuickConnect code was included (Figure 1–26). HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 1-20...
  • Page 31 Note: If the HE40T reader powers off without scanning the Save Settings code, you will lose your settings. Reset to RF Factory Defaults Code FIGURE 1–27. Reset to RF Save Settings Factory Defaults Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual 1-21...

  • Page 32: Radio Range And Transferring Data

    Note: While robust, One Way Mode doesn’t guarantee data integrity and you may have data loss when operating in the fringes of radio range or in the presence of radio interference. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 1-22...

  • Page 33: Save Settings

    HE40T may not appear disconnected in the slave Bluetooth connection manager for 10 – 15 seconds after the command is issued). The HE40T will also disconnect after 90 seconds of inactivity. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual 1-23...

  • Page 34: Reconnecting To The Reader

    The Auto Disconnect feature is used when multiple HE40T readers are connecting to the same Bluetooth Radio. By enabling Auto Disconnect, the HE40T radio disconnects after each data transmission, allowing other radios to connect. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 1-24...

  • Page 35: Bluetooth Radio - Timeout Settings (Uncabled)

    If the reader has power (USB cable, power cable, etc.), it will disconnect based on cable timeout settings. Bluetooth Radio Timeout Settings (Uncabled) FIGURE 1–34. 5 Minutes 10 Minutes 90 Seconds (Default) 15 Minutes 30 Minutes 1 Hour 2 Hours Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual 1-25...

  • Page 36: Bluetooth Radio - Out Of Range Notification Settings

    HE40T reader. Each LED has a small icon underneath that represents the following: HE40T LEDs FIGURE 1–36. Memory / Connection Icon Battery or Power icon HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 1-26...
  • Page 37 None None 1 Beep, Successfully Decoded slight pause, and Processed 1 Beep Configuration Code But Flash Red 3 Times Flash Red 3 Times 3 Beeps Was Not Successfully Decoded and Processed Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual 1-27...

  • Page 38: Targeting And Reading Techniques

    The H2 Cabled Handle and BH1/BH2 Battery Handle each feature a trigger on the handle. The two triggers on the top of the reader also work when the handle is attached. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 1-28...
  • Page 39 To read a symbol with the HE40T: The HE40T features omnidirectional decoding. Center the symbol in any orientation within the laser dot aiming pattern (Figure 1–38). Centering the Symbol Within the Laser Dot FIGURE 1–38. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual 1-29...
  • Page 40 To read a symbol with a shiny background, hold the HE40T slightly tilted to avoid the reflected light from the LEDs. The reader may be optimized to your specific environment by scanning codes in Chapter 6, “Advanced Decoder Performance”. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 1-30...

  • Page 41: Imager Field Of View And Resolution

    If only the far field is used (large, lower density symbols), the near field can be ignored. • Further optimization may be obtained by “windowing” the field to a smaller area. SXGA Imaging Area FIGURE 1–39. 1024 Near Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual 1-31...
  • Page 42 Getting Started Chapter Imager Focal Lengths FIGURE 1–40. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 1-32...

  • Page 43: Optimization And Trigger Programming

    The width of the Field of View is 4” (101.6 mm) at the optimal focus point. The following sections provide you with the ability to program individual triggers, or all triggers, to perform with different parameters. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...

  • Page 44: Left Trigger Programming

    Scan the codes in Figure 2–2 to set the right trigger functionality: Right Trigger Programming Codes FIGURE 2–2. Read Codes with Both Imagers (Default) Read Code with Far-Field Imager Only Read Code with Near-Field Imager ONLY HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 45: Handle Trigger Programming

    Near Field Only On Far Field Only On Off (Default) Note: This function is only recommended for short term use because of battery “Continuous Scan — Sleep Timeout” on page 2-4). consumption (see Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...

  • Page 46: Continuous Scan - Sleep Timeout

    Continuous Scan - Duration Before Entering Sleep Mode FIGURE 2–6. Uncabled - 5 Minutes (Default) Uncabled - 15 Minutes Uncabled - 30 Minutes Note: This function is only recommended for short term use because of battery consumption. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 47: Continuous Scan - Trigger Delays

    Motion Detection Scan Settings Scan the codes in Figure 2–8 to set the reader to read when it detects motion in its scanning zone: Motion Detection On/Off Codes FIGURE 2–9. Off (Default) Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 48 Optimization and Trigger Programming Chapter HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 49: He40T Programming: Symbology Settings

    FIGURE 3–1. Reset to USB Factory Defaults Radio setting will not be reset with this code Reset to PS2 Factory Defaults Radio setting will not be reset with this code Save Settings Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 50 Clear All CodeXML Rules Readers are shipped from manufacturing with default communication settings that are hardware dependent. Note: If you do not save your settings, and the HE40T loses power, you will lose your settings. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 51: Codabar Symbology

    Code 39 Symbology Scan the codes in Figure 3–4 to enable/disable Code 39 symbology settings: Code 39 Symbology Codes FIGURE 3–4. Code 39 On Code 39 Off (Default) Sample Code 39 Code Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...

  • Page 52: Code 93 Symbology

    Code 128 Symbology Scan the codes in Figure 3–6 to enable/disable Code 128 symbology settings: Code 128 Symbology Codes FIGURE 3–6. Code 128 On Code 128 Off (Default) Sample Code 128 Code HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 53: Interleaved 2 Of 5 Symbology

    Sample Int 2 of 5 Code PDF 417 Symbology Scan the codes in Figure 3–8 to enable/disable PDF 417 symbology settings: PDF417 Symbology Codes FIGURE 3–8. PDF 417 On PDF 417 Off (Default) Sample PDF 417 Code Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...

  • Page 54: Qr Code Symbology

    QR Code Symbology Scan the codes in Figure 3–9 to enable/disable QR/Micro QR Code symbology settings: QR Code Symbology Codes FIGURE 3–9. QR/Micro QR Off (Default) QR/Micro QR On Sample QR Code HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 55: Upc/Ean/Jan

    Scan the codes in Figure 3–10 to enable/disable UPC/EAN/JAN symbology settings: UPC/EAN/JAN Symbology Codes FIGURE 3–10. UPC On UPC Off (Default) UPC Extension On UPC Extension Off (Default) Sample UPC A Code Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...

  • Page 56: All 1D Bar Codes

    Scan the codes in Figure 3–11 to enable all supported 1D bar codes (Code 128, Code 39, Code 93, I 2 of 5, Codabar, UPC). All 1D Codes On/Off FIGURE 3–11. All 1D Codes On All 1D Codes Off HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 57: Dod Uid Settings

    If there is a valid UII/CPN/LBN, a UII/CPN/LBN string is outputted. For decoded Data Matrix with invalid UII/CPN/LBN, HE40T stops image acquisition without an output string. The UII/CPN DM On option will have the following output format: Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 58 UII/CPN DM with Data Fields — The HE40T is configured to construct UII/CPN/LBN with all the data fields. The UII/CPN with Data Field option has the following output format: UII/CPN; DF0; DF1; DF2; DF3; DF4; DF5; DF6; DF7 HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...
  • Page 59 (UII ERROR: xxxx) (30P ERROR: xxxx) Original decoded data (UII ERROR: xxxx) (PNR ERROR: xxxx) Invalid UII and Invalid LBN (UII ERROR: xxxx) (240 ERROR: xxxx) (UII ERROR: xxxx) (30T ERROR: xxxx) Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 60 There is a space between UII and CPN in both tables (UII:12345678 CPN:87654321). – The constructed UII type can be Contruct_1, Contruct_2, Construct_1_2, or IUID_EQUIVALENT. – The constructed CPN type can be PNR, 30P, or 240. The constructed LBN type is 30T. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...
  • Page 61 UII ERROR: SPACE AFTER TEI DATA QUALIFIER UII ERROR: TEI DATA QUALIFIER UII ERROR: UII ELEMENT INCOMPLETE UII ERROR: WRONG FORMAT INDICATOR UII ERROR: UII STRING TOO LONG • ; — A field separator. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 62 Department of Defense Unique Identification (UID) Chapter HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 63: Reader Feedback And Special Settings

    Vibrate On Vibrate On Beep On (Default) Beep On Beep Off Scan the codes in Figure 5–2 to set your reader’s volume: Volume Codes FIGURE 5–2. Beep Low Beep Off Beep High (Default) Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...

  • Page 64: Laser Settings

    Scan the codes in Figure 5–5 to set the amount of time before a reader powers down: Reader Power Off Codes FIGURE 5–5. 2 Hours 1 Hour 4 Hours (Default) Press and hold (1 second) any red trigger on the reader to power up a reader. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 65: Reader Id And Firmware Version

    SSSSSSSSSS — The reader’s serial number (ten digits) • P — Is “A” if running firmware is the application, “B” if bootLoader • XXXXXXXX — Microscan Internal ID (not applicable) • MicroscanZ.Z.Z.ZZ — Microscan software release version Example Xap/i3308314606040010029505A17?0016?Microscan1.0.1.7 Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...

  • Page 66: Reader Settings Locked & Unlocked

    US English With Leading 0 option with the U.S. keyboard. • German — Use this option with the German keyboard to display ASCII characters the same way as the US English With Leading 0 option with the U.S. keyboard. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 67: Time Stamp Settings

    If you enable the time set feature, every time the HE40T is powered off or rebooted, the timer will stop. Scan the codes in Figure 5–9 to turn the time set on/off: Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 68 Reader Feedback and Special Settings Chapter Time Set On/Off FIGURE 5–9. Off (Default) Note: The time set feature is in relative time from when the reader was last powered up. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 69: Advanced Decoder Performance

    Note: Turbo Dot Peen mode should not be used for reading small marks (dot peen or others) as it may increase the processing time and reduce the robustness of reading small marks. Turbo Dot Peen Mode Codes FIGURE 6–1. Off (Default) Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 70 Advanced Decoder Performance Chapter HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 71: Adding A Prefix Or Suffix

    (i.e., if you scan the comma prefix twice, you will get two comma prefixes). Scan the codes in Figure 7–1 to set the appropriate prefix. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 72 Prefix - Comma Prefix - Space Prefix - Tab (USB/PS2) Prefix - Tab (RS-232) Prefix - Erase Prefix - Carriage Return Line Feed (RS-232) This code will erase all prefix data Save Settings HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 73: Suffix Settings

    Suffix Codes FIGURE 7–2. Suffix - Space Suffix - Comma Suffix - Enter (USB/PS2) Suffix - Carriage Return Suffix - Line Feed Suffix - Carriage Return Line Feed (RS-232) (RS-232) (RS-232) Save Settings Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...

  • Page 74: Erase Prefix And Suffix Settings

    This code will erase all suffix data Erase Prefix and Suffix Settings Scan the codes in Figure 7–4 to erase all prefix and suffix data: Erase Prefix & Suffix Codes FIGURE 7–4. Erase Prefix & Suffix Data HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 75: Maintenance And Troubleshooting

    Bootloader Mode is utilized to download new version of bootloader firmware and custom applications M692_01 Reset to RF One Way Bootloader Mode Factory Default Settings Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...

  • Page 76: General Safety Information

    Charge the Lithium Ion Battery in the BH1/BH2 with Microscan’ cables ONLY. Do not open battery, dispose of in fire, or short circuit; it may ignite, explode, leak, or get hot, causing personal injury. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 77: He40T Accessories

    The HE40T’s housing may be cleaned in the same way. For applications that require cleaning with disinfectant, please use products with the following ingredients: • Isopropyl Alcohol • Ethyl Alcohol (Denatured Grade) Microscan does not recommend using bleach. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...

  • Page 78: Hawkeye™ 40T User Manual

    Maintenance and Troubleshooting Chapter HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 79: Programming Codes For Alternate Os Compatibility

    Reset to USB Factory Defaults Settings Scan the three programming codes (Figure A–2) in the following order: – Microsoft Windows CE, Linux, Mac OS X code – USB Keyboard Mode code – Save Settings code Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 80 Scan codes in order, top to bottom FIGURE A–2. Microsoft Windows CE, Linux, Mac OS X USB Keyboard Mode Save Settings Cycle the power on the HE40T by removing and re-installing the battery in the unit. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...
  • Page 81 Plug the USB cable into the Mac processor (not the keyboard). The screen in Figure A–3 is displayed: Keyboard Setup Assistant Screen - Introduction FIGURE A–3. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 82 Programming Codes for Alternate OS Compatibility Appendix Click Continue. The screen in Figure A–4 is displayed: Keyboard Setup Assistant Screen - Identifying Keyboard FIGURE A–4. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...
  • Page 83 Scan the code in Figure A–5: Code FIGURE A–5. Microscan The screen in Figure A–6 is displayed: Keyboard Setup Assistant Screen - Cannot Identify Keyboard FIGURE A–6. Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 84 Click OK. The Select the Keyboard Type screen is displayed, as shown in Figure A–7: Keyboard Setup Assistant Screen - Select Keyboard Type FIGURE A–7. Select ANSI and then click Done. You are now ready to scan codes in using Mac OS X. HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 85: Certification And Specifications

    Certification and APPENDIX B Specifications CE Compliance The HawkEye™ 40T has been certified to conform to the requirements of Council Directives 89/336/EEC, 73/23/EEC, and 1999/5/EC to comply with the following European Standards: • EN 60950-1:2001 Low Voltage/Safety • EN 300 238-2(2000-07) Radio •...

  • Page 86: Fcc Statement

    Support on the Internet” on page xi. FCC Statement The HawkEye™ 40T has been tested for compliance with FCC regulations and was found to be compliant with all applicable FCC Rules and Regulations This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 87: Fda Statement

    US21 CFR Subchapter J Part 1040.10 EN 60950-1:2001 The HawkEye™ 40T can be set to use targeting lasers. If the targeting lasers are activated, do not stare into the beams. The HawkEye™ 40T’s targeting lasers have been rated as Class 2M Lasers by IEC 60825-1...

  • Page 88: Specifications

    256 level gray scale Optical Resolution: Near Field:1024 x 640 pixels Far Field: 1024 x 640 pixels Pitch: ± 60º (from front to back) Skew: ± 60º from plane parallel to symbol (side-to-side) HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...

  • Page 89: User Environment

    Code, Code 39, Code 128, UPC/EAN/JAN, Int 2 of 5, Codabar, Code 93 Image Output Options: JPEG or BMP (Uncompressed) Field Selection: Near or Far Resolution Selection: SXGA (1024 x 640) Time Stamp: Interval Logging Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual...
  • Page 90 Certification and Specifications Appendix HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009...
  • Page 91 1-24 code 39 operation 1-20 code 93 out of range notification settings 1-26 continuous scan range 1-22 timeout settings 1-25 duplicate scan delay 2-5 transferring data 1-22 sleep timeout 2-4 Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual Index-1...
  • Page 92 1-18 Far Field parity settings 1-20 Feedback 1-9, 1-26 stop bit settings 1-19 send & buffer mode 1-10 General Safety Information log mode 1-10 suffix HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 Index-2...
  • Page 93 1-19 Motion Detection parity settings 1-20 stop bit settings 1-19 Near Field Safety general information One Way Mode 1-22 Scan Settings Operating Range motion detection line of sight 1-22 wireless version Rev 2.0.0, Jan 2009 HawkEye™ 40T User Manual Index-3...
  • Page 94 Targeting Techniques 1-28 Techniques reading 1-28 targeting 1-28 Time Stamp Settings Timeout Settings 1-20 bluetooth radio (uncabled) 1-25 Transfer all data in memory only unsent data in memory 1-10 Trigger delays HawkEye™ 40T User Manual Rev 2.0.0, Jan 2009 Index-4...
