Input 1

Input 1
For example, an application is setup so that a mismatch stops the production
line by using outputs in a latch mode. A push button switch can be connected
Usage:
to the input pin so that when pressed, it unlatches the output, allowing the
line to resume operations.
A programmable, discrete input used to reset counters, outputs or control
Definition:
optoelectrical settings.
Serial Cmd: K730,input
<
Default: Disabled
Options: 0 = Disabled
Disabled
Definition: When set to Disabled there is no effect on operation.
Reset Counts
Usage: Primarily used in test mode. Can also be used to reset counters daily.
When set to Reset Counts, a transition to the active state of the input will
Definition:
cause the reader to reset the internal counters.
Unlatch Output
This setting is used in combination with any of the three discrete outputs
Definition: that are in Unlatch Mode 1. A transition to the active state will clear any of
the three outputs that were previously latched.

Active State (Input)

Definition: Sets the active level of the input pin.
Serial Cmd: K730,input
<
Default: Active Off
0 = Active On (same as active closed)
Options:
1 = Active Off (same as active open)
5-38
mode,active state>
1 = Reset Counts
mode,active state>
2 = Unlatch Output
