Bad/No Symbol Qualification

Bad/No Symbol Qualification
Useful in determining if a symbol is present and if user-defined require-
Usage:
ments for that symbol are met.
Sets the requirements that will qualify an object or a symbol before output-
Definition:
ting a decode or message.

Bad Symbol Message

Usage: Can tell the user if a qualified symbol is present but not decodable.
When enabled, sends a message to the host whenever an object meets
Definition:
specified qualifications for "bad symbol" status.
Serial Cmd: <K715,[unused],message>
Default: BAD_SYMBOL
Options: Up to 128 ASCII characters (except NULL)

No Symbol Message

Usage: Can tell the user if a object does not qualify as a symbol.
When enabled, send a message to the host whenever an object meets
Definition:
specified qualifications for "no symbol" status but is not decoded.
Serial Cmd: <K716,[unused],message>
Default: NO_SYMBOL
Options: Up to 128 ASCII characters (except NULL)
1D/Stacked Symbology Qualification

Minimum Number of Bars

Definition: Sets the minimum number of bars to qualify linear symbols.
<K717,minimum number of
Serial Cmd:
scans,start/stop status>
Default: 0
Options: 0 to 255 (0 is disabled)
5-10
bars,minimum number of qualified
