RS-232 Auxiliary Port

Stop Bits, Aux Port

Usage: Only changed if necessary to match host setting.
Allows the user to select the last one or two bits in each character to indi-
Definition:
cate the end of the character.
<K101,aux port mode,baud
Serial Cmd:
status,daisy chain ID>
Default: One
Options: 0 = One

Data Bits, Aux Port

Usage: Only changed if necessary to match host setting.
Definition: Number of bits in each character.
<K101,aux port mode,baud rate,parity,stop
Serial Cmd:
status,daisy chain ID>
Default: Eight
Options: 0 = Seven

Auxiliary Port Mode

Determines the flow of data between the auxiliary port device(s), the reader,
Definition:
and the host.
<K101,aux port
Serial Cmd:
status,daisy chain ID>
Default: Disabled
0 = Disabled
Options:
3 = Full duplex
Note: RS-232 host and aux port are available with full functionality.
2-12
rate,parity,stop
1 = Two
1 = Eight
mode,baud rate,parity,stop bits,data bits,daisy chain ID
1 = Transparent
4 = Daisy chain
bits,data bits,daisy chain ID
bits,data bits,daisy chain ID
2 = Half duplex
5 = Command Processing
Quadrus EZ Reader User's Manual
