Appendix F — Serial Configuration Commands
The following table is a summary of all the available serial configuration commands, pre-
sented in the order found in the chapters.
Serial Configuration Commands
Communications
Host Port Connections
Host Port Protocol
Host 232/422 Status
Auxiliary Port
Daisy Chain Autoconfigure
Daisy Chain ID
Ethernet Configuration
Preamble
Postamble
Response Timeout
LRC
Aux Port System Data Status <K146,aux port system data>
Read Cycle
Multisymbol
Trigger Mode/Duration
External Trigger State
Serial Trigger Character
Start Trigger Character
Stop Trigger Character
End of Read Cycle
Active Camera
Captures
Capture Timing
Dual Camera Operations
Store Noread Image
Quadrus EZ Reader User's Manual
<K100,baud rate,parity,stop bits,data bits>
<K140,protocol>
<K102,host 422>
<K101,aux port mode,baud rate,parity,stop bits,data
bits,daisy chain ID status,daisy chain ID>
<K150DAISY>
<K151,daisy chain reader #,daisy chain reader ID>
<K125,IP address,subnet address,gatewayaddress,IP
address mode,primary TCP port,video TCP port>
<K141,status,preamble characters>
<K142,status,postamble characters>
<K143,response timeout>
<K145,status>
<K222,number of symbols,multisymbol separator>
<K200,trigger mode,trigger filter duration>
<K202,extermal trigger state>
<K201,serial trigger character>
<K229,start character>
<K230,stop character>
<K220,end of read cycle,read cycle timeout>
<K240,active camera>
<K241,capture mode,number of captures,rapid capture
mode>
<K242,time before 1st capture,time between capture 1 and
2,,,,,,,,time between capture 7 and 8>
<K243,switching mode,number of internal camera captures,
number of external camera captures,internal camera timeout,
external camera timeout>
<K244,image storage type,image storage mode>
Appendices
A-13
