Control/Hex Output - Microscan Quadrus EZ Reader User Manual

Serial Verification

Control/Hex Output

Useful for viewing settings with binary characters when using serial com-
Usage:
mand on a terminal.
Determines the response to an Serial Command Echo or status request
command.
When set to Control, two characters are transmitted to represent a non-
Definition:
displayable character. For example, a carriage return will be shown as the
two characters: ^M.
When set to Hex, the output is the hex character.
<K701,serial command echo status,serial command beep
Serial Cmd:
hex output>
Default: Control
Options: 0 = Control
5-24
1 = Hex
status,control/
Quadrus EZ Reader User's Manual
