Step 3 —Communicating in Ethernet
By now either the reader should be configured with an IP address or the host computer is
configured to use the reader's default IP address. Now ESP needs configuration:
1. In ESP under the
2. Click the TCP/IP tab.
3. Type in the reader's IP address (as shown on the ESP Communications menu).
4. Click Connect.
5. After a few seconds, ESP should display "CONNECTED" at the bottom of the window.
Quadrus EZ Reader User's Manual
Connect pull down menu, select Settings...
Ethernet
15-7
